ANADOLU ISUZU Visigo E6 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER'S MANUAL
Revision No: 01
i
GENEL / PUBLIC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Visigo E6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ANADOLU ISUZU Visigo E6

Summary of Contents for ANADOLU ISUZU Visigo E6

  • Page 1 USER’S MANUAL Revision No: 01 GENEL / PUBLIC...
  • Page 2 The information, pictures and technical specifications here are based on the last product information available at the publication of the user’s manual and Anadolu Isuzu A.Ş. reserves the right to change without any prior notification.

  • Page 3: Table Of Contents

    TABLE O F CONTENTS PAGE INTRODUCTION Chassis Number Identification Plate Engine Number Vehicle Guarantee Options Recommendations / Warnings GENERAL INFORMATION Engine Start Engine Stop Opening and Closing Doors Emergency Exits Steering Wheel Adjustment CONTROLLERS AND INDICATOR Front Control Panel Side Control Panel Instrument and Warning Lights Panel VEHICLE EQUIPMENT Driver Seat...
  • Page 4 PAGE Transmission Retarder Fuel Tank Accumulators Tyre Inflation Set Heating and Cooling System Preheater Exhaust Emission System Regeneration Diesel Exhaust Emission Fluid Heating System Electronic Braking System (EBS) Advanced Emergency Braking System (AEBS) Engine Room Fire Detection System Engine Room Fire Extinguishing System (Optional) SERVICE and MAINTENANCE Cleaning The Vehicle Pulling The Vehicle...

  • Page 5: Introduction

    1. INTRODUCTION GENEL / PUBLIC...

  • Page 6: Chassis Number

    CHASSIS NUMBER Chassis number is located in the front part of the vehicle, as shown in the picture. IDENTIFICATION PLATE Identification plate is at the front door entry, at the step level on the side of hostess seat. There are VIN number, sum of maximum axle load, maximum front axle load, and maximum rear axle load on the identification plate.
  • Page 7 A detailed description of the composition of the VIN (SAMPLE) NNA: (AIOS) ANADOLU ISUZU OTOMOTIV SANAYI VE TICARET ANONIM 1 - 3 INTERNATIONAL WMI NO: SIRKETI MODEL LINE BUS GROUP 14 PASSENGER SEATS 17 PASSENGER SEATS 18 PASSENGER SEATS 19 PASSENGER SEATS...

  • Page 8: Engine Number

    ENGINE NUMBER Engine number is stated on two places : On engine introduction tag located on rocker cover On oil cooler body located on engine block VEHICLE GUARANTEE Vehicle’s warranty term and conditions are stated in the “Warranty Certificate” provided along with the vehicle.

  • Page 9: Recommendations / Warnings

    RECOMMENDATIONS / WARNINGS • For spare keys or lost keys, the serial number on keyswitch is required to notify Isuzu service, so please note the serial number. • Only use the fuel (DIN EN 590 compatible sulphur rate max 10 ppm) with the stated characteristics for your vehicle.
  • Page 10 • Start hazard flasher system and pull over to a safe place that will not prevent traffic if your vehicle malfunctions when driving. Place warning triangles to let other vehicles know about your presence. Let the other passengers get off and keep them waiting in a safe place. Inform the closest Isuzu service.

  • Page 11: General Information

    2. GENERAL INFORMATION...

  • Page 12: Engine Start

    ENGINE START Set the main switch “ON” and transmission “N”. Set keyswitch “M ", turn the keyswitch and press the starter ("D" position). • Do not run the starter for longer than 30 sec and do not step on the accelerator pedal when starting.
  • Page 13 Opening the Doors in Emergencies There are air cocks on the upper side of doors for emergencies. Turn the tap clockwise to discharge the air and push the door towards outside to open. There are also air cocks on sides of the doors to open the doors from outside when necessary.

  • Page 14: Emergency Exits

    EMERGENCY EXITS Emergency exit is enabled by breaking the window on the rear, right and left side of the vehicle and window on the trapdoor using the emergency hammer. Fold the rear seats before using rear window as an emergency exit. STEERING WHEEL ADJUSTMENT Steering wheel is adjustable upwards, downwards, frontwards and backwards according to the driver's...

