Mini-ITX SBC with AMD® ASB1 (BGA) processors, VGA/HDMI/LVDS,
Quick Installation Guide
Package Contents
KINO-780EB package includes the following items:
1 x KINO-780EB Single Board Computer
1 x RS-232 cable with bracket
1 x KB/MS Y cable
2 x SATA with 5V power cable kits
1 x Audio cable
1 x I/O shielding
1 x Mini Jumper Pack
1 x Utility CD
1 x QIG(Quick Installation Guide)
PCIe GbE, USB2.0, SATAII
KINO-780EB
Version 1.0
Mar. 22, 2010
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Related Manuals for IEI Technology KINO-780EB
Summary of Contents for IEI Technology KINO-780EB
- Page 1 Quick Installation Guide Version 1.0 Mar. 22, 2010 Package Contents KINO-780EB package includes the following items: 1 x KINO-780EB Single Board Computer 1 x RS-232 cable with bracket 1 x KB/MS Y cable 2 x SATA with 5V power cable kits...
- Page 2 BIOS : AMI BIOS System Memory : Two 200-pin 667MHz Dual Channel DDR2 SDRAM SO-DIMM supported (system max. 4GB for KINO-780EB-L325-R10) One 200-pin 667MHz Single Channel DDR2 SDRAM SO-DIMM supported (system max. 2GB for KINO-780EB-210U-R10) Ethernet : One Realtek RTL8111CP GbE Controller(PCIe x1 Interface)
-
Page 3: Ordering Information
Humidity : Operation: 5% ~95% non-condensing Dimensions : 170mm x 170mm Weight : GW: 1000g / NW: 370 g Ordering Information KINO-780EB-L325-R10 : Mini-ITX SBC with AMD® Dual core L325 1.5GHz processors, VGA/HDMI/LVDS, PCIe GbE, USB2.0, SATAII KINO-780EB-210U-R10: Mini-ITX SBC with AMD® Single core 210U 1.5GHz processors, VGA/HDMI/LVDS, PCIe GbE, USB2.0, SATAII... - Page 4 Jumpers Setting LABEL FUNCTION J_CMOS1 Clear CMOS Setup AT/ATX Power Mode Setting LCD Back Light Voltage Level Selection LCD Voltage Selection UART _SEL1 COM2 RS232 or RS-422 or RS-485 Type Select LVDS1 Panel Resolution type select J_CMOS1: Clear CMOS Setup DESCRIPTION CLR_CMOS1 Short 1-2...
- Page 5 UART_SEL1: COM1 RS232 or RS-422 or RS-485 Type Select UART _SEL1 DESCRIPTION RS-232 (default) RS-422 RS-485 RS-485 with RTS Control 9-10 JP1: LVDS1 Panel Resolution type select Panel Resolution Default: Disable LVDS Open Open Open Open 640x480 18-bit Open Open Open Short 800X600 18-bit...
- Page 6 Table of Connectors LABEL FUNCTION VGA1 VGA 15-pin Female Connector USB1 External 2 Ports USB Connector LAN1 RJ-45 LAN Connector S_ATA1 S_ATA2 Serial ATA Connectors S_ATA3 S_ATA4 SATA_POWER1 Serial ATA Power Output Connectors SATA_POWER2 COM1 Internal Serial Port Connector (RS-232/422/485) COM2 Internal Serial Port Connector (RS-232) USB2...
- Page 7 VGA1: 15-pin Female Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GREEN BLUE CRT_PLUG# VCC (+5V) DDCDAT HSYNC VSYNC DDCCLK USB1: External 2 ports USB Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) VCC (+5V) DATA- DATA- DATA+ DATA+ LAN1: RJ-45 LAN Connector PIN NO.
- Page 8 COM1 : Internal Serial Port Connector (RS-232/422/485) PIN NO. DESCRIPTION PIN NO. DESCRIPTION DATA CARRIER DATA SET READY DETECT (DCD#) (DSR#) RECEIVE DATA REQUEST TO SEND (RXD) (RTS#) TRANSMIT DATA CLEAR TO SEND (TXD) (CTS#) DATA TERMINAL RING INDICATOR READY (DTR#) (RI#) TXD485+ TXD485#...
- Page 9 SPEAKOUT1 : External Audio Line-out Connector PIN NO. DESCRIPTION Line-Out SPDIF1 : SPDIF Connector PIN NO. DESCRIPTION SPDIF_OUT SPDIF_IN CPU_FAN1, SYS_FAN1 : Fan Connector PIN NO. DESCRIPTION +12V Rotation Signal BAT1: +3V Battery Connector PIN NO. DESCRIPTION BAT (+3.3V) TPM1: Trusted Platform Module connector PIN NO.
- Page 10 LVDS1: 24-bit dual-channel LVDS Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION A_Y0 A_Y0# A_Y1 A_Y1# A_Y2 A_Y2# A_CK A_CK# A_Y3 A_Y3# B_Y0 B_Y0# B_Y1 B_Y1# B_Y2 B_Y2# B_CK B_CK# B_Y3 B_Y3# VCC_LCD VCC_LCD VCC_LCD VCC_LCD INVERTER1: LVDS1 Panel Backlight +12V Power Source connector PIN NO.
- Page 11 JSPI1: Flash BIOS SPI ROM Connector PIN NO. DESCRIPTION DESCRIPTION SPI_VCC (+3.3V) SPI_CS#0 SPI_CLK SPI_SO0 SPI_SI DIO1 : Digital Input / Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC (+5V) Output 3 Output 2 Output 1 Output 0 Input 3 Input 2 Input 1 Input 0...
- Page 12 HDMI1: HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI_DATA2 HDMI_DATA2# HDMI_SCL HDMI_DATA1 HDMI_SDA HDMI_DATA1# HDMI_DATA0 HDMI_HPD HDMI_GND HDMI_DATA0# HDMI_GND HDMI_CLK HDMI_GND HDMI_GND HDMI_CLK# MINI-PCIE1: PCIe Mini Card Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_WAKE# +3.3V +1.5V CLKREQ# LFRAME# LAD3 CLK- LAD2...
- Page 13 CF1 : CF Card Slot (Optional) PIN NO. DESCRIPTION PIN NO. DESCRIPTION CE2# IOR# IOW# CSEL# RESET# WAIT# INPACK# REG# BVD2 BVD1 IR1: Infrared Interface connector DESCRIPTION IR-RX IR-TX...
-
Page 14: Board Layout: Jumper And Connector Locations
Board Layout: Jumper and Connector Locations...
