Summary of Contents for Holman 40823
- Page 1 Instruction Guide 40823 Holman Rancho Cordova, CA 95742 800-343-7486 InstallationSupport@Holman.com 20230208R2 DATE: ________________...
-
Page 2: Table Of Contents
3/16” Allen Hex Wrench Before You Begin Read all instructions prior to assembling or installing any Holman product. Always locate your installation locations prior to performing any work. For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) -
Page 3: Parts List
Instructions – 40823 Parts List Hardware For Technical Support Call: 800-343-7486, Monday-Friday, 7AM - 4 PM (PST) Page 2... -
Page 4: Step 1 - Assemble Cross Bars
Instructions – 40823 DO NOT EXCEED MANUFACTURERS WEIGHT CAPACITY FOR ROOF! Step 1 – Assemble Cross Bars Insert the short cross tube into the larger cross tube. Screw 3/8” x 3/8” set screw into the cross tube and snug tighten but allow for movement. -
Page 5: Step 3 - Attach Mount Feet To Crossbars
Instructions – 40823 Step 3 – Attach Mount Feet to Crossbars Attach each foot to the crossbars using a 1/2" x 1” counter sunk screw. Snug tighten. Step 4 – Install Rack on Van Roof Place rack on top of van, adjusting width of the cross tubes as needed.
