Management LED

The Management LED shows the status of the retries mechanism:
Action
Zero Touch is running.
Successfully connected to Zero Touch Cloud Server and saved the
deployment script.
Zero Touch process is completed. SMP activation is not needed.
Activation sleeping time.
Reactivation.
SMP is connected.
SMP mode is off.
Gateway failed to connect to the SMP and will exit from the retry
script.
Wait times before retry:
Failure Waiting Time
1st 2 minutes
2nd 4 minutes
3rd 8 minutes
4th 16 minutes
Subsequent Retries every 16 minutes until Cloud Services are successfully activated.
Quantum Spark 1900 / 2000 Appliance Getting Started Guide | 45
Front Panel
Management LED
Activity
Blinks red (slowly)
Blinks red (rapidly)
Off
Blinks blue (slowly)
Blinks blue (rapidly)
Solid blue
Off
Solid red
