KINO-ADL-H610 Mini-ITX Motherboard
MODEL:
KINO-ADL-H610
Mini-ITX SBC supports LGA1700 Intel® 12th/13th Generation
Core™ i9/i7/i5/i3, Pentium® and Celeron® processor, DDR4,
triple independent displays, dual 2.5GbE LAN, USB 3.2,
SATA 6Gb/s and RoHS
User Manual
Page 1
Rev. 1.00 – April 27, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINO-ADL-H610 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology KINO-ADL-H610

Summary of Contents for IEI Technology KINO-ADL-H610

  • Page 1 KINO-ADL-H610 Mini-ITX Motherboard MODEL: KINO-ADL-H610 Mini-ITX SBC supports LGA1700 Intel® 12th/13th Generation Core™ i9/i7/i5/i3, Pentium® and Celeron® processor, DDR4, triple independent displays, dual 2.5GbE LAN, USB 3.2, SATA 6Gb/s and RoHS User Manual Page 1 Rev. 1.00 – April 27, 2023...
  • Page 2 KINO-ADL-H610 Mini-ITX Motherboard Revision Date Version Changes April 27, 2023 1.00 Initial release Page 2...
  • Page 3 KINO-ADL-H610 Mini-ITX Motherboard Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 KINO-ADL-H610 Mini-ITX Motherboard Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    PTIONAL TEMS 3 CONNECTORS ......................27 3.1 P ..............28 ERIPHERAL NTERFACE ONNECTORS 3.1.1 KINO-ADL-H610 Layout ................. 28 3.1.2 Peripheral Interface Connectors ..............29 3.1.3 External Interface Panel Connectors ............... 30 3.2 I ..............31 NTERNAL ERIPHERAL ONNECTORS 3.2.1 Audio Connector ....................31 3.2.2 RTC battery connector ..................
  • Page 6 KINO-ADL-H610 Mini-ITX Motherboard 3.2.12 LAN LED Connectors ..................43 3.2.13 M.2 Slot, A-key ....................44 3.2.14 M.2 Slot, M-key ....................46 3.2.15 IEI iDPM slot ....................48 3.2.16 PCIe x16 Slot ....................50 3.2.17 RS-232 Serial Port Connector ............... 50 3.2.18 SATA 6Gb/s Drive Connectors ...............
  • Page 7 KINO-ADL-H610 Mini-ITX Motherboard 5 BIOS ..........................86 5.1 I ......................87 NTRODUCTION 5.1.1 Starting Setup ....................87 5.1.2 Using Setup ...................... 88 5.1.2.1 Keyboard Navigation ................88 5.1.2.2 Touch Navigation ..................89 5.1.3 Getting Help ..................... 90 5.1.4 Unable to Reboot after Configuration Changes ..........90 5.1.5 BIOS Menu Bar ....................
  • Page 8 KINO-ADL-H610 Mini-ITX Motherboard 5.4.2.1.2 PCIe Root Port Setting ............... 128 5.4.2.2 SATA Configuration ................130 5.4.2.3 HD Audio Configuration ................. 131 5.5 S ....................... 132 ECURITY 5.6 B ........................134 5.6.1 Boot Configuration ..................134 5.7 S & E ......................135 A REGULATORY COMPLIANCE ................
  • Page 9 KINO-ADL-H610 Mini-ITX Motherboard List of Figures Figure 1-1: KINO-ADL-H610 ......................14 Figure 1-2: Connectors ........................16 Figure 1-3: KINO-ADL-H610 Dimensions (mm) .................17 Figure 1-4: Data Flow ........................18 Figure 3-1: Peripheral Interface Connectors (Front Side) ............28 Figure 3-2: Audio Connector Location ..................31 Figure 3-3: Battery Connector Location ..................33 Figure 3-4: Buzzer Connector Location ..................34...
  • Page 10 KINO-ADL-H610 Mini-ITX Motherboard Figure 3-28: USB 3.2 Gen2 and LAN Connector ................60 Figure 3-29: LAN Connector ......................61 Figure 3-30: USB 3.2 Gen1 and LAN Connector ................62 Figure 3-31: LAN Connector ......................63 Figure 3-32: Ethernet and USB 2.0 Connector ................63 Figure 3-33: HDMI Connector ......................64 Figure 3-34: DP Connector ......................65...
  • Page 11 KINO-ADL-H610 Mini-ITX Motherboard List of Tables Table 1-1: KINO-ADL-H610 Specifications .................21 Table 2-1: Packing List .........................24 Table 2-2: Optional Items ......................26 Table 3-1: Peripheral Interface Connectors ................30 Table 3-2: External Peripheral Connectors ................30 Table 3-3: Audio Connector Pinouts ..................31 Table 3-4: Battery Connector Pinouts ..................33 Table 3-5: Buzzer Connector Pinouts ..................34...
  • Page 12 KINO-ADL-H610 Mini-ITX Motherboard Table 3-28: USB 3.2 Gen1 Port Pinouts ..................62 Table 3-29: LAN Port Pinouts ......................63 Table 3-30: USB 2.0 Port Pinouts ....................64 Table 3-31: HDMI Connector Pinouts ..................64 Table 3-32: DP Connector Pinouts ....................65 Table 3-33: RS-232/422/485 Connector Pinouts ................66 Table 4-1: AT/ATX Power Mode Switch Settings ...............79...

  • Page 13: Introduction

    KINO-ADL-H610 Mini-ITX Motherboard Chapter Introduction Page 13...

  • Page 14: Ntroduction

    Core™ i9/i7/i5/i3, Pentium® or Celeron® processor and supports two 260-pin 3200 MHz dual-channel DDR4 SDRAM unbuffered SO-DIMM supporting up to 64GB. The KINO-ADL-H610 provides two 2.5 GbE interfaces through the Intel® I225V PCIe 2.5 GbE controllers. The integrated Intel® H610/H610E chipset supports two SATA 6Gb/s drives, one M.2 (2242/2280) M key slot supporting PCIe x4 signal and one M.2 2230 A-key...

