Access & Power Integration
T1RAL3F8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix backplane (TAL1R)
- (1) eFlow6NB - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Fused Dual Output Power Distribution Module
- (1) ACMS8 - Fused Dual Output Access Power Controller
T1RAL33F16
16 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix backplane (TAL1R)
- (2) eFlow6NB - Power Supply/Chargers
- (2) ACMS8 - Fused Dual Output Access Power Controllers
Installation Guide
All registered trademarks are property of their respective owners.
Rev. T1RAL111518
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
More than just power.™
Advertisement
Related Manuals for Altronix TROVE T1RAL3F8
Summary of Contents for Altronix TROVE T1RAL3F8
- Page 1 T1RAL3F8 8 Door Kit with Fused Outputs Fully assembled kit includes: - Trove1R rack enclosure with Altronix backplane (TAL1R) - (1) eFlow6NB - Power Supply/Charger - (1) VR6 - Voltage Regulator - (1) PDS8 - Fused Dual Output Power Distribution Module...
-
Page 2: Configuration Chart
Overview: Altronix Trove Rack kits are pre-assembled and consist of Trove1AL1R enclosure/backplane with factory installed Altronix power supply/ charger(s) and sub-assemblies. Configuration Chart: Maximum Supply Nominal DC Power Power Current for Main Output Voltage 120VAC Supply Supply and Aux. Outputs... -
Page 3: Hardware Included
Assembling and Attaching Z Bracket Wire Management Accessory (included): Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig. 1, pg. 3). 2. Attach arms to each other using bolts and lock nuts (Fig. 1a, pg. 3). - Page 4 1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware). 2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) turn the enclosure upside down. Punch out the knockout in designated location, on the back of the unit, from outside of the drawer (Fig. 3, pg. 4).
- Page 5 T1RAL3F8 Configuration Fig. 4 To IEC connector Altronix - eFlow6NB 24VDC Altronix - VR6/PDS8 Altronix - ACMS8 COM-- GND GND Trove1RAL Series - 5 -...
- Page 6 T1RAL33F16 Configuration Fig. 5 To IEC connector Altronix - eFlow6NB 24VDC Altronix - ACMS8 COM-- GND GND Altronix - eFlow6NB Altronix - ACMS8 12VDC COM-- GND GND - 6 - Trove1RAL Series...
- Page 7 Notes: Trove1RAL Series - 7 -...
- Page 8 3.25” 82.3mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. MEMBER IITrove1RAL Series J12T - 8 -...
