Bose ControlSpace ESP-00 II Service Manual page 56

Reference
Designator
C100 10uF, 16V, 40C, 20%
C101 0.01uF, 0603, X7R, 50V, 55C, 10%
C102 0.01uF, 0603, X7R, 50V, 55C, 10%
C103 0.01uF, 0603, X7R, 50V, 55C, 10%
C104 0.01uF, 0603, X7R, 50V, 55C, 10%
C105 0.01uF, 0603, X7R, 50V, 55C, 10%
C106 0.01uF, 0603, X7R, 50V, 55C, 10%
C107 0.01uF, 0603, X7R, 50V, 55C, 10%
C108 0.01uF, 0603, X7R, 50V, 55C, 10%
C109 0.1uF, 0603, Y5V, 50V, -30C, 20%
C110 0.1uF, 0603, Y5V, 50V, -30C, 20%
C111 10uF, 16V, 40C, 20%
C112 0.1uF, 0603, Y5V, 50V, -30C, 20%
C113 0.1uF, 0603, Y5V, 50V, -30C, 20%
C114 10uF, 16V, 40C, 20%
C115 0.1uF, 0603, Y5V, 50V, -30C, 20%
C116 12pF, 0603, 50V, 55C, NPO, 5%
C117 12pF, 0603, 50V, 55C, NPO, 5%
C118 0.1uF, 0603, Y5V, 50V, -30C, 20%
C119 0.1uF, 0603, Y5V, 50V, -30C, 20%
C120 47uF, 16V, 40C, 20%
C121 0.1uF, 0603, Y5V, 50V, -30C, 20%
C122 0.1uF, 0603, Y5V, 50V, -30C, 20%
C123 0.1uF, 0603, Y5V, 50V, -30C, 20%
C124 0.1uF, 0603, Y5V, 50V, -30C, 20%
C125 0.1uF, 0603, Y5V, 50V, -30C, 20%
C126 0.1uF, 0603, Y5V, 50V, -30C, 20%
C127 0.1uF, 0603, Y5V, 50V, -30C, 20%
C128 0.1uF, 0603, Y5V, 50V, -30C, 20%
C129 0.1uF, 0603, Y5V, 50V, -30C, 20%
C130 0.1uF, 0603, Y5V, 50V, -30C, 20%
C131 47pF, 0603, 50V, 55C, NPO, 5%
C132 47pF, 0603, 50V, 55C, NPO, 5%
C403 1000pF, CER, Y5P, 2KV, 55C,
10%
ELECTRICAL PART LIST
General Input/Output (GIO) PCB Assembly
Capacitors
Description Vendor
NICHICON UZT1C100MCR1GB
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10B103KBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C100MCR1GB
Samsung CL10F104ZBNC
Samsung CL10C120JBNC
Samsung CL10C120JBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
NICHICON UZT1C470MCR1GB
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10F104ZBNC
Samsung CL10C470JBNC
Samsung CL10C470JBNC
Panasonic ECKD3D102KBP
56
Vendor Part Note
Number