  • Page 15: Controllers And Indicators

    3. CONTROLLERS AND INDICATORS...

  • Page 16: Front Control Panel

    FRONT CONTROL PANEL 1. Front door control switch 2. Back door control switch 3. Flasher switch 4. Suspension control switch 5. Multimedia set 1. Front Door Control Switch When pressed the lower edge of the switch, front door is opened/closed. The switch does not get activated when the vehicle speed exceeds 5 km.
  • Page 17 4. Suspension control switch This switch is used for a higher driving level than the normal one. When pressed the lower edge of the switch, the vehicle gets a higher level and if you press the higher edge of the switch, the vehicle gets the normal driving level.
  • Page 18 6. LCD screen switch LCD screen is turned on when pressed the lower edge of the switch. LCD screen is turned off when pressed the upper edge of the switch. 7. AEBS switch This switch is used to deactivate the AEBS system. When pressed the switch, warning letter “AEBS”...
  • Page 19 10. Reading lamp switch Switch works as two levels. It i s opened on the first level when pressed the lower edge and if reading lamp switch on the service set is turned on by the passenger, the lamp is on. It goes off if turned off. Reading lamps are turned on the second level when pressed the lower edge for the second time, it may not be controlled by the passenger.
  • Page 20 14. Sunroof switch It is used to open / close the sunroof. When pressed and released the lower edge of the switch, sunroof is opened automatically. If you press the switch once more to stop the movement when the desired level of space is reached. When pressed the switch once more to stop the movement when the desired level of closure is reached.
  • Page 21 The hand control does not automatically turn off at low speeds. Do not forget to reset the lever to Position 0 when the vehicle is stationary or when the retarder is no longer required. 17. Hillholder switch 18. Central lock key (optional) 19.
  • Page 22 19. Spot light switch Spot light on the upper driver’s compartment is turned on when pressed the lower edge of the switch. The light is turned off when pressed the upper edge of the switch. 20. Combi / Water Heater Switch It has two levels.
  • Page 23 24. Outside mirror resistance switch Outside mirror heater is activated when pressed the lower edge of the switch. It is deactivated when pressed for the second time. If the heater is not turned off by the driver, it is automatically deactivated after 20 minutes. 25.
  • Page 24 27. A/C control panel It is described in detail under the heating and cooling system. 28. Tachograph The tachograph records vehicle speeds, time, distance travelled and other information. It can be useful in achieving economic driving and optimum management of operations. 1 Driver 1 Activity button and ejection button 2 Card slot 1...
  • Page 25 29. Amplifier Amplifier enables one to turn the volume of speaker and microphone up/down. 30. Wiper lever The wiper lever has the following positions, which correspond to the states of the wiper. Lever position Intermittent Slow Fast Wiper state Stopped (Light rain) (Moderate rain) (Heavy rain)

  • Page 26: Side Control Panel

    SIDE CONTROL PANEL 1. Lighter 2. Cruise control on/off switch 3. Cruise control fixing and speed increasing switch 4. Driver window switch 5. Mirror control switch 6. Emergency switch 7. Handbrake 8. Glass holder 1. Lighter Lighter is pushed towards the heat element inside and it goes out automatically when heated.
  • Page 27 4. Driver window switch Driver window moves downwards when pressed the lower edge of the switch. It stops when pressed once. It moves upwards as long as pressed on the upper edge. 5. Mirror control switch This switch is used for the driver to adjust the directions of rear view mirror according to himself.

