- Page 1 Installation Guide 40814 Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20231010R1 DATE: ________________...
-
Page 2: Table Of Contents
7/16”, 9/16” Socket and Wrench Before You Begin • Read all instructions prior to assembling or installing any Holman product. • Always locate your installation locations prior to performing any work. • Extended ladder hooks must be installed on the inner mounting location to avoid issues with drop down actuation. -
Page 3: Parts List
Instructions – 40814 Parts List DO NOT EXCEED MANUFACTURERS WEIGHT CAPACITY FOR ROOF. Step 1 – Remove Existing Ladder Hooks and Ladder Stops NOTE: If you have not installed the ladder hooks yet this step can be skipped. • Remove the two 1/4” lock nuts and 1/4”... -
Page 4: Step 2 - Install Extended Ladder Stops
Instructions – 40814 Step 2 – Install Extended Ladder Stops • Using the ladder stop hardware removed in step 1, bolt ladder hook to the cross bar. Step 3 – Install Extended Ladder Hooks NOTE: Roof height clearance is reduced when extended ladder hook is installed. Please verify and be aware of the total height of the vehicle with rack installed. - Page 5 Instructions – 40814 AT LEAST 1/4” Rack shown assembled for clarity. GO BACK AND TIGHTEN ALL HARDWARE. INSTALLATION IS COMPLETE. For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 4...
