T1MK1F4S and T1MK1F4SD: Configuration of Mercury Boards:
1. Fasten snap on spacers onto metal pems configuration (A), (B), (C) or (D) of backplane depending on the access controller (Fig. 4, pg. 5).
2. Position access controller module over corresponding spacers and depress onto snap on spacers (Fig. 4a, pg. 5).
3. Mount backplane to enclosure with hardware.
Access Controller Position Chart for the Following Models:
Mercury Access Controller
EP1502, LP1502, MR52, MR16IN, MR16OUT
EP1501, LP1501, MR51e, MR62e
MR50
EP2500, LP2500, MUX8
Fig. 4
Altronix eFlow4NB
-
BAT
+
B
A
D
C
- 5 -
Altronix VR6 is mounted under PDS8(CB)
IN GND
1
OFF - 24V
ON - 12V
ON
LED1
NC C NO COM
OUTPUT 1
-
DC
+
A
Altronix PDS8(CB)
TRIGGER
INPUT
TRG
IN GND
IN GND
IN GND
2
3
4
Altronix ACM4(CB)
LED2
LED3
LED4
NC C NO COM
NC C NO COM
NC C NO COM
OUTPUT 2
OUTPUT 3
OUTPUT 4
ACM4
ACCESS POWER
CONTROLLER
B
D
C
Pem Mounting
A
B
C
D
Fig. 4a
Pem
Snap On
Spacer
Backplane
Mercury Board
Trove1 Mercury Kits Installation Guide