  • Page 28: Instrument And Warning Lights Panel

    INSTRUMENT AND WARNING LIGHTS PANEL Brake System Pressure Warning: Red and audio warning light is on when brake system pressure falls below 6 bars. Battery Warning: Red warning light is on when ignition switch is on and is off when engine is started and passes idle speed. It indicates a malfunction in charging system if it is on when driving.
  • Page 29 Driver Warning: Yellow warning light is on for the driver to identify the problems on NOx control system and their causes. Driver warning is on; If diesel exhaust emission fluid level is below warning level, If diesel exhaust emission fluid of incompatible quality is used, If diesel exhaust emission fluid of incompatible amount is used, When diesel exhaust emission fluid is sprayed in an intermittent way, When EGR valve or system sensors do not work compatibly.
  • Page 30 Exhaust System High Temperature Warning: When active regeneration starts in the vehicle or exhaust temperature exceeds a programmable limit, a yellow warning light is on. When exhaust temperature decreases to suitable temperatures, warning light goes off. There must not be any inflammable materials at the exit of exhaust pipe when warning light is on while the vehicle is parked.
  • Page 31 Engine Speed Indicator Engine speed indicator measures the engine speed per minute. It starts working when the engine is started. Speed (km/h) Indicator It shows the vehicle speed as km/h, it starts working after the vehicle has started. Fuel Indicator Fuel indicators show the fuel level in fuel tank.
  • Page 32 Information Screen TURBO BRAKE SW ITCH ACTIVE INSUFFICIENT RADIATORWATER MISSION INDICATOR TRANS PARK BRAKE PULLED TOTAL KM TEMPERATURE AND LEVEL ENGINEWATER TEMPERATURE HEAT DAILY KM HOUR Sub-menus may be displayed using the MODE and TRIP keys on the indicator. When MODE key is pressed; Driving info, Vehicle info, Alarms/warnings,...
  • Page 33 AL ARMS / WARNINGS Engine Error Codes Transmission Error Codes SETTINGS Date / Hour Language Screen Press MODE and TRIP keys at a time to go back to the main screen.

  • Page 34: Vehicle Equipment

    4.VEHICLE EQUIPMENT...

  • Page 35: Driver Seat

    DRIVER SEAT 1. Seat inclination adjustment : Button on the left is pulled upwards to adjust the inclination of the seat. The seat inclination is brought to the desired position by giving the weight frontwards or backwards. 2. Backrest inclination adjustment : It is adjusted by unlocking the backrest (lock lever is lifted up) and backrest is laid by pressing backwards.

  • Page 36: Passenger Seats

    PASSENGER SEATS Passenger seats are covered in cloth. Leather upholstery is offered as an option. There is 1 hostess seat at the front door entrance. Passenger seats may be laid backwards, seats by the aisle may spread to the side. The front right and left double seats and middle seat of the back five seats have 3 points seat belt while the other passenger seats have two points seat belt.

  • Page 37: Roller Blinds

    ROLLER BLINDS There are two electrical roller blinds on the front window. Blinds may be controlled through separate switches on the front control panel. There is also a roller blind opened and closed manually on the left of the driver. SUNROOF There is sunroof in the vehicle to make sure that inside of the vehicle is more illuminated and panoramic view chance is given to the passengers during journey.

  • Page 38: Water Heater Unit

    WATER HEATER UNIT There is 5 lt. capacity water heater unit at the front door entrance, it has got the power of 24V and 500 W. DIAGNOSTIC SOCKET Torpedo is in the cabinet on the right side. This socket is used to load and change parameters on engine control unit and fault diagnosis.

  • Page 39: Lcd Screen

    RIGHT OUTSIDE MIRROR LEFT OUTSIDEMIRROR LCD SCREEN There is 19” LCD screen under the passenger information panel. There is a magnetic protective frame which is easily demountable on the screen. Image(TV, film, music) may be transmitted to the screen from the multimedia set on the front control panel.

  • Page 40: Wc (Optional)

    WC (OPTIONAL) Functions Hand Wash Button : When this button is pushed water flows for a certain period of time from the faucet. After water flow stops, flow is provided by pushing this button again. Flush Button Pushing this button opens the flap, ensures the flow of water for a certain period of time, toilet content in toilet bowl is transfered to sewage tank.
  • Page 41 Spot Lamp There are two spot lamps to lighten the WC interior. The first lamp lights on when the WC is activated by driver. The second lamp lights on when a passenger is inside Fan Motor It is used to ventilete WC interior, activated when a passenger is inside, deactivated when the passenger leaves.
  • Page 42 Door Lock The door lock opens by turning the mechanism counter clock wise direction which is shown on the picture. The door lock has two keys. The door is lockable with keys. To lock the door from inside, the mechanism is turned counter clock wise direction which is shown on the picture.

