OPERATING CONTROLS AND PROCEDURES
Engine Warning Indicator
The ENGINE WARNING indicator (65) is located at the
center of the console on the indicator light alert display. It
illuminates amber when energized by a signal from the
engine ECM.
NOTE:
If this indicator light illuminates, see Engine
Operator Manual.
Engine Service Indicator
The ENGINE SERVICE indicator (66) is located in the center
of the console on the indicator light alert display. It illuminates
amber when energized by a signal from the engine ECM.
NOTE:
If this indicator light illuminates, see Engine
Operator Manual.
Throttle Mode Switch
The THROTTLE MODE switch (67) is located on the front
console next to the hand throttle control. The switch is a two
position switch labeled HAND and FOOT and is used to
specify which throttle controls the engine. The HAND
position is for selecting the hand throttle control on the front
console. The FOOT position is for selecting the foot throttle
pedal on the cab floor.
Electronic System Diagnostic Indicator
The ELEC SYS DIAGN indicator (68) is located in the center
of the front console on the indicator light alert display. The
indicator is a red light that is used for troubleshooting the
CANBUS system.
NOTE:
A laptop computer with appropriate cable and
engine or electrical system software are required.
Work Light
The work light (69) is installed on the front of the cab. It is
controlled by the work light switch (36).
°
-29
C Indicator (Optional)
°
The -29
C Indicator (70) is on the front console on the
indicator light display. This light comes on when the
temperature is at or below -29°C. This serves as a warning
for the operator to stop operation in extreme cold.
Strobe Light or Beacon (Not Shown)
The strobe light or beacon is on the roof of the cab. It is on
when the ignition switch is at ACC or RUN.
RCL Lockout (All Units) and RCL Lockout
Alarm (CE Units) (Not Shown)
When the RCL system senses an unsafe condition, the
system locks out the lift cylinder from lowering the boom, but
3-14
allows the lift cylinder to rise to shorten moment so the
operator can make adjustments to the crane and/or prevent
load tipping. For CE units, a lockout alarm sounds when
lockout occurs.
Buzzer (Not Shown)
T h e b u z z e r s o u n d s w h e n t h e r e i s a n e n g i n e s t o p ,
transmission service, low brake pressure, or (for CE units) a
low steer pressure condition that causes a related warning
LED to light. The buzzer is on the relay panel assembly near
the front console.
Hourmeter (Not Shown)
The hour meter is located on the left side of the engine hood,
near the air intake filter. The hour meter is used to register
hours of engine operation.
Skylight Wiper (Not Shown)
The electrically-operated skylight wiper is installed to remove
moisture from the skylight. The single-speed wiper is located
on the left side of the skylight frame. The skylight wiper is
controlled by a switch on the wiper motor.
Backup Alarm (Not Shown)
The backup alarm is an audio system used to warn
personnel outside the crane when the crane is backing up.
The alarm system is electrical and consists of the backup
alarm and its associated wiring. The alarm is connected to
the electrical wiring for the transmission reverse solenoid. It
is activated when the transmission shifter is in the reverse
position. The backup alarm is installed on or near the
radiator shroud at the rear of the engine hood.
Data Link and Service Connector (Not
Shown)
The J1939 data link and service connector is mounted on the
right side of the cab near the 12VDC accessory outlet. It is
used for troubleshooting electrical system and engine faults
and conditions.
NOTE:
Anemometer (Not Shown)
A hand hold anemometer is provided in the cab. It is a wind
speed indicator with a compass located on the top. It
measures wind speed on a scale from 15 to 70 mph.
Emergency Exit
The windshield is considered the Emergency Exit. In an
emergency, push out on the windshield and escape through
the opening.
Published 05-02-2018 Control # 088-10
RT600E OPERATOR MANUAL
A laptop computer with appropriate cable and
engine or electrical system software are required.