  • Page 15: Features

    KINO-ADL-H610 Mini-ITX Motherboard 1.2 Features Some of the KINO-ADL-H610 motherboard features are listed below:  Mini-ITX form factor  generation LGA1700 Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor supported  Intel® H610/H610E chipset  Two 260-pin 3200 MHz dual-channel unbuffered DDR4 SO-DIMMs supported (system max.

  • Page 16: Connectors

    KINO-ADL-H610 Mini-ITX Motherboard 1.3 Connectors The connectors on the KINO-ADL-H610 are shown in the figure below. Figure 1-2: Connectors Page 16...

  • Page 17: Dimensions

    KINO-ADL-H610 Mini-ITX Motherboard 1.4 Dimensions The main dimensions of the KINO-ADL-H610 are shown in the diagram below. Figure 1-3: KINO-ADL-H610 Dimensions (mm) Page 17...

  • Page 18: Data Flow

    KINO-ADL-H610 Mini-ITX Motherboard 1.5 Data Flow The following diagram shows the data flow between the system chipset, the CPU and other components installed on the motherboard. Figure 1-4: Data Flow Page 18...

  • Page 19: Technical Specifications

    KINO-ADL-H610 Mini-ITX Motherboard 1.6 Technical Specifications The KINO-ADL-H610 technical specifications are listed below. 747H Specification/Model KINO-ADL-H610 Form Factor Mini-ITX generation LGA1700 Intel® Core™ i9/i7/i5/i3, Pentium® or CPU Supported Celeron® CPU (up to 65 W) Intel® H610/H610E Two 260-pin 3200 MHz dual-channel unbuffered DDR4 SDRAM Memory SO-DIMMs supported (system max.
  • Page 20 KINO-ADL-H610 Mini-ITX Motherboard One 4-pin CPU smart fan and one 4-pin system smart fan connector One 10-pin header (power LED, HDD LED, speaker, power Front Panel button, reset button) One 4-pin wafer connector LAN LED Two 2-pin headers for LAN1 LED, LAN2 LED...

  • Page 21: Table 1-1: Kino-Adl-H610 Specifications

    KINO-ADL-H610 Mini-ITX Motherboard Weight (GW/NW) 900 g / 400 g Table 1-1: KINO-ADL-H610 Specifications Page 21...

  • Page 22: Packing List

    KINO-ADL-H610 Mini-ITX Motherboard Chapter Packing List Page 22...

  • Page 23: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the KINO-ADL-H610 is unpacked, please do the following:  Follow the anti-static guidelines above.

  • Page 24: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the KINO-ADL-H610 was purchased from or contact an IEI sales representative directly by sending an email to sales@ieiworld.com.

  • Page 25: Optional Items

    KINO-ADL-H610 Mini-ITX Motherboard 2.4 Optional Items The following are optional components which may be separately purchased: Item and Part Number Image Dual USB cable (wo bracket) (P/N: CB-USB02A-RS) RS-232 cable (P/N: 32205-002700-200-RS) SATA power cable (P/N: 32102-000100-200-RS) High-performance LGA1700 cooler kit (1U chassis...

  • Page 26: Table 2-2: Optional Items

    KINO-ADL-H610 Mini-ITX Motherboard Item and Part Number Image LGA1700 cooler kit (125W) (P/N: 19100-000328-00-RS) Table 2-2: Optional Items Page 26...

  • Page 27: Connectors

    KINO-ADL-H610 Mini-ITX Motherboard Chapter Connectors Page 27...

  • Page 28: Peripheral Interface Connectors

    KINO-ADL-H610 Mini-ITX Motherboard 3.1 Peripheral Interface Connectors This chapter details all the peripheral interface connectors. 3.1.1 KINO-ADL-H610 Layout The figure below shows all the peripheral interface connectors. Figure 3-1: Peripheral Interface Connectors (Front Side) Page 28...

  • Page 29: Peripheral Interface Connectors

    KINO-ADL-H610 Mini-ITX Motherboard 3.1.2 Peripheral Interface Connectors The table below lists all the connectors on the board. Connector Type Label Audio connector 10-pin header AUDIO1 RTC battery connector 2-pin wafer BAT1 Buzzer connector 2-pin wafer DDR4 SO-DIMM sockets 260-pin DDR4 SO-DIMM...

  • Page 30: External Interface Panel Connectors

    KINO-ADL-H610 Mini-ITX Motherboard Connector Type Label Flash descriptor security 2-pin header ME_FLASH1 override jumper USB 2.0 connectors 8-pin header USB1, USB2 Clear CMOS switch switch CMOS1 AT/ATX Power Mode switch switch J_AT_ATX1 Table 3-1: Peripheral Interface Connectors 3.1.3 External Interface Panel Connectors The table below lists the connectors on the external I/O panel.

  • Page 31: Internal Peripheral Connectors

    KINO-ADL-H610 Mini-ITX Motherboard 3.2 Internal Peripheral Connectors The section describes all of the connectors on the KINO-ADL-H610. 3.2.1 Audio Connector CN Label: J_AUDIO1 CN Type: 10-pin header, p=2.0 mm CN Location: See Figure 3-2 CN Pinouts: See Table 3-3 This connector connects to speakers, a microphone and an audio input.

  • Page 32: Rtc Battery Connector

    Dispose of used batteries according to instructions and local regulations. NOTE: It is recommended to attach the RTC battery onto the system chassis in which the KINO-ADL-H610 is installed. CN Label: BAT1 CN Type: 2-pin wafer, p=1.25 mm...