  • Page 43: Trapdoor

    TRAPDOOR There is one manually opened and closed trapdoor in the middle of the vehicle. Trapdoor is designed in a way to allow use for emergency exit in addition to use for ventilation purposes. Exit is possible by breaking the glass with the emergency hammer in the cover.

  • Page 44: Outside Warning And Illumination Lamps

    There are 4 parking sensors mounted on the rear bumper. When the vehicle is reversed, sensors are activated. It gives audible warning to the driver according to the distance between the obstacle and bumper when maneuvering back. OUTSIDE WARNING AND ILLUMINATION LAMPS Number on the Lamps vehicle...
  • Page 45 Rear Lamp Group Side Signal Lamps There are total 2 side signal lamps on the right and left of the vehicle. Front and rear signal lamps work together. Sidemarkers and Positioning Lamps There are total 4 positioning lamps, 2 on the top front and 2 on the top back of the vehicle.

  • Page 46: Pedals

    PEDALS Brake Pedal Pedal on the left (hanging type) is the brake pedal, which is a part of electronic braking system (EBS). Electrical signal is sent to the central control unit and air is distributed to brake elements once the brake pedal is stepped on. Retarder activates automatically when the brake pedal is applied.

  • Page 47: Transmission

    TRANSMISSION The vehicle may be used both in automatic and manual modes. Transmission selector features are as follows: Shifting up Shifting up Transition to the manual mode from automatic mode Forward gear In neutral Reverse gear Shifting down — Shifting down Automatic Mode: This mode is indicated by the letter “A”...
  • Page 48 Transmission Use Automatic Mode: When the vehicle is at a still state, step on the service brake and bring the selector to “D” position. Clutch is automatically grabbed when stepped on the accelerator and the vehicle moves. Transmission shifts gears automatically during the journey. In any moment of journey, such as hard use conditions, it is possible to move the selector downwards and upwards only to manually shift gears or the selector is brought to the “A/M”...
  • Page 49 Indicator Warnings “CL” = Clutch overly loaded Stop the vehicle and shut off the engine. “CW ” = Clutch overly worn indicator Take the vehicle to a service. “EE” = Electronic system error It will not be possible to drive the vehicle. Call the service. “ES”...

  • Page 50: Retarder

    Kickdown (shifting down) Feature Kickdown feature allows shifting down when high engine power is needed. Step on the accelerator pedal until the kickdown passes the activation point. Use of kickdown feature increases fuel costs. RETARDER 1. Rear Axle 2. Retarder Your vehicle is equipped with a retarder.
  • Page 51 Your retarder will provide the necessary braking, whether at high road speeds or in dense traffic. Its efficient usage will reduce fuel consumption and permit higher average speeds in safety, whilst increasing brake and tyre service life. Use the retarder in conjunction with the engine braking for an optimum use of the gear ratios.

  • Page 52: Fuel Tank

    NOTE: If the vehicle’s ABS warning light remains on, the retarder will not operate. When the ABS warning light is on, there is a problem with the ABS. The ABS must be serviced before the retarder will operate. Important Points to Remember •...

  • Page 53: Accumulators

    Opening and Closing the Fuel Tank • Before opening the fuel tank filler cap, get rid of the static electricity on your body. • Open the cap and insert the key fully and turn it to the “OPEN” position. • Turn the cap counter clockwise in order to open it. •...

