1.1 Product summary

X-431 PAD is a new generation of sophisticated automotive diagnostic product
with colorful screen and powerful functions developed by LAUNCH.
It provides an optional function of automotive sensor simulation test. "Sensor
simulation test" function is specially designed to diagnose and simulate vehicle
sensor faults quickly and conveniently, including "DC voltage simulation", "Fixed
frequency simulation", "Predefined waveform simulation" and "Hand-painted
waveform simulation".
Vehicle sensors are the signal input devices for electrical control systems, which
can transform all kinds of running parameters, such as vehicle speed, coolant
temperature, engine RPM, air flow, throttle opening, etc., into the electronic
signal for the vehicle computer who can optimize the engine running status per
the above-mentioned parameters to keep the engine working in a prime status.
Meanwhile, it integrates the functions of automobile multimeter, which enables
users to perform voltage, resistance and frequency test. (The function utilizes
the same hardware device as the sensor module)

1.2 Product features

DC voltage simulation
Fixed frequency simulation
Predefined waveform simulation
Hand-painted waveform simulation

1.3 Product function

It features automotive sensor simulation test and multimeter test function.

1.4 Technical parameters

Sensorbox
Parameters
Precision
Voltage range
X-431 PAD Sensorbox User's Manual

1 Foreword

1
Scope
±5%
-5V～+5V