  • Page 33: Buzzer Connector

    Table 3-4: Battery Connector Pinouts 3.2.3 Buzzer Connector NOTE: If you cannot find a good place to put a buzzer on the KINO-ADL-H610, it is recommended to attach the buzzer onto the system chassis in which the KINO-ADL-H610 is installed.

  • Page 34: Figure 3-4: Buzzer Connector Location

    KINO-ADL-H610 Mini-ITX Motherboard The buzzer connector is connected to a buzzer. Figure 3-4: Buzzer Connector Location Description PC_BEEP_N Table 3-5: Buzzer Connector Pinouts Page 34...

  • Page 35: Ddr4 So-Dimm Sockets

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.4 DDR4 SO-DIMM Sockets CAUTION: For dual channel configuration, always install two identical memory modules that feature the same capacity, timings, voltage, number of ranks and the same brand. CN Label: DIMM1, DIMM2 CN Type: 260-pin DDR4 SO-DIMM socket...

  • Page 36: Digital I/O Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.5 Digital I/O Connector CN Label: CN Type: 14-pin header, p=2.00 mm CN Location: See Figure 3-6 CN Pinouts: See Table 3-6 The digital I/O connector provides programmable input and output for external devices. Figure 3-6: Digital I/O Connector Location...

  • Page 37: Fan Connector (Cpu)

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.6 Fan Connector (CPU) CN Label: CPU_FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location: See Figure 3-7 CN Pinouts: See Table 3-7 The fan connector attaches to a CPU cooling fan. Figure 3-7: CPU Fan Connector Location...

  • Page 38: Fan Connector (System)

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.7 Fan Connector (System) CN Label: SYS_FAN1 CN Type: 4-pin wafer, p=2.54 mm CN Location: See Figure 3-8 CN Pinouts: See Table 3-8 The fan connector attaches to a system cooling fan. Figure 3-8: System Fan Connector Location...

  • Page 39: Front Panel Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.8 Front Panel Connector CN Label: F_PANEL1 CN Type: 10-pin header, p=2.54 mm CN Location: See Figure 3-9 CN Pinouts: See Table 3-9 The front panel connector connects to the indicator LEDs and buttons on the computer's front panel.

  • Page 40: I 2 C Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.9 I C Connector CN Label: I2C1 CN Type: 4-pin wafer, p=1.25 mm CN Location: See Figure 3-10 CN Pinouts: See Table 3-10 The I C connector is used to connect I C-bus devices to the motherboard.

  • Page 41: Internal Power Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.10 Internal Power Connector CN Label: ATX1 CN Type: 20-pin Molex power connector, p=4.2 mm CN Location: See Figure 3-11 CN Pinouts: See Table 3-11 This connector provides power to the system. Figure 3-11: Internal Power Connector Pinout Location...

  • Page 42: Internal Power Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.11 Internal Power Connector CN Label: CPU12V1 CN Type: 8-pin Molex power connector, p=4.2 mm CN Location: See Figure 3-12 CN Pinouts: See Table 3-12 This connector provides power to the CPU. Figure 3-12: Internal Power Connector Pinout Location...

  • Page 43: Lan Led Connectors

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.12 LAN LED Connectors CN Label: JP2, JP3 CN Type: 2-pin header, p=2.0 mm CN Location: Figure 3-13 787H CN Pinouts: Table 3-13 788H The LAN LED connectors are used to connect to the LAN LED indicators on the chassis to indicate users the link activities of the three LAN ports.

  • Page 44: Slot, A-Key

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.13 M.2 Slot, A-key CN Label: M2_A1 CN Type: M.2 A-key slot CN Location: See Figure 3-14 CN Pinouts: See Table 3-14 The M.2 slot is keyed in the A position and accepts 2230 size of M.2 modules. The M.2 slot supports PCIe x1 and USB 2.0 signals.

  • Page 45: Table 3-14: M.2 A-Key Slot Pinouts

    KINO-ADL-H610 Mini-ITX Motherboard PCIE_TX_DP5 PCIE_TX_DN5 PCIE_RX_DP5 PCIE_RX_DN5 PCIE_CLK+ PCIE_CLK- PLT_RST SRCCLKREQB_15# BT_ON PCH_WAKE_N WLAN_OFF M2_DAT M2_CLK +3.3V +3.3V Table 3-14: M.2 A-Key Slot Pinouts Page 45...

  • Page 46: Slot, M-Key

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.14 M.2 Slot, M-key CN Label: NGFF1 CN Type: M.2 M-key slot CN Location: See Figure 3-15 CN Pinouts: See Table 3-15 88 H The M.2 slot is keyed in the M position and accepts 2242/2280 size of M.2 modules. The M.2 slot supports PCIe x4 signals.

  • Page 47: Table 3-15: M.2 M-Key Slot Pinouts

    KINO-ADL-H610 Mini-ITX Motherboard Description Description PCIE_3_RX_DP PCIE_3_TX_DN PCIE_3_TX_DP PCIE_2_RX_DN PCIE_2_RX_DP PCIE_2_TX_DN PCIE_2_TX_DP M_1_SSD_SLP M.2_SMCLK PCIE_1_RX_DN M.2_SMDAT PCIE_1_RX_DP PCIE_1_TX_DN PCIE_1_TX_DP1 PLT_RST_N SRCCLKREQB_13_N PCIE_CLK_DN13 PCIE_CLK_DP13 Module Key Module Key Module Key Module Key Module Key Module Key Module Key Module Key PEDET...

  • Page 48: Iei Idpm Slot

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.15 IEI iDPM slot CN Label: IDPM CN Type: iDPM slot CN Location: See Figure 3-16 CN Pinouts: See Table 3-16 The iDPM slot only use for IEI eDP/LVDS/VGA module Figure 3-16: IDPM Slot Location Description Description +3.3V...

