Installation Instructions 7000 ELR Series Multi-Point Lock Table of Contents 1 - Warnings ........................2 2 - General Description . -
Page 2: Warnings
7000 ELR Series Multi-Point Lock Installation Instructions Warnings Changes or modifications to this unit could void the user’s authority to operate the equipment. ALWAYS disconnect power before mak- ing any electrical or mechanical adjustments to the system. Observe precautions for handling electrostatic sensitive devices. This device complies with Part 15 of the FCC Rules. -
Page 3: General Description
7000 ELR Series Multi-Point Lock Installation Instructions General Description The SARGENT stand alone ELR 7000 series multi point lock is designed to automatically retract the rods, concealed within the door. 1. Functions The 7000 ELR can be configured to work in either of two modes: POWER MODE: (see Section 9: Electrical Operation, Section I: POWER MODE) The device is not energized when locked. - Page 4 7000 ELR Series Multi-Point Lock Installation Instructions Parts Breakdown - (See reference list on page 5). ELR 7000 Series A8147-4 10/24 1-800-727-5477 • www.sargentlock.com Copyright © 2015, 2024, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
-
Page 5: Parts Breakdown
7000 ELR Series Multi-Point Lock Installation Instructions Tools Required - (Same for all Series Products) Phillips screwdriver #8-32 tap & drill Slotted screwdriver Drill with bits (for metal door applications) Parts Breakdown - (Continued) ITEM PART # Description Req. MP-7XX-2 WD/MD/AD Inside Trim Assembly 7XX-2 Outside Trim Assembly... -
Page 6: Door Preparation
7000 ELR Series Multi-Point Lock Installation Instructions Door Preparation. Verify Hand and Bevel of Door. Inside Left Hand Right Hand Reverse Reverse Inside Outside Outside If door is not pre-drilled, prepare door according to the appropriate template. Refer to templates at www.sargentlock.com. y Metal door (MD/AD): A7860 y Check hand of door. - Page 7 7000 ELR Series Multi-Point Lock Installation Instructions Preparation of ELR Mounting Holes (If required) Important: If the manufacturer has not pre-drilled the door, prepare the door per instructions below, using plastic template included with the device. Screw hole orientation is not affected by handing. (See steps 1-4). If the door is pre-drilled by the manufacturer, continue to instruc- tions on the following page.
- Page 8 7000 ELR Series Multi-Point Lock Installation Instructions Installation of ELR Assembly Install the upper left mounting screw, Completely tighten the upper left #8-32 x 5/8“Fillister head for metal door mounting screw. and #8 x 5/8“self-tapping wood screw for IMPORTANT: Be careful not to pinch or disconnect the wires located in that area.
-
Page 9: Wiring Diagrams
7000 ELR Series Multi-Point Lock Installation Instructions Installation of Inside Escutcheon Mount inside escutcheon assembly to Position escutcheon against door by plate using (1) #8-32 x 5/8” Phillips flat hooking the top edge on the top of the head undercut machine screw. ELR assembly. -
Page 10: Mechanical Operational Check
7000 ELR Series Multi-Point Lock Installation Instructions Mechanical Operational Check For devices without cylinders, go to “Install Outside and Inside Trim” on page 6. For devices with cylinders, insert key into cylinder and rotate. Rotate the lever to retract latch and rods. Electrical Operational Check SECTION I: POWER MODE In this configuration, the device is not energized when locked. - Page 11 7000 ELR Series Multi-Point Lock Installation Instructions Power Mode Installation Instructions How it works: The ELR module retracts when power is applied and releases when power is removed. Mount ELR 7000 Multi-point device using instruction sheets provided. NOTE: Ensure proper mechanical function before attempting electrical retraction: •...
- Page 12 7000 ELR Series Multi-Point Lock Installation Instructions TIMER MODE Wiring ElectroLynx Opening Installation This is the simplest installation method, requiring the installer to plug 1- Black (ELR 0VDC) 2- Red (ELR + 24VDC) the ElectroLynx connectors from the device to the harness to the hinge 2- White (TIMER A) 4- Green (EG) and then to the pigtail, which is connected to the access control system.
- Page 13 7000 ELR Series Multi-Point Lock Installation Instructions POWER MODE Troubleshooting Prior to electrical troubleshooting, confirm that the mechanical system properly functions, i.e., that the levers fully retract all latches and rods, and the door opens freely. Refer to applicable Sargent 7000 Series Multi-point Device product instruction sheet to correct mechanical installation issues.
-
Page 14: Troubleshooting
7000 ELR Series Multi-Point Lock Installation Instructions LED Signalling Chart SIGNAL CAUSE TROUBLESHOOTING Dark / Unlit Controller microprocessor is not active Confirm connections and incoming power Steady Flashing (GREEN) Normal operation Cycle device by closing the timer circuit Solid Light (GREEN) Input voltage is dropping out of operating range Check wire run and power supply output 1 Flashes Followed by Pause (YELLOW) - Page 15 7000 ELR Series Multi-Point Lock Installation Instructions TIMER MODE Troubleshooting (continued) For additional installation assistance, please contact 1-800-810-WIRE (9473). When calling, please provide the following information to improve our service (provide what you can): y Your name and contact number. y Sargent 7000 Multi-point Device product type.
- Page 16 WARNING WARNING This product can expose you to Attention Installer: Improper lead which is known to the state of installation may result in dam- California to cause cancer and birth age to the product and void the defects or other reproductive harm. factory warranty.
