OPERATING CONTROLS AND PROCEDURES
CAUTION
Disengage the swing brake and the swing lock pin or 360°
swing lock before attempting to swing.
The operator must select the proper load chart and RCL
program for the outrigger position selected.
Never push or pull the swing control lever through neutral
to the opposite direction to stop swing motion. Use the
swing brake foot pedal to stop swing rotation.
NOTE: Automatic rear axle oscillation lockout will activate
when the boom swings right or left of the crane
centerline.
To swing the turntable right (clockwise), push the SWING
control lever forward away from yourself. To swing the
turntable left (counterclockwise), pull the swing control lever
back, toward yourself. Always operate the control level with a
slow, even pressure. Use the swing brake foot pedal to stop
rotation, then position the SWING BRAKE switch to ON to
prevent further rotation.
Elevating The Boom (Single Axis Controller Option)
Keep the area above and below the boom clear of all
obstructions and personnel when elevating the boom.
To elevate the boom, pull the BOOM (lift) control lever back,
toward yourself, and hold until the boom reaches the desired
elevation level.
Lowering The Boom (Single Axis Controller Option)
Keep the area beneath the boom clear of all obstructions
and personnel when lowering the boom.
Long cantilever booms can create a tipping condition,
even when unloaded and in an extended, lowered
position.
CAUTION
When lowering the boom, simultaneously let out the hoist
cable to prevent two-blocking the boom nose and hook
block.
The closer the load is carried to the boom nose, the more
important it becomes to simultaneously let out the hoist
cable as the boom is lowered.
3-32
WARNING
WARNING
Published 05-02-2018 Control # 088-10
RT600E OPERATOR MANUAL
To lower the boom, push the BOOM control lever forward,
away from yourself, and hold until the boom is lowered to the
desired position.
Extending The Boom (Single Axis Controller Option)
When extending the boom, simultaneously let out the
hoist cable to prevent two-blocking the boom nose and
hook block.
Check the load chart for the maximum load at a given
radius, boom angle, and length before extending the
boom with a load.
CAUTION
Before extending the boom, ensure the large access
cover on top of the boom base section is installed.
NOTE: When the crane is equipped with an auxiliary hoist,
the telescope function is controlled by a foot pedal.
To extend the boom, push the TELESCOPE control lever
forward, away from yourself, and hold until the boom extends
to the desired length.
Retracting The Boom (Single Axis Controller Option)
When retracting the boom, the load will lower unless the
hoist cable is taken in at the same time
To retract the boom, pull the TELESCOPE control lever
back, toward yourself, and hold until the boom retracts to the
desired length.
E x t e n d i n g a n d R e t r ac t i n g t h e B o o m Wit h th e
Telescope Control Pedal (Single Axis Controller
Option)
The telescope control pedal is used on a crane equipped
with an auxiliary hoist. Push on the top of the pedal to extend
the boom and push on the bottom of the pedal to retract the
boom.