  • Page 49: Table 3-16: Idpm Connector Pinouts

    KINO-ADL-H610 Mini-ITX Motherboard Description Description Module Key +3.3VS DISPLAY_DETECT_P +3.3VS IN21 DISPLAY_DETECT_P +3.3VS IN23 +3.3VS EDP_TX3_DN +12VS EDP_TX3_DP +12VS +12VS EDP_TX2_DN +12VS EDP_TX2_DP SMB_CLK EDP_TX1_DN SMB_DATA EDP_TX1_DP EC_BKLT_CTRL EDP_TX0_DN EDP1_BKLT_CTRL EDP_TX0_DP EDP1_BKLT_EN EDP1_VDD_EN # EDP_AUX_DN EDP_HPD_R EDP_AUX_DP BUF_PLT_RST# LVDS_EN +V5S...

  • Page 50: Pcie X16 Slot

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.16 PCIe x16 Slot CN Label: PCIE4 CN Type: PCIe x16 slot CN Location: See Figure 3-17 The PCIe x16 expansion card slot is for PCIe x16 expansion card. Figure 3-17: PCIe x16 Slot Location 3.2.17 RS-232 Serial Port Connector...

  • Page 51: Sata 6Gb/S Drive Connectors

    KINO-ADL-H610 Mini-ITX Motherboard Figure 3-18: RS-232 Serial Port Connector Location Description Description Table 3-17: RS-232 Serial Port Connector Pinouts 3.2.18 SATA 6Gb/s Drive Connectors CN Label: S_ATA1, S_ATA2 CN Type: 7-pin SATA drive connector CN Location: See Figure 3-19 CN Pinouts:...

  • Page 52: Figure 3-19: Sata 6Gb/S Drive Connector Locations

    KINO-ADL-H610 Mini-ITX Motherboard Figure 3-19: SATA 6Gb/s Drive Connector Locations Description Description SATA_RX ‐ SATA_TX+ SATA RX+ SATA_TX ‐ Table 3-18: SATA 6Gb/s Drive Connector Pinouts Page 52...

  • Page 53: Chassis Intrusion Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.19 Chassis Intrusion Connector CN Label: CHASSIS1 CN Type: 2-pin header, p=2.54 mm CN Location: See Figure 3-20 CN Pinouts: See Table 3-19 The CHASSIS1 (Chassis Intrusion Connector) Figure 3-20: Chassis Intrusion Connector Location Description CASEOPEN_N Table 3-19: Chassis Intrusion Pinouts...

  • Page 54: Spi Flash Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.20 SPI Flash Connector CN Label: JSPI1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-21 CN Pinouts: See Table 3-20 The SPI flash connector is used to flash the SPI ROM. Figure 3-21: SPI Flash Connector Location Description +3.3V...

  • Page 55: Spi Flash Connector, Ec

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.21 SPI Flash Connector, EC CN Label: EC_SPI1 CN Type: 8-pin wafer, p=1.25 mm CN Location: See Figure 3-22 CN Pinouts: See Table 3-21 The SPI flash connector is used to flash the EC ROM. Figure 3-22: SPI EC Flash Connector Location...

  • Page 56: Ec Debug Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.22 EC Debug Connector CN Label: DEBUG_SPI1 CN Type: 6-pin wafer, p=1.25 mm CN Location: See Figure 3-23 CN Pinouts: See Table 3-22 The EC Debug Connector is used to debug the EC. Figure 3-23: EC Debug Connector Location...

  • Page 57: Vr Power Ic Debug Connector

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.23 VR Power IC Debug Connector CN Label: CN Type: 5-pin header, p=2.54 mm CN Location: See Figure 3-24 CN Pinouts: See Table 3-23 The VR power IC debug connector is used to debug the VR power IC.

  • Page 58: Flash Descriptor Jumper

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.24 Flash Descriptor Jumper CN Label: ME_FLASH1 CN Type: 2-pin header, p=2.0 mm CN Location: See Figure 3-25 CN Pinouts: See Table 3-24 The Flash Descriptor Jumper is used to flash the security override jumper. Figure 3-25: Flash descriptor jumper Location...

  • Page 59: Usb 2.0 Connectors

    KINO-ADL-H610 Mini-ITX Motherboard 3.2.25 USB 2.0 Connectors CN Label: USB_CN4 CN Type: 8-pin header, p=2.00 mm CN Location: See Figure 3-26 CN Pinouts: See Table 3-25 The USB 2.0 connectors connect to USB 2.0/1.1 devices. Each pin header provides two USB 2.0 ports.

  • Page 60: External Peripheral Interface Connector Panel

    CN Location: See Figure 3-28 and Figure 3-29 CN Pinouts: See Table 3-26 and Table 3-27 Figure 3-28: USB 3.2 Gen2 and LAN Connector There are two external USB 3.2 Gen2 (10Gb/s) connectors on the KINO-ADL-H610. Description Description Page 60...

  • Page 61: Figure 3-29: Lan Connector

    KINO-ADL-H610 Mini-ITX Motherboard USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ Table 3-26: USB 3.2 Gen2 Port Pinouts Each LAN connector connects to a local network. DESCRIPTION DESCRIPTION LAN1_MD0+ LAN1_MD3+ LAN1_MD0- LAN1_MD3- LAN1_MD1+ LAN1_MD1-...

  • Page 62: Ethernet And Usb 3.2 Gen1 Connectors

    CN Location: See Figure 3-30 and Figure 3-31 CN Pinouts: See Table 3-28 and Table 3-29 Figure 3-30: USB 3.2 Gen1 and LAN Connector There are two external USB 3.2 Gen1 (5Gb/s) connectors on the KINO-ADL-H610. Description Description USB_DATA- USB_DATA-...

