4X4 Series Ii Pcb Assembly (Optional On Esp-00 Ii) - Bose ControlSpace ESP-00 II Service Manual

Reference Description
Designator
Q402 DTC114EKA
Q403 2SC3326
Q404 2SC3326
Q405 2SC3326
Q406 2SC3326
Q407 DTC114EKA
Q408 DTA114EKA
Q409 DTC114EKA
Q700 DTC114EKA
Q701 DTC114EKA
Q702 DTC114EKA
Q703 DTC114EKA
Q704 DTC114EKA
Q705 DTC114EKA
Q706 DTC114EKA
Reference Description
Designator
M100 TC9164CFG
M101 NJM4580E
M102 NJM4580E
M103 NJM4580E
M104 NJM4580E
M200 TC9164CFG
M201 NJM4580E
M202 NJM4580E
M203 NJM4580E
M204 NJM4580E
M300 NJM4580E
M301 NJM4580E
M302 NJM4580E
M303 NJM4580E
M400 NJM4580E
M401 NJM4580E
M402 NJM4580E
M403 NJM4580E
M500 CS5361-KZ
M501 CS5361-KZ
M550 CS4392-KZ
M551 CS4392-KZ
M700 74VHC541
M701 74VHC541
M702 74AC273
M703 S-80947CNMC-G9H
M704 TA48033F
M705 TA7805F
M707 74AC273
ELECTRICAL PART LIST

4x4 Series II PCB Assembly (optional on ESP-00 II)

Transistors (continued)
Vendor Part Number
DTC114EKA
2SC3326
2SC3326
2SC3326
2SC3326
DTC114EKA
DTA114EKA
DTC114EKA
DTC114EKA
DTC114EKA
DTC114EKA
DTC114EKA
DTC114EKA
DTC114EKA
DTC114EKA
Integrated Circuits
Vendor Part Number
TC9164CFG
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
TC9164CFG
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
NJM4580ETE2(JRC)
CS5361-KZ
CS5361-KZ
CS4392-KZ
CS4392-KZ
TC74VHC541FT
TC74VHC541FT
TC74AC273FT
S-80947CNMC-G9H
uPC2933T
uPC2905AT
TC74AC273FT
43
Vendor Name
RHOM
TOSHIBA
TOSHIBA
TOSHIBA
TOSHIBA
RHOM
RHOM
RHOM
RHOM
RHOM
RHOM
RHOM
RHOM
RHOM
RHOM
Vendor Name
TOSHIBA
JRC
JRC
JRC
JRC
TOSHIBA
JRC
JRC
JRC
JRC
JRC
JRC
JRC
JRC
JRC
JRC
JRC
JRC
CIRRUS
CIRRUS
CIRRUS
CIRRUS
TOSHIBA
TOSHIBA
TOSHIBA
SEIKO
TOSHIBA
TOSHIBA
TOSHIBA
Note
Note
