Access & Power Integration
T1RM3F4V
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix and Mercury backplane (TM1R)
- (1) eFlow6NBV - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8 - Fused Dual Output Power Distribution Module
- (1) ACM4 - Fused Access Power Controller
T1RM3F4DV
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix and Mercury/LenelS2 backplane (TM1R)
- (1) eFlow6NBV - Power Supply/Charger
- (1) VR6 - Voltage Regulator
- (1) PDS8CB - PTC Dual Output Power Distribution Module
- (1) ACM4CB - PTC Access Power Controller
Installation Guide
All registered trademarks are property of their respective owners.
Rev. T1RM3F4V080720
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Related Manuals for Altronix TROVE T1RM3F4V
Summary of Contents for Altronix TROVE T1RM3F4V
- Page 1 T1RM3F4V 4 Door Kit with Fused Outputs Fully assembled kit includes: - Trove1R rack enclosure with Altronix and Mercury backplane (TM1R) - (1) eFlow6NBV - Power Supply/Charger - (1) VR6 - Voltage Regulator - (1) PDS8 - Fused Dual Output Power Distribution Module...
- Page 2 Overview: Altronix T1RM3F4V and T1RM3F4DV rack kits are pre-assembled and consist of Trove1M1R enclosure/backplane with factory installed Altronix power supply/charger and sub-assemblies. These kits also accommodate various combinations of Mercury/LenelS2 boards for up to four (4) doors in a single enclosure.
- Page 3 1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware). 2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent) turn the enclosure upside down. Punch out the knockout in designated location, on the back of the unit, from outside of the drawer (Fig.
- Page 4 Assembling and Attaching Z Bracket Wire Management Accessory (included): Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory. Hardware (included): Fig. 3 Ten (10) bolts and eight (8) lock nuts. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig.
- Page 5 Pem Mounting LP1502, MR52, MR16IN, MR16OUT LP2500, MUX8 LP1501, MR62e MR50 Fig. 5 To IEC connector Altronix Altronix eFlow6NB eFlow6NBV PWR1+ PWR1+ Altronix PDS8(CB)/VR6 Fig. 5a COM(-) Pan Head Screw OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 COM(-) PWR1+...
- Page 6 Notes: - 6 - T1RM3F4(D)V Installation Guide...
- Page 7 Notes: T1RM3F4(D)V Installation Guide - 7 -...
- Page 8 116.1mm 26.5” 673.1mm 19” (482.6mm) 3.375” 85.8mm Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIT1RM3F4(D)V...