  • Page 54: Tyre Inflation Set

    TYRE INFLATION SET If the air pressure in vehicle tyres are low, tyre inflation set among the tools are used to adjust tyre pressures. In order to do that: • Park the vehicle in a way not to block the traffic. •...
  • Page 55 Rotary Sw itch K3 Driver side temperature adjustment is made. Button S1 Cooling of driver side is activated. Passenger side cooling must be active in order for this function to run. Button S2 Short Pressing Driver side fresh air choke flap is opened and closed. Double Click Closes driver and passenger fresh air valve for 10 minutes.
  • Page 56 Button S7 Passenger side fan speed is increased (7 grade). Button S8 Passenger side fan speed is decreased (7 grade). Button S9 It increases passenger side SET temperature. When 6x is pressed once maximum temperature value is reached, MAX HEATING becomes active. Button S10 It decreases passenger side SET temperature.
  • Page 57 SPECIAL FUNCTIONS Special functions are activated with the button combinations below. Smog Activation : When fresh air button is double clicked, driver and passenger fresh air valves get closed for 10 minutes. Mod Function : When AUTO button is double clicked, AUTO / HEAT / COOL / AUTO functions are selected. FUNCTION HEATING VENTILATION...
  • Page 58 Frontbox Temperature : Frontbox temperature is displayed on the screen when keys are pressed for 5 seconds. Keylock : Key lock is activated and “Loc” appears on the screen when keys are pressed for 10 seconds. Passenger side fan and temperature adjustment are locked with key lock. Time Setting : -Time setting can be adjusted when IGNITION is off.

  • Page 59: Preheater

    PREHEATER Preheater behind upper inspection hatch at the left rear section of the vehicle. Filter valve must be open when preheater is run. Filter must be cleaned through periodical maintenances. Preheater Starting Time Adjustment − Preheater start time adjustment is entered by pressing keys together.

  • Page 60: Exhaust Emission System

    EXHAUST EMISSION SYSTEM There is EGR (Exhaust Gas Treatment Unit) system in the vehicle for the engine to allow Euro 6 emission. EGR system allows NOx level to decrease by cooling burnt exhaust gases and sending them back to the system, consequently reducing combustion temperatures.

  • Page 61: Regeneration

    Diesel exhaust emission fluid is solution of urea at the rate of 32,5% in demineralized water. It is a fluid consumed to decrease the engine emission rates. Diesel exhaust emission fluid is sprayed into the exhaust gases by dosage pump. It gets into reaction with nitrogen-oxide gases formed when burning and discharged to make such gases pure nitrogen and water.

  • Page 62: Diesel Exhaust Emission Fluid Heating System

    DIESEL EXHAUST EMISSION FLUID HEATING SYSTEM Diesel exhaust emission f luid used in the vehicle starts to freeze at -11°C. Engine starts spraying urea to the exhaust system when the temperature rises. If the fluid in the tank has remained frozen when the engine heated, engine will have power turn-off because urea will not be sprayed.

  • Page 63: Advanced Emergency Braking System (Aebs)

    ESC (Electronic Stability Control) It is possible intervene wheel brakes independently sudden maneuverings in vehicles which carry load and passengers with electronic control. The purpose is to prevent possible accidents such as vehicle skidding or rolling over. So a more determined driving dynamic is guaranteed. Angular acceleration sensor Acceleration sensor is positioned on the floor casing in the trunk space close to the center of...
  • Page 64 If the AEBS is not deactivated in the following situations, the vehicle may self-brake and create a hazardous situation: - If the vehicle towed with the ignition switch on - When the vehicle is in a stable position, it moves to a mechanism where wheels rotate - If the wheels are turned by lifting the vehicle from front or rear axle to the air AEB function contains the sub-functions described in the following sections.
  • Page 65 AEBS Limitations The following limitations shows the different AEBS restrictions that can lead to an unexpected response and impaired system performance. • Sudden changes that correct a critical situation and that have already been recognized by the driver cause warnings that are perceived as unnecessary by the driver.

  • Page 66: Engine Room Fire Detection System

    EBA (Extended Brake Assistance) The extended braking aid reinforces the driver's manual brake request to avoid an oncoming collision at times of collision. In the event of an active collision warning, the EBA will send a request for the required deceleration to the brake system, depending on the current brake pedal position, to avoid an accident if the driver has started to depress the brake pedal slightly.
  • Page 67 Processes below must be applied when the fire extinguishing system becomes active for any reason other than fire and tanks get empty: • Wash all component surfaces with water to prevent from corrosion the parts in the engine room that system affects. •...

