7 Installation and electrical connection
Installation and electrical connection must
be carried out in accordance with local
regulations and only by qualified person-
nel!
WARNING! Risk of injury!
The existing directives for accident prevention
must be adhered to.
Warning! Danger of electric shock!
Danger from electrical current must be elimi-
nated.
Local directives or general directives [e.g. IEC]
and instructions from local energy supply
companies must be adhered to.

7.1 Installation

Install the switchgear/system at a dry location.
Protect the place of installation from direct expo-
sure to sunlight.
7.2 Electrical connection
DANGER! Risk of fatal injury!
Improper electrical connections can lead to fa-
tal electric shocks.
• Have the electrical connection established by
an electrician approved by the local electricity
supplier only and in accordance with local reg-
ulations.
• Observe the Installation and operating instruc-
tions for the pumps and accessories!
• Disconnect the power supply before any work.
Warning! Danger of electric shock!
There is a potentially fatal voltage on the sup-
ply side, even when the main switch is turned
off.
• The type of mains, current and voltage of the
mains connection must match the details on the
rating plate of the control device.
NOTE:
• Fuse on mains side in accordance with the infor-
mation in the wiring diagram
• Feed the ends of the mains cable through the
threaded cable connections and cable inlets and
wire them according to the markings on the termi-
nal strips.
• Earth the pump/installation in accordance with the
regulations.
7.2.2 Power supply connection
Connect the on-site 3-wire cable (L, N, PE) for the
supplying network to the main switch, in accord-
ance with the wiring diagram.
7.2.3 Battery connection
Connect the batteries using the cables provided.
Firmly tighten the screws on the fixation clips.
Installation and operating instructions Wilo‐Control SC‐Fire Diesel DK
7.2.4 Fault signal/run signals connection
A signal can be taken from the terminal strip for
the fault signal/run signal via a potential-free con-
tact in order to indicate a fault/operation (see wir-
ing diagram).
Potential-free contacts, max. contact load
250 V~/1 A
Warning! Danger of electric shock!
There is a potentially fatal voltage on these
terminals, even when the main switch is turned
off.
8 Commissioning
WARNING! Risk of fatal injury! Commission-
ing by qualified personnel only! Improper
commissioning poses a risk of fatal injury. Have
commissioning performed by qualified person-
nel only.
DANGER! Risk of fatal injury!
When working on the open switchgear, there is
a danger of electric shock from touching the
live components.
This work must only be carried out by quali-
fied personnel!
We recommend that you have the switchgear
commissioned by Wilo customer service.
Before switching on for the first time, the on-site
wiring must be checked, in particular the earthing.
Tighten all terminals prior to commissioning!
8.1 Factory setting
The control is factory preset.
The factory settings can be restored by Wilo cus-
tomer service.
8.2 Checking the speed adjustment
The motor speed is adjusted in the factory. To
check the speed adjustment, start the motor manu-
ally. Once the motor has started, record the speed
with a portable rev counter and compare it to the
speed on the display. If the two values match, no
correction is necessary.
If the difference is large, readjustment is necessary.
Proceed as follows. Set the motor to a constant,
known speed. Enter and confirm this value in
menu 1.2.1.1. Go to the next menu item. In
menu 1.2.1.2, change the setting to "Start" and
confirm. After the adjustment, "Finished" appears
on the display. The speed adjustment is complete
and saved. The motor can be stopped by pressing
the "stop" button (Fig. 2, item 14).
