Access & Power Integration
T1RAL13F8P8
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove1R rack enclosure with Altronix backplane (TAL1R)
- (1) eFlow4NB - Power Supply/Charger
- (1) eFlow6NB - Power Supply/Charger
- (1) ACM8 - Fused Access Power Controller
- (1) PD8UL - Fused Power Distribution Module
All components of this Trove kit are UL Listed sub-assemblies.
Please refer to the included corresponding
Sub-Assembly Installation Guides for further information.
Installation Guide
All registered trademarks are property of their respective owners.
Rev. T1RAL13F8P8032019
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