  • Page 68: Service And Maintenance

    5. SERVICE AND MAINTENANCE...

  • Page 69: Cleaning The Vehicle

    CLEANING THE VEHICLE Outside Cleaning • Do not clean your vehicle with detergent and chemical materials, do not wipe with gas. • Use pressurized water for vehicle cleaning (except for engine area), do not leave the extra water on the vehicle after cleaning, remove the extra water with a cloth or washleather. •...

  • Page 70: Engine Maintenance

    ENGINE MAINTENANCE It is possible to reach the vehicle engine from 4 parts. It is possible to reach the engine behind, sides and inside and under the vehicle. Rear cap It is possible to reach alternators, A/C compressor, V belts, circulation pump, fuel water seperator, hydraulic fan oil tank, oil level stick, steering wheel tank, hydraulic fan engine and pump, fire extinguishing tubes (optional), expansion tank by opening the rear cap.
  • Page 71 Left side front cap (1) It is possible to reach diesel exhaust emission fluid tank, dosage pump, accumulators, fuse box, dosage pump water valve by opening the left side front cap. Left side rear cap (2) It is possible to reach exhaust gas treatment unit, temperature and NOX sensor on exhaust gas treatment unit, urea injector by opening the left side rear cap.
  • Page 72 In order to start the engine: hand brake pulled, keyswitch on, gear shifted to "N” position and this button pressed. This button is pressed to stop the engine. This (green) button is pressed to illuminate the engine. When the rear cap is open, there is a safety switch to prevent starting the engine from the driver area.
  • Page 73 Exhaust Manifold Air Intake Alternator Starter Crankcase Oil filter Transmission Oil Filler Cap Turbo Unit...
  • Page 74 1. Tail Pipe 11. Circulation Pump 2. Exhaust Gas Processor Unit 12. Crankshaft Pulley 13. Hydrofan Engine 3. Expansion Tank 4. Water Filler Cap 14. Fan Propeller 5. Cooling Unit 15. A/C Compressor 6. Hydrofan Oil Reservoir 16. Air Filter 7.

  • Page 75: Engine Cooling System

    ENGINE COOLING SYSTEM Engine cooling system keeps the engine temperature in the suitable temperature range, which lets the engine run efficiently and prevents the engine parts from wearing by preserving the suitable oil viscosity. System also cools the transmission. It also covers the hot water need of cabin heater system and heats the diesel exhaust emission fluid tank in very low temperatures.

  • Page 76: Changing Engine Oil And Oil Filter

    12. Close the manual valves on the waterlines tied to cabin heater and A/C units (engine water inlet and outlet). 13. Restart the engine and run the engine at high idle speed until cooling water temperature has reached the thermostat opening temperature values. Radiator frille may be covered with a cloth (linoleum etc.) to reach the high temperature quicker.

  • Page 77: Changing Fuel Filter

    Use an engine oil compatible with the fluid specifications. Oil Level Control You may reach the oil level control stick by opening the rear engine cap. For oil level control: • Pull the oil level stick • Wipe with a clean cloth •...

  • Page 78: Control Of Brake Disc And Linings

    Fuel water separator is mounted on the body on the right side when rear cap is opened. Its function is to ensure that fuel is efficiently used by distilling the water in the fuel. Changing the Fuel Water Separator Filter : It is possible to reach the fuel water separator filter from vehicle’s rear cap.

  • Page 79: Differential Oil Change

    4. 9 lt must be added from the plug indicated with oil filling (2). 5. Plug must be tightened with 60 Nm once the oil has been completed. Oil Level Control • Position the vehicle on a flat ground. • Control the transmission oil level when it is cool (< 40 °C). •...
  • Page 80 A/C compressor belt is banded 17 V belt. Codes on the belt are indicated below. Contact Isuzu service to change the belt when it get damaged or severed. Compressor belt must stretched by tightening ring nuts on the indicated point (must be performed by Isuzu service) Also stretching system always stretches the belt actively with a...

  • Page 81: Steering Wheel Hydraulic Tank

    STEERING WHEEL HYDRAULIC TANK It is located on the right side of engine when the engine rear inspection hatch is opened. There is a screwed cap and oil level control stick on the tank. Oil level control must be performed once in every 3000 km. Level stick of tank is dismounted for oil level control, there is minimum and maximum line on the stick, oil level must be between these two lines.

