Bose ControlSpace ESP-00 II Service Manual page 39

Reference Description
Designator
C428 2700pF
C429 1500pF
C430 4700pF
C431 4700pF
C432 47uF, 16V
C433 10uF, 16V, BP
C434 22pF
C435 22pF
C436 10uF, 16V, BP
C437 22pF
C438 22pF
C439 22pF
C440 22pF
C441 22pF
C442 22pF
C443 0.01uF
C444 0.01uF
C445 1500pF
C446 2700pF
C447 2700pF
C448 1500pF
C449 10uF, 16V
C450 10uF, 16V
C451 4700pF
C452 4700pF
C453 47uF, 16V
C454 47uF, 16V
C455 47uF, 16V
C500 47uF, 16V
C501 0.1uF
C502 10uF, 16V
C503 0.1uF
C504 47uF, 16V
C505 0.1uF
C506 560pF
C507 560pF
C508 10uF, 16V
C509 0.1uF
C510 10uF, 16V
C511 0.1uF
C512 0.1uF
C513 10uF, 16V
C514 0.1uF
C515 10uF, 16V
C516 560pF
C517 560pF
ELECTRICAL PART LIST
4x4 Series II PCB Assembly (optional on ESP-00 II)
Capacitors (continued)
Vendor Part Number
GRM188B11H272KA01D
P-GRM39B152K-50
GRM188B11H472KA01D
GRM188B11H472KA01D
MVK16VC47MF55
RVB16V100M-R
GRM39CH220J50PB
GRM39CH220J50PB
RVB16V100M-R
GRM39CH220J50PB
GRM39CH220J50PB
GRM39CH220J50PB
GRM39CH220J50PB
GRM39CH220J50PB
GRM39CH220J50PB
GRM39B103K50PT
GRM39B103K50PT
P-GRM39B152K-50
GRM188B11H272KA01D
GRM188B11H272KA01D
P-GRM39B152K-50
MVK16VC10MD55
MVK16VC10MD55
GRM188B11H472KA01D
GRM188B11H472KA01D
MVK16VC47MF55
MVK16VC47MF55
MVK16VC47MF55
MVK16VC47MF55
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
MVK16VC47MF55
GRM188F11E104ZA01D
GRM188B11H561KA01D
GRM188B11H561KA01D
MVK16VC10MD55
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188B11H561KA01D
GRM188B11H561KA01D
39
Vendor Name
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
ELNA
MURATA
MURATA
ELNA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
NICHIKEMI
MURATA
MURATA
NICHIKEMI
NICHIKEMI
NICHIKEMI
NICHIKEMI
MURATA
NICHIKEMI
MURATA
NICHIKEMI
MURATA
MURATA
MURATA
NICHIKEMI
MURATA
NICHIKEMI
MURATA
MURATA
NICHIKEMI
MURATA
NICHIKEMI
MURATA
MURATA
Note
