Wilo -Control SC-Fire Diesel DK Installation And Operating Instructions Manual page 33

English
Code
E54.0
E54.1
E54.2
E54.3
E54.4
E100.1
E100.2
E105.1
E105.2
E106.1
E106.2
E109.0
E130.0
E131.0
E132.0
E133.0
E134.0
E135.0
E136.0
E137.0
If the fault cannot be remedied, please
contact your nearest Wilo customer ser-
vice point or representative.
Installation and operating instructions Wilo‐Control SC‐Fire Diesel DK
Fault description
No bus communication
to HMI board
No bus communication to
charger for battery A
No bus communication
to charger for battery B
Faulty data transfer
from charger for battery
Faulty data transfer
from charger for battery
Battery fault in battery A
Battery fault in battery B
Short-circuit in battery A
Short-circuit in battery B
Cable break in battery A
Cable break in battery B
Freely configurable fault
Lack of fuel
Heating fault
Low oil pressure
Excess motor temperature
Starting pinion not engaged
Pinion rim interrupted
Failed start attempts
Belt break
Causes
Connection to HMI board inter-
rupted
Connection to charger for battery A
interrupted
Connection to charger for bat-
tery B interrupted
Faults on the data cable
Faults on the data cable
Battery A defective
Battery B defective
Battery A defective
Battery B defective
Connection to battery A inter-
rupted
Connection to battery B interrupted Check connection to battery B.
Depending on the fault configu-
ration
Fuel below minimum level
Thermostatic valve for the
heating has triggered
Oil pressure switch has triggered
Thermostatic valve for the
motor has triggered
Confirmation from starting pinion
missing
Confirmation from starting pinion
missing
6 unsuccessful start attempts
performed
No tension for generator
Remedy
Check setting in 5.4.1.0 and
correct, if necessary.
Check connection.
Request customer service.
Check connection.
Request customer service.
Check connection.
Request customer service.
Request customer service.
Request customer service.
Check battery A and replace, if
necessary.
Request customer service.
Check battery B and replace, if
necessary.
Request customer service.
Check battery A and replace, if
necessary.
Request customer service.
Check battery B and replace, if
necessary.
Check connection to battery A.
Request customer service.
Request customer service.
Depending on the fault configura-
tion
Refuel.
Check heating.
Check oil level and refill, if
necessary.
Request customer service.
Check cooling water level.
Request customer service.
Check starter.
Check fuse.
Request customer service.
Check fuse.
Request customer service.
Request customer service.
Check V-belt and replace, if nec-
essary.
Request customer service.