  • Page 63: Usb 2.0 Connectors

    CN Label: USB_CN3 CN Type: USB 2.0 combo CN Location: See Figure 3-32 CN Pinouts: See Table 3-30 There are two external USB 2.0 connectors on the KINO-ADL-H610. Figure 3-32: Ethernet and USB 2.0 Connector Description Description USB_DATA- USB_DATA- Page 63...

  • Page 64: Dp And Hdmi Connectors

    See Figure 3-33 and Figure 3-34 CN Pinouts: See Table 3-31 and Table 3-32 The KINO-ADL-H610 has one HDMI and one DP port. They can connect to HDMI and DP devices. The HDMI connector can connect to an HDMI device.

  • Page 65: Rs-232/422/485 Connectors

    KINO-ADL-H610 Mini-ITX Motherboard The DP connector connects to a display device with DisplayPort interface. Description Description LANE0P LANE3N LANE0N AUX_CTRL_DET_C LANE1P LANE1N AUXP LANE2P AUXN LANE2N LANE3P Table 3-32: DP Connector Pinouts Figure 3-34: DP Connector 3.3.5 RS-232/422/485 Connectors CN Label:...

  • Page 66: Figure 3-35: Serial Port Pinout Locations

    KINO-ADL-H610 Mini-ITX Motherboard RS-232 RS-422 RS-485 RXD422- Table 3-33: RS-232/422/485 Connector Pinouts Figure 3-35: Serial Port Pinout Locations Page 66...

  • Page 67: Installation

    KINO-ADL-H610 Mini-ITX Motherboard Chapter Installation Page 67...

  • Page 68: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the KINO-ADL-H610. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the KINO-ADL-H610 or any other electrical component is handled, the following anti-static precautions are strictly adhered to.
  • Page 69 Before and during the installation please DO the following:  Read the user manual: The user manual provides a complete description of the KINO-ADL-H610 installation instructions and configuration options.  Wear an electrostatic discharge cuff (ESD): Electronic components are easily damaged by ESD. Wearing an ESD cuff removes ESD from the body and helps prevent ESD damage.

  • Page 70: Socket Lga1700 Cpu Installation

    KINO-ADL-H610 Mini-ITX Motherboard 4.3 Socket LGA1700 CPU Installation WARNING: CPUs are expensive and sensitive components. When installing the CPU please be careful not to damage it in anyway. Make sure the CPU is installed properly and ensure the correct cooling kit is properly installed.

  • Page 71: Figure 4-2: Remove Protective Cover

    KINO-ADL-H610 Mini-ITX Motherboard Figure 4-2: Remove Protective Cover Step 3: Inspect the CPU socket. Make sure there are no bent pins and make sure the socket contacts are free of foreign material. If any debris is found, remove it with compressed air.

  • Page 72: Figure 4-3: Insert The Socket Lga1700 Cpu

    KINO-ADL-H610 Mini-ITX Motherboard Step 7: Insert the CPU. Gently insert the CPU into the socket. If the CPU pins are properly aligned, the CPU should slide into the CPU socket smoothly. See Figure 4-3. Figure 4-3: Insert the Socket LGA1700 CPU Step 8: Close the CPU socket.

  • Page 73: Figure 4-5: Engage The Load Lever

    KINO-ADL-H610 Mini-ITX Motherboard Figure 4-5: Engage The Load Lever Page 73...

  • Page 74: Socket Lga1700 Cooling Kit Installation

    KINO-ADL-H610 Mini-ITX Motherboard 4.4 Socket LGA1700 Cooling Kit Installation WARNING: DO NOT attempt to install a push-pin cooling fan. The pre-installed support bracket prevents the board from bending and is ONLY compatible with captive screw type cooling fans. The cooling kit can be bought from IEI. The cooling kit has a heat sink and fan.
  • Page 75 Do not overtighten the screws. Step 5: Connect the fan cable. Connect the cooling kit fan cable to the CPU fan connector on the KINO-ADL-H610. Carefully route the cable and avoid heat blades.Step 0: generating chips and fan...

  • Page 76: So-Dimm Installation

    KINO-ADL-H610 Mini-ITX Motherboard 4.5 SO-DIMM Installation CAUTION: For dual channel configuration, always install two identical memory modules that feature the same capacity, timings, voltage, number of ranks and the same brand. To install a SO-DIMM, please follow the steps below and refer to Figure 4-7.

  • Page 77: Module Installation

    KINO-ADL-H610 Mini-ITX Motherboard 4.6 M.2 Module Installation CAUTION: The standoff and screw pre-installed for the M.2 2242 module must be removed before installing an M.2 2280 module. Failing to do so may cause short circuit or other damges to the motherboard.

  • Page 78: Figure 4-9: Securing The M.2 Module

    KINO-ADL-H610 Mini-ITX Motherboard Step 4: Secure the M.2 module with an M2*3 retention screw (Figure 4-9). Figure 4-9: Securing the M.2 Module Page 78...

  • Page 79: System Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 4.7 System Configuration The system configuration should be performed before installation. 4.7.1 AT/ATX Power Mode Setting The AT and ATX power mode selection is made through the AT/ATX power mode switch which is shown in Figure 4-10.

  • Page 80: Clear Cmos Button

    KINO-ADL-H610 Mini-ITX Motherboard 4.7.2 Clear CMOS Button To reset the BIOS, remove the on-board battery and press the clear CMOS button for three seconds or more. The clear CMOS button location is shown in Figure 4-11. Figure 4-11: Clear CMOS Button Location...

  • Page 81: Internal Peripheral Device Connections

    This section outlines the installation of peripheral devices to the onboard connectors. 4.8.1 SATA Drive Connection The KINO-ADL-H610 is shipped with one SATA drive cable. To connect the SATA drives to the connectors, please follow the steps below. Step 1: Locate the connectors.

