Bose ControlSpace ESP-00 II Service Manual page 21

Reference Description
Designator
C147 12pF
C148 12pF
C149 12pF
C150 47pF
C151 47pF
C152 47pF
C153 47pF
C154 47pF
C155 47pF
C156 47pF
C157 47pF
C158 47pF
C159 47pF
C160 47pF
C161 47pF
C162 47pF
C163 47pF
C164 47pF
C165 47pF
C200 47uF, 16V
C201 0.1uF
C202 0.1uF
C203 47uF, 16V
C204 0.1uF
C205 0.1uF
C206 0.1uF
C207 47uF, 16V
C208 10uF, 16V
C209 0.1uF
C210 0.1uF
C211 10uF, 16V
C212 0.1uF
C213 0.1uF
C214 0.1uF
C215 0.1uF
C216 0.1uF
C217 47pF
C218 47pF
C220 47uF, 16V
C221 47uF, 16V
C222 0.1uF
C223 0.1uF
C300 12pF
C301 12pF
C302 12pF
C303 47pF
ELECTRICAL PART LIST
ESP-00 II Motherboard PCB Assembly (Rev. B)
Capacitors (continued)
Vendor Part Number
GRM1882C1H120JA01D
GRM1882C1H120JA01D
GRM1882C1H120JA01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
MVK16VC47MF55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC47MF55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC47MF55
MVK16VC10MD55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
MVK16VC10MD55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM1882C1H470JZ01D
GRM1882C1H470JZ01D
MVK16VC47MF55
MVK16VC47MF55
GRM188F11E104ZA01D
GRM188F11E104ZA01D
GRM1882C1H120JA01D
GRM1882C1H120JA01D
GRM1882C1H120JA01D
GRM1882C1H470JZ01D
21
Vendor Name
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
MURATA
MURATA
NICHIKEMI
MURATA
MURATA
MURATA
NICHIKEMI
NICHIKEMI
MURATA
MURATA
NICHIKEMI
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
NICHIKEMI
NICHIKEMI
MURATA
MURATA
MURATA
MURATA
MURATA
MURATA
Note
