Bose ControlSpace ESP-00 II Service Manual page 54

Reference
Designator
Q450 PNP, 50V, 100Ma, SOT-23
Q451 PNP, 50V, 100Ma, SOT-23
Q452 PNP, 50V, 100Ma, SOT-23
Q453 PNP, 50V, 100Ma, SOT-23
Q454 PNP, 50V, 100Ma, SOT-23
Q455 PNP, 50V, 100Ma, SOT-23
Q456 PNP, 50V, 100Ma, SOT-23
Q457 PNP, 50V, 100Ma, SOT-23
Q458 NPN, 50V, 100mA, SOT-23
Reference
Designator
M100 SDRAM, TSOP-54
M101 DSP, QFP-208
M200 PROG GATE ARRAY, QFP-208
M201 OCTAL BUFFER DR, TSSOP20
M202 OCTAL BUFFER DR, TSSOP20
M300 MICROPROCESSOR, QFP-176
M301 SDRAM, TSOP-54
M302 FLASH MEMORY, TSOP-48
M400 HEX INVERTER, TSSOP-14
M401 ETHER LAN CONT, TQFP-100
M450 TRANSCEIVER, SOIC-16
M452 OCTAL BUFFER DR, TSSOP20
M453 VOLT DET, SOT-23-5
M454 VOLT DET, TSOP-5
M455 VOLT DET, SOT-23-5
M456 VOLT DET, SOT-23-5
M457 VOLT DET, Vd=3.0V
M458 VOLT DET, SOT-23-5
M460 REG, 3.3V, 1A, TO-252
M461 REG, SOT-223, TI
M462 REG, SOT-223, TI
M463 PWM SWITCHER
Reference
Designator
CN452 CONN, SMT, 1.0MM, 100 PIN
CN530 CONN, SMT, 100P
X200 50.000MHz, 100ppm, 50pF
X201 24.576MHz, 100ppm, 50pF
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Transistors
Description
Integrated Circuits
Description
Miscellaneous
Description
Vendor Vendor Part Number
KEC KRA102S
KEC KRA102S
KEC KRA102S
KEC KRA102S
KEC KRA102S
KEC KRA102S
KEC KRA102S
KEC KRA102S
KEC KRC102S
Vendor Vendor Part Number
ELPIDA EDS1216AATA-75
TI TMS320C6713BPYP
XILINX XC2S150E6PQ208C
ONSemi MC74VHC541DT
ONSemi MC74VHC541DT
Renases HD6417706F133
ELPIDA EDS1216AATA-75
SPANSION S29GL064M90TAIR
ONSEMI MC74VHC04DT
Cirrus CS8900A-CQ3
Harris/Intersil HIN202ECB
ONSemi MC74VHC541DT
SEIKO S-80947CNMC-G9H-T2
ONSEMI NCP303LSN11T1
SEIKO S-80917CNMC-G8M-T2
SEIKO S-80917CNMC-G8M-T2
SEIKO S-80930CNMC-G80-T2
SEIKO S-80940CNMC-G9A-T2
NEC UPC2933T
NEC LM317DCY
NEC LM317DCY
TI TPS54312PWP
Vendor Vendor Part Number
KEL 87BFN-100R
Molex 52584-1079
KDS DSO531SVL 50MHz
KDS DSO531SVL
24.576MHz
54
Note
Note
Note
