Access & Power Integration
T1SAK3F4
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TSA1 Altronix/Salto backplane
- (1) eFlow6NB - Power Supply/Charger
- (1) ACM4 - Fused Access Power Controller
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Dual Input Power Distribution Module
T2SAK7F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TSA2 Altronix/Salto backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) ACM8 - Fused Access Power Controller
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Dual Input Power Distribution Module
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TSAK032919
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
T2SAK75F12
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TSA2 Altronix/Salto backplane
- (1) eFlow104NB - Power Supply/Charger
- (1) eFlow102NB - Power Supply/Charger
- (1) ACM8 - Fused Access Power Controller
- (1) ACM4 - Fused Access Power Controller
- (1) PDS8 - Dual Input Power Distribution Module
More than just power.™
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix Trove T1SAK3F4
Summary of Contents for Altronix Trove T1SAK3F4
- Page 1 12 Door Kit with Fused Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TSA1 Altronix/Salto backplane - Trove2 enclosure with TSA2 Altronix/Salto backplane - (1) eFlow6NB - Power Supply/Charger - (1) eFlow104NB - Power Supply/Charger...
-
Page 2: Configuration Chart
Install the three lower screws and make sure to tighten all screws. 3. Mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) in desired location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side Fig. - Page 3 OUT4 OUT5 OUT6 OUT7 OUT8 Common(-) Common(-) DM2+ DM2+ Common Power Outputs (NEG) --- BAT + --- DC + Altronix VR6 mounted under PDS8 Fig. 2a Backplane Standoff HS4 Module Pan Head Screw Trove / SALTO Kits - 3 -...
- Page 4 Fuse6 Fuse7 Fuse8 OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 Common(-) Common(-) DM2+ DM2+ Common Power Outputs (NEG) Altronix VR6 mounted under PDS8 Fig. 3a Backplane Standoff HS4 Module Pan Head Screw - 4 - Trove / SALTO Kits...
- Page 5 IN GND IN GND IN GND IN GND MAIN 10A 250V Altronix ACM8 NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM NC C NO COM OUTPUT 1...
- Page 6 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
- Page 7 T1SAK3F4 Enclosure Dimensions (H x W x D): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.31mm) 7.25” (184.15mm) 1.45” 1.948” (36.83mm) (49.483mm) 4.5” (114.3mm) 13.0” 1.25” 1.25” (330.2mm) (31.75mm) (31.75mm) 1.5” 1.5” 0.5897” (38.09mm) (38.09mm) (14.98mm) 0.569”...
- Page 8 (133.35mm) (50.8mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. IITrove / SALTO K05S MEMBER - 8 -...