  • Page 82: Air Filter

    AIR FILTER It is possible to reach air filter by opening the rear left side filter cap. In order to clean the air filter, rubber dust valve in the bottom part is tightened from the edges to empty the accumulated dust. Air filter element Air filter element change must be made in every 30000 km.

  • Page 83: Draining Water In Air Tanks

    DRAINING WATER IN AIR TANKS There are 2 air tank drain valves (one of them is under the air tank) under front stair and 2 air tank drain valves in the lower part, at front region of right rear wheel. Drain water in air tanks daily, by pressing on the valves.

  • Page 84: Fuses / Relays

    For complete change of outside wiper arm, plastic cap at the point where it is connected to the vehicle body is open, ring nut here is dismounted to remove the wiper arm (Image 3). When removing the wiper arm, sprinkler hose connected to the arm must be pulled and removed from the point where it is connected to the vehicle body.
  • Page 85 Changing parking bulb • Open the front bonnet. • Pull the socket which has a bulb on the edge and is located under the light unit. • Change with an equivalent bulb. • Mount the socket back. Changing Half Signal Lamps •...
  • Page 86 Changing Roof Illumination Fluorescent Lamps Roof illumination is ensured through fluorescent in the aluminum by the aisle side of air channel. To change fluorescent lamps, remove the polycarbonate lens on the aluminum body and replace the fluorescent. Changing the Rear Reflector •...

  • Page 87: Using Jack And Changing Tyres

    USING JACK AND CHANGING TYRES Jack points of the vehicle are located behind the front and rear wheels on the body. Using jack • Make sure relief screw is tight • Use its own jack lever to lift the jack •...

  • Page 88: Periodical Maintenance

    NOTE : If tyre pressure is continuously decreasing, there may be an object sticking into the tyre. Check whether there is air leak from the wheel or valve. Wheel nut tightening sequence Wheel with 5 nuts Wheel with 6 nuts Front wheel nuts Rear wheel nuts Model or...
  • Page 89 • Check the outside illumination lamps operation compatible with safe driving • Check the air suction hoses, exhaust pipes, and belts • Check whether there is a hydraulic leakage in fan system • Discharge the water accumulated in fuel water seperator •...
  • Page 90 Maintenance Range ( * 1000 Diagnostic Control of Engine Faults Engine Oil (or 6 (or 6 (or 6 (or 6 (or 6 (or 6 months) months) months) months) months) months) Valve space (or 4 adjustment years) Oil filter (or 6 (or 6 (or 6 (or 6...
  • Page 91 Maintenance Range ( * 1000 km) Cleaning transmission ventilation valve Transmission oil leakage control Transmission connecting bolts torque control Front axle pins and bushes R 65000 km or 1 year Differential oil Rear axle and brake caliper connecting bolts Hydraulic steering wheel oil (or 2 years) Fluid leakage at...
  • Page 92 Maintenance Range ( * 1000 Cable terminations and tightening torques Function control of brake, signal, parking, fog and brake lamps Inside illumination control Windshield wiper and washing system function General control of fuse panel electric cable and sockets Gas, brake and clutch pedal control Accumulator connecting cables Accumulator electrolit...

  • Page 93: Technical Information

    TECHNICAL INFORMATION...
  • Page 94 Dimensions (mm) Maximum length 9560 Maximum width 2454 Maximum height 3368 (including A/C unit) Wheelbase 4660 Front overhang 1890 Rear overhang 3010 Front track width 2012 Rear track width 1751 Inner height max. 1950 Masses (kg) Gross vehicle mass 12700 9150 (including full tank full, driver and Empty mass assistant)
  • Page 95 8.1 Bar Pressure Maximum Closing Air Dryer 10.45 Bar Pressure Tyres Cold Inflation Pressure 7.75 bar / 112 psi VISIGO E6 FLUID SPECIFICATIONS DEFINITION CAPACIT Y NORM CLASS Engine Oil 27 lt SAE 15W 40 CES-20086, API CK-4 or CES-20081, ACEA E-9...

  • Page 96: List Of Foreign Distributors
