7380F Multi-Point Lock
Installation Instructions
10. Adjust Device
1
IMPORTANT: Device
Must Be In HOLD OPEN
Before Adjusting Device.
2
IMPORTANT: Must
Rotate Exactly Three
Revolutions.
1-800-438-1951 • www.assaabloy.com
Copyright © 2016, 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Hand
Tighten
3x
15
80-8470-7380-000 10/23
