Installation Guide
AT-VTP-FMK-7-BL
Flush Mount Kits for Velocity Touch Panels
AT-VTP-FMK-7-BL
The Atlona AT-VTP-FMK-7 is a flush mount kit for Velocity™ 7" touch panels. It allows the touch
panel to be recessed into a wall so the panel face is virtually flush with the wall surface. The
VTP-FMK-7 kit fastens to the wall with adjustable metal tabs and the touch panel attaches to
the mount via four magnets. These magnets secure the touch panel to the enclosure when in
use while also allowing it to easily be removed for maintenance if necessary. The VTP-FMK-7 is
available in black and compatible with Velocity 7" touch panels including the AT-VTP-700VL-BL.
Package Contents
1 x AT-VTP-FMK-7-BL
1 x Perforated Wall Cutout Template
4 x Magnets
4 x Plastic Washers
4 x Screws
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Panduit ATLONA AT-VTP-FMK-7-BL
Summary of Contents for Panduit ATLONA AT-VTP-FMK-7-BL
- Page 1 Installation Guide AT-VTP-FMK-7-BL Flush Mount Kits for Velocity Touch Panels AT-VTP-FMK-7-BL The Atlona AT-VTP-FMK-7 is a flush mount kit for Velocity™ 7” touch panels. It allows the touch panel to be recessed into a wall so the panel face is virtually flush with the wall surface. The VTP-FMK-7 kit fastens to the wall with adjustable metal tabs and the touch panel attaches to the mount via four magnets.
-
Page 2: Mounting Instructions
Installation Guide AT-VTP-FMK-7-BL Mounting Instructions Use the following steps to install the AT-VTP-FMK into the wall. Remove the inner cut out from the Perforated Wall Cutout Template. The two outer rings should remain. 9 i n i n c 8 . 0 9 i n . - Page 3 Installation Guide AT-VTP-FMK-7-BL Pull the Ethernet cable through the hole in the wall and thread it through the VTP-FMK. Slide the VTP-FMK into the hole in the wall until it is pressed fully against the wall. Press a screwdriver into the triangle metal flaps of the unit to secure the VTP-FMK into the wall.
- Page 4 Installation Guide AT-VTP-FMK-7-BL *Optional* If mounting screws are installed in the Velocity Touch Panel, remove them from the back of the unit. Thread the screw into the magnet first, followed by the washer. Screw the group into the back of the Velocity Touch Panel. 10.
- Page 5 Installation Guide AT-VTP-FMK-7-BL Panel Removal If the panel needs to be removed from the flush mount, it can be done using two methods: corner press or included suction cup. Press a finger into the top right corner. The left side of the panel will pop out and the panel can be removed.
-
Page 6: Warranty
Installation Guide AT-VTP-FMK-7-BL Warranty To view the product warranty, use the following link or QR code: https://atlona.com/warranty/. International atlona.com 408.962.0515 41.43.508.4321 • • © 2024 Atlona Inc. All rights reserved. “Atlona” and the Atlona logo are registered trademarks of Atlona Inc. All other brand names and trademarks or registered trademarks are the property of their respective owners.
