- Page 1 Bose ® Volume Control User Interface and Volume Control with A/B Select User Interface Installation Guide...
-
Page 2: Important Safety Instructions
Regional electrical codes may require similar qualifications for wiring the system. Please read this install guide The Bose Volume Control User Interface and Volume Control with A/B Select User Interface are engineered ® to provide custom on-site controls for the FreeSpace DXA 2120 digital mixer/amplifier. - Page 3 Provided in carton Volume control with A/B select user interface Volume control user interface ©2006 Bose Corporation. No part of this work may be reproduced, modified, distributed, or otherwise used without prior written permission.
-
Page 4: Also Needed
Not provided Double-gang junction box Cable* * For the volume control user interface, use a single twisted pair of data-grade cable (22-24 AWG or 0.34-0.25mm * For the volume control with A/B select user interface, use two twisted pairs of data-grade... - Page 5 Assembly...
-
Page 6: Recommended Cable Lengths
Recommended cable lengths For one user interface 2000 ft (610 m) max. Chassis 22-24 AWG or 0.34-0.25mm For two user interfaces 2000 ft (610 m) max. Chassis 22-24 AWG or 0.34-0.25mm... - Page 7 Wiring CAUTION: Be sure to terminate cable at both ends. User interface connector 6-terminal input connector mounts to REMOTE jack on the chassis One volume control user interface Two volume control user interfaces...
- Page 8 Wiring User interface connector 6-terminal input connector mounts to REMOTE jack on the chassis One volume control with A/B select user interface Two volume control with A/B select user interfaces...
- Page 9 • Install the junction box recessed slightly or flush to the surface of the finished wall. CAUTION: Do not install a volume control user interface or volume control with A/B select user interface in a junction box that houses an AC power (mains) cord.
- Page 10 Mounting After connecting the wires, mount the user interface in the junction box. Two sets of screws are provided. Use the screws that are appropriate for your junction box: Use #6 for North American boxes, or M4 for Japanese, European, and Australian boxes.
- Page 11 Dimensions ® Note: The Bose Volume Control User Interface is the same dimensions as the Volume Control with A/B Select User Interface shown above.
-
Page 12: Limited Warranty
We will repair or replace any defective parts within a reasonable period of time and free of charge. How you can obtain Limited Warranty service: 1. You can ship the system to either a Bose Service Agency or to Bose directly with a proof of purchase from an authorized dealer. Please: A. - Page 13 THIS LIMITED WARRANTY IS FULLY TRANSFERABLE PROVIDED THAT THE CURRENT OWNER FURNISHES THE ORIGINAL PROOF OF PURCHASE FROM AN AUTHORIZED BOSE DEALER. THE MAXIMUM LIABILITY OF BOSE SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT. SOME PLACES DO NOT ALLOW LIMITATIONS OR THE EXCLUSION OR LIMITATION OF RELIEF, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
- Page 16 ©2006 Bose Corporation, The Mountain Framingham, MA 01701-9168 USA AM300771 Rev.00...
