Danfoss EKE 1C Installation Manual page 4

DIN rail mounting / demounting
The unit can be mounted onto a 35 mm DIN rail simply by snapping it into place and securing it with a stopper to prevent
sliding. It is demounted by gently pulling the stirrup located in the base of the housing.
1
Connection overview: EKE 1C
Back board
connections
PWR 24V Vbat
© Danfoss | Climate Solutions | 2023.10
2
3
"Click"
Superheat controller Superheat controller
EKE 1C - 080G5400
STEPPER VALVE DIGITAL OUTPUT
STEPPER VALVE DIGITAL OUTPUT
ANALOG INPUT 1-5
ANALOG INPUT 1-5
Front board
connections
CAN RJ
CAN RJ
CAN CAN RJ
DIGITAL INPUT 1-2
Superheat controller Superheat controller
EKE 1C - 080G5400
RS485
Not used
AN269954243889en-000905 | 4
AO1
