Access & Power Integration
T1KE34D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) AL600ULXB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T1KE38D
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TLU1 backplane
- One (1) AL600ULXB - Power Supply/Charger
- Two (2) ACM4CB - PTC Access Power Controllers
T2KE3316D
16 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TLU2 backplane
- Two (2) AL600ULXB - Power Supply/Charger
- Two (2) ACM8CB - PTC Access Power Controllers
Installation Guide
All components of this Trove kit are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
All registered trademarks are property of their respective owners.
Rev. 122221
Installing Company: _________________________ Service Rep. Name: ____________________________________________
Address: _________________________________________________________ Phone #: ___________________________
More than just power.™

Advertisement

loading
Need help?

Need help?

Do you have a question about the TROVE T1KE34D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Altronix TROVE T1KE34D

Summary of Contents for Altronix TROVE T1KE34D

  • Page 1 Access & Power Integration T1KE34D 4 Door Kit with PTC Outputs Fully assembled kit includes: - Trove1 enclosure with TLU1 backplane - One (1) AL600ULXB - Power Supply/Charger - One (1) ACM4CB - PTC Access Power Controller T1KE38D 8 Door Kit with PTC Outputs Fully assembled kit includes: - Trove1 enclosure with TLU1 backplane - One (1) AL600ULXB - Power Supply/Charger...

  • Page 2: Configuration Chart

    Overview: Altronix Trove Kisi kits are pre-assembled and consists of Trove1LU1 or Trove2LU2 enclosure/backplane with factory installed Altronix power supply/charger and sub-assemblies. Trove Kisi kits also accommodates up to four (4) Kisi Pro Controllers for up to sixteen (16) doors in a single enclosure.
  • Page 3 T1KE34D: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 2, pg. 3). 2. Attach mounting magnets to TLU1 in the approximate position as shown below (Fig. 2, pg. 3). Note: Kisi Pro Controllers should be properly oriented.
  • Page 4 T1KE38D: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 3, pg. 4). 2. Attach mounting magnets to TLU1 in the approximate position as shown below (Fig. 3, pg. 4). Note: Kisi Pro Controllers should be properly oriented.
  • Page 5 T2KE3316D: Configuration of Kisi Pro Controllers: 1. Fasten mounting magnets (provided) to Kisi Pro Controllers with screws and spacers (provided) using the controllers’ mounting holes (Fig. 4, pg. 5). 2. Attach mounting magnets to TLU2 in the approximate position as shown below (Fig. 4, pg. 5). Note: Kisi Pro Controllers should be properly oriented.
  • Page 6 T1KE34D/T1KE38D Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6” (15.2mm) 0.57”...
  • Page 7 T2KE3316D Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
  • Page 8 Notes: Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty. MEMBER IIT1KE34D/38D / T2KE3316D L27U - 8 -...