  • Page 82: Figure 4-13: Sata Power Drive Connection

    KINO-ADL-H610 Mini-ITX Motherboard Figure 4-13: SATA Power Drive Connection The SATA power cable can be bought from IEI. See Optional Items in Section 2.4. Page 82...

  • Page 83: Available Drivers

    KINO-ADL-H610 Mini-ITX Motherboard 4.9 Available Drivers All the drivers for the KINO-ADL-H610 are available on IEI Resource Download Center (https://download.ieiworld.com). Type KINO-ADL-H610 and press Enter to find all the relevant software, utilities, and documentation. Figure 4-14: IEI Resource Download Center...

  • Page 84: Driver Download

    4.9.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. Step 1: Go to https://download.ieiworld.com. Type KINO-ADL-H610 and press Enter. Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.
  • Page 85 KINO-ADL-H610 Mini-ITX Motherboard Step 3: Click the driver file name on the page and you will be prompted with the  following window. You can download the entire ISO file ( ), or double click an  individual item to find its driver file and click the file name to download (...

  • Page 86: Bios

    KINO-ADL-H610 Mini-ITX Motherboard Chapter BIOS Page 86...

  • Page 87: Introduction

    KINO-ADL-H610 Mini-ITX Motherboard 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice.

  • Page 88: Using Setup

    KINO-ADL-H610 Mini-ITX Motherboard 5.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen. 5.1.2.1 Keyboard Navigation For keyboard navigation, use the navigation keys shown in Table 5-1. Function Up arrow Move to previous item...

  • Page 89: Touch Navigation

    KINO-ADL-H610 Mini-ITX Motherboard 5.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Button Function Previous Values Load the last value you set. Optimized Defaults Load the factory default values in order to achieve the best performance.

  • Page 90: Getting Help

    KINO-ADL-H610 Mini-ITX Motherboard 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window, press the key. 5.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration is made, CMOS defaults.

  • Page 91: Main

    KINO-ADL-H610 Mini-ITX Motherboard 5.2 Main The Main BIOS menu appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS Menu 1: Main (1/3) Page 91...
  • Page 92 KINO-ADL-H610 Mini-ITX Motherboard BIOS Menu 2: Main (2/3) BIOS Menu 3: Main (3/3) Page 92...
  • Page 93 KINO-ADL-H610 Mini-ITX Motherboard  BIOS Information The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information cannot be changed. The items shown in the system overview include:  BIOS Vendor: Installed BIOS vendor  Core Version: Current BIOS version ...
  • Page 94 KINO-ADL-H610 Mini-ITX Motherboard  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 95: Advanced

    KINO-ADL-H610 Mini-ITX Motherboard 5.3 Advanced Use the Advanced menu (BIOS Menu 4) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware.

  • Page 96: Case Open Detection

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.1 Case Open Detection  Case Open Detection [Disabled] When the Case Open Detection is enabled, if anyone opens the computer's chassis, or case, Windows will notify the user with a pop-up message the next time he turns on his computer.
  • Page 97 KINO-ADL-H610 Mini-ITX Motherboard BIOS Menu 6: CPU Configuration (2/3) BIOS Menu 7: CPU Configuration (3/3) Page 97...
  • Page 98 KINO-ADL-H610 Mini-ITX Motherboard  Intel (VMX) Virtualization Technology [Enabled] Use the Intel (VMX) Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.
  • Page 99 KINO-ADL-H610 Mini-ITX Motherboard  Hyper-Threading [Enabled] Use the Hyper-Threading option to enable or disable the Hyper-Threading Technology.  Disabled Disables Hyper-Threading Technology  Enables Hyper-Threading Technology Enabled EFAULT  Intel(R) Trusted Execution Technology [Disabled] Use the Intel(R) Trusted Execution Technology option to enable or disable the utilization of additional hardware capabilities provided by Intel(R)Trusted Execution Techinology.
  • Page 100 KINO-ADL-H610 Mini-ITX Motherboard  Power Limit 1 Time Window [0] Use the Power Limit 1 Time Window option to select the PL1 time duration. The value may vary from 0 to 128. For 0 is the default value  Power Limit 2 [200000] Use the + or –...

  • Page 101: Trusted Computing

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.3 Trusted Computing Use the Trusted Computing menu (BIOS Menu 8) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS Menu 8: Trusted Computing Configuration Security Device Support [Enable]  Use the Security Device Support option to enable or disable BIOS support for security device.

  • Page 102: Rtc Wake Settings

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.4 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 9) configures RTC wake event. BIOS Menu 9: RTC Wake Settings (1/2) BIOS Menu 10: RTC Wake Settings (2/2) Page 102...
  • Page 103 KINO-ADL-H610 Mini-ITX Motherboard  Wake system with Fixed Time [Enabled] Use the Wake system with Fixed Time option to enable or disable the system wake on alarm event.  The real time clock (RTC) cannot generate a wake Disabled event ...

  • Page 104: F81966 Super Io Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.5 F81966 Super IO Configuration Use the F81966 Super IO Configuration menu (BIOS Menu 11) to set or change the configurations for serial ports. BIOS Menu 11: F81866 Super IO Configuration Page 104...

  • Page 105: Serial Port 1 Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.5.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 12) to configure the serial port. BIOS Menu 12: Serial Port 1 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 106: Serial Port 2 Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.5.2 Serial Port 2 Configuration Use the Serial Port 2 Configuration menu (BIOS Menu 13) to configure the serial port. BIOS Menu 13: Serial Port 2 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 107: Serial Port 3 Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.5.3 Serial Port 3 Configuration Use the Serial Port 3 Configuration menu (BIOS Menu 14) to configure the serial port. BIOS Menu 14: Serial Port 3 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 108: Serial Port 4 Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.5.4 Serial Port 4 Configuration Use the Serial Port 4 Configuration menu (BIOS Menu 15) to configure the serial port. BIOS Menu 15: Serial Port 4 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 109: Serial Port 5 Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.5.5 Serial Port 5 Configuration Use the Serial Port 5 Configuration menu (BIOS Menu 16) to configure the serial port. BIOS Menu 16: Serial Port 5 Configuration Menu  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.

