2.1 Sensorbox structure

Table 2-1 shows the ports and indicators for X-431 PAD sensorbox
No. Name
1 Data receiving
indicator
2 Data sending
indicator
3 Power indicator
4 B type USB port

2 Structure and Accessories

Fig. 2-1 Structural diagram of Sensorbox
Description
Indicator (green) for receiving data from main unit.
Indicator (green) for sending data to main unit.
It keeps steady on (red) after Sensorbox is
powered on.
Connect to main unit with USB cable when it is
