Mini-ITX Motherboard Supports LGA1700 12
i9/i7/i5/i3, Pentium® and Celeron® Processor, DDR4,
Triple Independent Display, Dual 2.5GbE LAN,
Quick Installation Guide
Package List
KINO-ADL-H610 package includes the following items:
1 x KINO-ADL-H610 single board computer
1 x SATA cable
1 x I/O shielding
1 x QIG
USB 3.2, SATA 6Gb/s, and RoHS
KINO-ADL-H610
Version 1.0
January 11, 2023
©2023 Copyright by IEI Integration Corp.
All rights reserved.
th
th
/13
Gen. Intel® Core™
Advertisement
Related Manuals for IEI Technology KINO-ADL-H610
Summary of Contents for IEI Technology KINO-ADL-H610
- Page 1 USB 3.2, SATA 6Gb/s, and RoHS KINO-ADL-H610 Quick Installation Guide Version 1.0 January 11, 2023 Package List KINO-ADL-H610 package includes the following items: 1 x KINO-ADL-H610 single board computer 1 x SATA cable 1 x I/O shielding ...
-
Page 2: Specifications
Specifications CPU: LGA1700 12 Generation Intel® Core™ i9/i7/i5/i3, Celeron® and Pentium® processors (up to 65W TDP) Chipset: Intel® H610/H610E Memory: Two 260-pin 3200 MHz dual-channel unbuffered DDR4 SDRAM SO-DIMM slots supporting up to 64 GB memory BIOS: AMI UEFI BIOS ... - Page 3 Front Panel: 1 x Front panel (2x5 pin, p=2.54; HDD LED, speaker, power button, reset button) LAN LED: 2 x LAN LED (1x2 pin, p=2.0) Expansions: 1 x PCIe Gen4 x16 slot* 1 x M.2 2242/2280 M key (PCIe Gen3 x4) 1 x M.2 2230 A key (PCIe Gen3 x1 &...
-
Page 4: Ordering Information
All the drivers and utility for the KINO- https://download.ieiworld.com ADL-H610 are available on IEI Resource Download Center. Type KINO-ADL-H610 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to... -
Page 5: Jumpers Setting And Connectors
Jumpers Setting and Connectors LABEL FUNCTION J_AT_ATX1 AT/ATX power mode setting J_CMOS1 Clear CMOS jumper ME_FLASH1 Flash descriptor security override jumper J_AUDIO1 Audio connector for IEI AC-KIT-888S kit ATX1 ATX power connector CPU12V1 ATX CPU 12V power connector BAT1 RTC battery connector Buzzer connector CHASSIS1 Chassis intrusion connector... - Page 6 External 2.5GbE RJ-45 and dual USB 3.2 LAN2_USB1 Gen 1 (5Gb/s) combo connector USB_CN3 External quad USB 2.0 connector J_AT_ATX1: AT/ATX Power Mode Setting PIN NO. DESCRIPTION Short A - B ATX Power Mode (default) Short B - C AT Power Mode J_CMOS1: Clear CMOS Button Status DESCRIPTION...
- Page 7 ATX1: ATX Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V -12V PS_ON Power good 5VSB +12V CPU12V1: ATX CPU 12V Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V BAT1: RTC Battery Connector PIN NO. DESCRIPTION PIN NO.
- Page 8 J2 : Digital Input/Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 5 Output 4 Output 3 Output 2 Output 1 Output 0 Input 5 Input 4 Input 3 Input 2 Input 1 Input 0 DEBUG_SPI1: EC Debug Connector PIN NO. DESCRIPTION PIN NO.
- Page 9 F_PANEL1: Front Panel Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION PWR_BTN_N EXRST_N SATA_LED# BEEP_PWR PC_BEEP_N I2C1: I C/SMBus Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_CLK SMB_DATA JP2: LAN1 Link LED Connector DESCRIPTION DESCRIPTION +3.3V LAN1_LED_LNK#_ACT JP3: LAN2 Link LED Connector DESCRIPTION DESCRIPTION +3.3V...
- Page 10 S_ATA1, S_ATA2: SATA 6Gb/s Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX‐ SATA_TX+ SATA RX+ SATA_TX‐ JSPI1: Flash SPI ROM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CLK SPI_CS# SPI_SI SPI_SO EC_SPI1: Flash EC ROM Connector PIN NO. DESCRIPTION PIN NO.
- Page 11 Module Key Module Key Module Key Module Key Module Key Module Key Module Key PCIE_TX_DP5 PCIE_TX_DN5 PCIE_RX_DP5 PCIE_RX_DN5 PCIE_CLK+ PCIE_CLK- PLT_RST SRCCLKREQB_15# BT_ON PCH_WAKE_N WLAN_OFF M2_DAT M2_CLK +3.3V +3.3V...
- Page 12 NGFF1: M.2 2242/2280 M Key Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V3P3S_SSD +V3P3S_SSD PCIE_4_RX_DN PCIE_4_RX_DP NGFF1_ACT_N PCIE_TX_DN4 +V3P3S_SSD PCIE_TX_DP4 +V3P3S_SSD +V3P3S_SSD PCIE_3_RX_DN +V3P3S_SSD PCIE_3_RX_DP PCIE_3_TX_DN PCIE_3_TX_DP PCIE_2_RX_DN PCIE_2_RX_DP PCIE_2_TX_DN PCIE_2_TX_DP M_1_SSD_SLP M.2_SMCLK PCIE_1_RX_DN M.2_SMDAT PCIE_1_RX_DP PCIE_1_TX_DN PCIE_1_TX_DP1 PLT_RST_N SRCCLKREQB_13_N PCIE_CLK_DN13 PCIE_CLK_DP13 Module Key...
- Page 13 Module Key Module Key PEDET +V3P3S_SSD +V3P3S_SSD +V3P3S_SSD COM56: External RS-232/422/485 Connectors RS-232 RS-422 RS-485 TXD422- TXD485- TXD422+ TXD485+ RXD422+ RXD422- HDMI_DP1 External DP Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LANE0P LANE3N LANE0N CONFIG_A_1 LANE1P CONFIG_A_2 AUXP LANE1N LANE2P AUXN LANE2N LANE3P...
- Page 14 External HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI_DATA2P HDMI_CLKN HDMI_DATA2N HDMI_DATA1P HDMI_CLK HDMI_DATA1N HDMI_SDA HDMI_DATA0P HDMI_DATA0N HDMI_HPD HDMI_CLKP LAN1_USB1 External Dual USB 3.2 Gen 2 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+...
- Page 15 LAN2_USB1 External Dual USB 3.2 Gen 1 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ 2.5GbE RJ-45 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN2_MD0+ LAN2_MD3+ LAN2_MD0- LAN2_MD3- LAN2_MD1+ LAN2_MD1-...
- Page 16 Board Layout: Jumper and Connector Locations (Unit: mm)
