Available Accessories
Accessory Cards
®
The ControlSpace ESP-00 Series II processor has eight available audio expansion slots and
supports up to 64 audio channels (up to 32 analog audio channels). 8 control inputs and 8
control outputs are supplied with the ESP-00 II processor and can be doubled to 16 inputs and
16 outputs by installing an optional GPIO Expansion card into the open GPIO 2 slot. Four DSP
processors are employed and cannot be expanded further in this model.
8 available audio slots
Open card slots, ESP-00 II processor, cover removed
Note: No audio cards are pre-installed in the ESP-00 II processor so the unit can be custom-
configured to meet the needs of the appli-cation. Please order accessory cards as needed for
your application.
At time of print, the following expansion cards are available. For further information on these
cards, and to view new cards that are available, please visit pro.Bose.com where an online
interactive configurator tool provides technical details, assistance in populating expansion cards,
and additional information about user controls.
• Dante™ network card (PC 359843-0020)
®
• CobraNet I/O expansion card (PC 311506)
• ESPLink 8-Channel output card (PC 350513-0010)
• 4x4 mic/line input/output card series II (PC 041915)
• SDR 4-Ch mic/line input card (PC 041917)
• SDR 4-Ch line output card (PC 041916)
• EDR line-level input card (PC 041764)
• EDR line-level output card (PC 041763)
• AES3 eight-channel input card (PC 041765)
• AES3 eight-channel line output card (PC 041766)
• Surround sound decoder input card (PC 302210)
• GPIO Expansion card (PC 041768)
PRODUCT DESCRIPTION
Factory-installed DSP/Network/RS-232
and GPIO card
1 available GPIO slot