  • Page 110: Serial Port 6 Configuration

    KINO-ADL-H610 Mini-ITX Motherboard  The serial port mode is RS-232 RS232 EFAULT RS422 with Register The serial port mode is RS-422 RS485 with Register The serial port mode is RS-485 5.3.5.6 Serial Port 6 Configuration Use the Serial Port 6 Configuration menu (BIOS Menu 17) to configure the serial port.

  • Page 111: Ec Kb9068 H/W Monitor

    KINO-ADL-H610 Mini-ITX Motherboard  Serial Port I/O port address is 2C0h and the interrupt IO=2C0h; IRQ=10 address is IRQ10  Device Mode [RS232] Use the Device Mode option to change the serial port mode.  RS232 The serial port mode is RS-232...
  • Page 112 KINO-ADL-H610 Mini-ITX Motherboard  PC Health Status The following system parameters and values are shown. The system parameters that are monitored are:  System Temperatures: CPU Temperature System Temperature1  Fan Speeds: CPU_Fan1 Speed SYS_Fan1 Speed  Voltages: +VCCCORE +5VS...

  • Page 113: Smart Fan Mode Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.6.1 Smart Fan Mode Configuration Use the Smart Fan Mode Configuration submenu (BIOS Menu 19) to configure the CPU/system fan start/off temperature and control mode. BIOS Menu 19: Smart Fan Mode Configuration  CPU_FAN Smart Fan Control [Auto Mode] Use the CPU_FAN Smart Fan Control option to configure the CPU Smart Fan.
  • Page 114 KINO-ADL-H610 Mini-ITX Motherboard  CPU_FAN Off Temperature If the CPU temperature is lower than the value set this option, the fan speed change to be lowest. To set a value, Use the + or – key to change the value or enter a decimal number between 1 and 100.

  • Page 115: Serial Port Console Redirection

    KINO-ADL-H610 Mini-ITX Motherboard  Auto mode fan slope PWM The PWM slope refers to the ratio relationship between the fan speed and the temperature. When the temperature rises or falls by 1° C, the fan speed increases or decreases accordingly. Changing the slope requires entering a number between 1 and 8.

  • Page 116: Console Redirection Settings

    KINO-ADL-H610 Mini-ITX Motherboard BIOS Menu 21: Serial Port Console Redirection (2/2)  Console Redirection [Disabled] Use Console Redirection option to enable or disable the console redirection function.  Disabled Disabled the console redirection function EFAULT  Enabled Enabled the console redirection function The Console Redirection Settings submenu will be available when the Console Redirection option is enabled.
  • Page 117 KINO-ADL-H610 Mini-ITX Motherboard BIOS Menu 22: COM Console Redirection Settings  Terminal Type [ANSI] Use the Terminal Type option to specify the remote terminal type.  VT100 The target terminal type is VT100  VT100+ The target terminal type is VT100+ ...
  • Page 118 KINO-ADL-H610 Mini-ITX Motherboard  Sets the serial port transmission speed at 57600. 57600  115200 Sets the serial port transmission speed at 115200. EFAULT  Data Bits [8] Use the Data Bits option to specify the number of data bits.

  • Page 119: Nvme Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.3.8 NVMe Configuration Use the NVMe Configuration (BIOS Menu 23) menu to display the NVMe controller and device information. BIOS Menu 23: NVMe Configuration Page 119...

  • Page 120: Chipset

    KINO-ADL-H610 Mini-ITX Motherboard 5.4 Chipset Use the Chipset menu (BIOS Menu 24) to access the PCH IO and System Agent (SA) configuration menus. WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 121: System Agent (Sa) Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 25) to configure the System Agent (SA) parameters. BIOS Menu 25: System Agent (SA) Configuration VT-d [Enabled]  Use the VT-d option to enable or disable the VT-d capability.

  • Page 122: Memory Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.1.1 Memory Configuration Use the Memory Configuration submenu (BIOS Menu 26) to view memory information. BIOS Menu 26: Memory Configuration Page 122...

  • Page 123: Graphics Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.1.2 Graphics Configuration Use the Graphics Configuration (BIOS Menu 27) menu to configure the video device connected to the system. BIOS Menu 27: Graphics Configuration  Primary Display [Auto] Use the Primary Display option to select the primary graphics controller the system uses.
  • Page 124 KINO-ADL-H610 Mini-ITX Motherboard option should be set to Enabled and the above Primary Display option should be set to IGFX.  Auto Auto mode  Disabled Disables IGFX.  Enables IGFX. Enabled Default  DVMT Pre-Allocated [160M] Use the DVMT Pre-Allocated option to set the amount of system memory allocated to the integrated graphics processor when the system boots.

  • Page 125: Peg Port Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.1.3 PEG Port Configuration BIOS Menu 28: PEG Port Configuration  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to detect non-compliance PCIe device in PEG.  Disabled Do not detect non-compliance PCIe device in PEG EFAULT ...

  • Page 126: Pch-Io Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 29) to configure the PCH parameters. BIOS Menu 29: PCH-IO Configuration  Auto Power Button Function [Disabled (AT)] Use the Auto Power Button Function BIOS option to show the power mode state. Use the J_ATX_AT1 to switch the AT/ATX power mode.

  • Page 127: Pci Express Configuration

    KINO-ADL-H610 Mini-ITX Motherboard  Power saving function is enabled. It will reduce power Enabled consumption when the system is off.  USB Power SW1(LAN1/LAN2_USB1B) [+5VDUAL] Use the USB Power SW1 to enable or disable the USB Power. +5VDUAL means keep USB port’s power when S5.

