Bose ControlSpace ESP-00 II Service Manual page 32

Reference Description
Designator
R512 5.1 Ohm
R513 OPEN
R514 OPEN
R515 5.1 Ohm
R516 2.7k
R517 2.7k
R518 470 Ohm
R519 470 Ohm
R520 470 Ohm
R521 470 Ohm
R522 33 Ohm
R523 330 Ohm
R524 330 Ohm
R525 0 Ohm
R550 10k
R551 10k
R552 0 Ohm
R553 0 Ohm
R554 10k
R555 0 Ohm
R556 33 Ohm
R557 180 Ohm
R558 180 Ohm
R559 180 Ohm
R560 10k
R561 10k
R562 OPEN
R563 180 Ohm
R564 OPEN
R565 OPEN
R566 0 Ohm
R600 OPEN
R601 OPEN
R602 0 Ohm
R603 0 Ohm
R604 0 Ohm
R605 0 Ohm
R606 0 Ohm
R607 0 Ohm
R608 0 Ohm
R609 0 Ohm
R610 OPEN
R611 OPEN
R612 0 Ohm
R613 0 Ohm
R614 0 Ohm
ELECTRICAL PART LIST
4x4 Series II PCB Assembly (optional on ESP-00 II)
Resistors (continued)
Vendor Part Number
RK73H1JTD5.1RF
NOT USED
NOT USED
RK73H1JTD5.1RF
RK73H1JTD2.7KF
RK73H1JTD2.7KF
RK73H1JTD470RF
RK73H1JTD470RF
RK73H1JTD470RF
RK73H1JTD470RF
RK73H1JTD33RF
RK73H1JTD330RF
RK73H1JTD330RF
RK73Z1JTD 0RJ
RK73H1JTD10KF
RK73H1JTD10KF
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73H1JTD10KF
RK73Z1JTD 0RJ
RK73H1JTD33RF
RK73H1JTD180RF
RK73H1JTD180RF
RK73H1JTD180RF
RK73H1JTD10KF
RK73H1JTD10KF
NOT USED
RK73H1JTD180RF
NOT USED
NOT USED
RK73Z1JTD 0RJ
NOT USED
NOT USED
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
NOT USED
NOT USED
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
RK73Z1JTD 0RJ
32
Vendor Name
KOA
NOT USED
NOT USED
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
NOT USED
KOA
NOT USED
NOT USED
KOA
NOT USED
NOT USED
KOA
KOA
KOA
KOA
KOA
KOA
KOA
KOA
NOT USED
NOT USED
KOA
KOA
KOA
Note
