7380F Multi-Point Lock
Installation Instructions
7. Pin Three Assemblies
(1)
Push-on
Retaining Ring
(1)
Drive Pin
1
Right Hand Door Shown
8. Mount Door to Frame
Right Hand
Door Shown
1-800-438-1951 • www.assaabloy.com
Copyright © 2016, 2023, ASSA ABLOY Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
Outside
Inside
2
IMPORTANT: Do not trim door if door rubs along floor!
13
80-8470-7380-000 10/23