  • Page 128: Pcie Root Port Setting

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.2.1.2 PCIe Root Port Setting Use the M2_M(x4), M2_A submenu (BIOS Menu 31) to configure the PCI Root Port Setting. BIOS Menu 31: PCIe Slot Configuration Submenu  PCIe Speed [Auto] Use the PCIe Speed option to specify the PCI Express port speed. Configuration options are listed below.
  • Page 129 KINO-ADL-H610 Mini-ITX Motherboard  Detect Non-Compliance Device [Disabled] Use the Detect Non-Compliance Device option to configure whether to detect if a non- compliance PCI Express device is connected to the PCI Express port.  Do not detect if a non-compliance PCI Express...

  • Page 130: Sata Configuration

    KINO-ADL-H610 Mini-ITX Motherboard 5.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 32) to change and/or set the configuration of the SATA devices installed in the system. BIOS Menu 32: SATA Configuration  SATA Mode Selection [AHCI] Use the SATA Mode Selection option to determine how the SATA devices operate.

  • Page 131: Hd Audio Configuration

    KINO-ADL-H610 Mini-ITX Motherboard  Designates the SATA port as hot-pluggable. Enabled 5.4.2.3 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 33) to configure the PCH Azalia settings. BIOS Menu 33: HD Audio Configuration HD Audio [Enabled] ...

  • Page 132: Security

    KINO-ADL-H610 Mini-ITX Motherboard 5.5 Security Use the Security menu (BIOS Menu 35) to set system and user passwords. BIOS Menu 34: Security (1/2) Page 132...
  • Page 133 KINO-ADL-H610 Mini-ITX Motherboard BIOS Menu 35: Security (2/2)  Administrator Password Use the Administrator Password to set or change an administrator password.  User Password Use the User Password to set or change a user password. Page 133...

  • Page 134: Boot

    KINO-ADL-H610 Mini-ITX Motherboard 5.6 Boot Use the Boot menu (BIOS Menu 36) to configure system boot options. BIOS Menu 36: Boot 5.6.1 Boot Configuration  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.

  • Page 135: Save & Exit

    KINO-ADL-H610 Mini-ITX Motherboard  Ignore all PXE Option ROMs Disabled EFAULT  Enabled Load PXE Option ROMs. 5.7 Save & Exit Use the Save & Exit menu (BIOS Menu 37) to load default BIOS values, optimal failsafe values and to save configuration changes.
  • Page 136 KINO-ADL-H610 Mini-ITX Motherboard  Restore Defaults Use the Restore Defaults option to load the optimal default values for each of the parameters on the Setup menus. F3 key can be used for this operation.  Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults.

  • Page 137: A Regulatory Compliance

    KINO-ADL-H610 Mini-ITX Motherboard Appendix Regulatory Compliance Page 137...
  • Page 138 KINO-ADL-H610 Mini-ITX Motherboard DECLARATION OF CONFORMITY This equipment has been tested and found to comply with specifications for CE marking. If the user modifies and/or installs other devices in the equipment, the CE conformity declaration may no longer apply. FCC WARNING This equipment complies with Part 15 of the FCC Rules.

  • Page 139: B Product Disposal

    KINO-ADL-H610 Mini-ITX Motherboard Appendix Product Disposal Page 139...
  • Page 140 KINO-ADL-H610 Mini-ITX Motherboard CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 141: Cbios Options

    KINO-ADL-H610 Mini-ITX Motherboard Appendix BIOS Options Page 141...
  • Page 142 KINO-ADL-H610 Mini-ITX Motherboard Below is a list of BIOS configuration options in the BIOS chapter.  BIOS Information .........................93  Processor Information ......................93  PCH Information ........................93  System Date [xx/xx/xx] ......................94  System Time [xx:xx:xx] .......................94  Case Open Detection [Disabled] ..................96 ...
  • Page 143 KINO-ADL-H610 Mini-ITX Motherboard  Device Mode [RS232] ......................111  PC Health Status ........................112  Tcc Activation Offset [0] ....................112  CPU_FAN Smart Fan Control [Auto Mode] ..............113  CPU_FAN Start Temperature ....................113  CPU_FAN Off Temperature ....................114  CPU_FAN Start PWM ......................114 ...
  • Page 144 KINO-ADL-H610 Mini-ITX Motherboard  Launch PXE OpROM [Disabled] ..................134  Save Changes and Reset ....................135  Discard Changes and Reset .....................135  Restore Defaults ........................136  Save as User Defaults .......................136  Restore User Defaults .......................136 Page 144...

  • Page 145: D Watchdog Timer

    KINO-ADL-H610 Mini-ITX Motherboard Appendix Watchdog Timer Page 145...
  • Page 146 KINO-ADL-H610 Mini-ITX Motherboard NOTE: The following discussion applies to DOS environment. Contact IEI support or visit the IEI website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash. This condition may have occurred by external EMIs or a software bug.
  • Page 147 KINO-ADL-H610 Mini-ITX Motherboard NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...

  • Page 148: E Error Beep Code

    KINO-ADL-H610 Mini-ITX Motherboard Appendix Error Beep Code Page 148...

  • Page 149: Pei Beep Codes

    KINO-ADL-H610 Mini-ITX Motherboard E.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed...

  • Page 150: F Hazardous Materials Disclosure

    KINO-ADL-H610 Mini-ITX Motherboard Appendix Hazardous Materials Disclosure Page 150...

  • Page 151: Rohs Ii Directive (2015/863/Eu)

    KINO-ADL-H610 Mini-ITX Motherboard F.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 152: China Rohs

    KINO-ADL-H610 Mini-ITX Motherboard F.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572- 2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 152...

Table of Contents
