Altronix/CDVI Kits
Models Include:
T1CVK3F4
4 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1 enclosure with TC1 Altronix/CDVI backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) ACM4 - Fused Access Power Controller
T2CVK7F10
10 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- One (1) eFlow104NB - Power Supply/Charger
- One (1) ACM8 - Fused Access Control Module
- One (1) ACM4 - Fused Access Control Module
- One (1) PD8UL - Fused Power Distribution Module
T2CVK33F10
10 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- Two (2) eFLow6NB - Power Supply/Chargers
- Two (2) MOM5 - PTC Power Distribution Modules with Fire Alarm Interface
T3CVK77F20
20 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove3 enclosure with TCV3 Altronix/CDVI backplane
- Two (2) eFlow104NB - Power Supply/Chargers
- Two (2) ACM8 - Fused Access Control Modules
- One (1) ACM4 - Fused Access Control Module
- One (1) PD8UL - Fused Power Distribution Module
- One (1) RSB2 - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
All components of these Trove kits are UL Listed sub-assemblies.
Please refer to the included corresponding Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TCVK_112723
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T1CVK3F4D
4 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove1 enclosure with TC1 Altronix/CDVI backplane
- One (1) eFlow6NB - Power Supply/Charger
- One (1) ACM4CB - PTC Access Power Controller
T2CVK7F10D
10 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- One (1) eFLow104NB - Power Supply/Charger
- One (1) ACM8CB - PTC Access Control Module
- One (1) ACM4CB - PTC Access Control Module
- One (1) PD8ULCB - PTC Power Distribution Module
T2CVK33F10Q
10 Door Networked Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TCV2 Altronix/CDVI backplane
- Two (2) eFLow6NB - Power Supply/Chargers
- One (1) LINQ2 - Network Communication Module
- Two (2) MOM5 - PTC Power Distribution Modules with Fire Alarm Interface
T3CVK77F20D
20 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove3 enclosure with TCV3 Altronix/CDVI backplane
- Two (2) eFlow104NB - Power Supply/Chargers
- Two (2) ACM8CB - PTC Access Control Modules
- One (1) ACM4CB - PTC Access Control Module
- One (1) PD8ULCB - PTC Power Distribution Module
- One (1) RSB2 - Rocker Switch Bracket with
Two (2) Rocker Switches (Not evaluated by UL)
More than just power.™
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Altronix TROVE T1CVK3F4D
Summary of Contents for Altronix TROVE T1CVK3F4D
- Page 1 4 Door Kit with PTC Outputs Fully assembled kit includes: Fully assembled kit includes: - Trove1 enclosure with TC1 Altronix/CDVI backplane - Trove1 enclosure with TC1 Altronix/CDVI backplane - One (1) eFlow6NB - Power Supply/Charger - One (1) eFlow6NB - Power Supply/Charger...
-
Page 2: Configuration Chart
Overview: Altronix Trove CDVI kits are pre-assembled and consist of Trove enclosures/backplanes with factory installed Altronix power supply/chargers and sub-assemblies. These kits also accommodate various combinations of CDVI Atrium A22K/A22NB/ADH10 boards for up to twenty (20) doors in a single enclosure. - Page 3 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 2 Fig. 2a TRIGGER INPUT IN GND IN GND IN GND IN GND Altronix ACM4(CB) Spacer LED1 LED2 LED3 LED4 MAIN NC C NO COM NC C NO COM...
- Page 4 Please make sure that they are mounted correctly, as shown in Fig. 3 below. 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 3 Fig. 3a RJ45 Jack Altronix eFlow104NB Spacer CDVI - A22K/A22NB/ADH10 Backplane CDVI -...
- Page 5 3. Fasten backplane to Trove2 enclosure utilizing pan head screws (provided). Fig. 4 LINQ2 Module (T2CVK33F10Q) Fig. 4a OFF - 24V ON - 12V Spacer RJ45 Jack Altronix eFlow6NB CDVI - A22K/A22NB/ADH10 Backplane AC DC NC C NO NC C NO TRIGGER +AUX- AC FAIL...
- Page 6 Please make sure that they are mounted correctly, as shown in Fig. 5 below. 3. Fasten backplane to Trove3 enclosure utilizing pan head screws (provided). Fig. 5 Fig. 5a RJ45 Jack RJ45 Jack CDVI - A22K/A22NB/ADH10 CDVI - A22K/A22NB/ADH10 Altronix eFlow104NB RSB2 Spacer Backplane RJ45 Jack RJ45 Jack CDVI - A22K/A22NB/ADH10...
- Page 7 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
- Page 8 Notes: - 8 - Trove CDVI Kits Installation Guide...
- Page 9 Notes: - 9 - Trove CDVI Kits Installation Guide...
- Page 10 T1CVK3F4(D) (Trove1) Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6”...
- Page 11 T2CVK7F10(D) and T2CVK33F10(Q) (Trove2) Enclosure Dimensions (H x W x D approximate): 27.25” x 21.5” x 6.5” (692.2mm x 552.5mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77”...
- Page 12 8.75” (222.3mm) 2” (50.8mm) Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty...
