Key Item
5 SD card
slot
6 WAN and
WAN-B
ports
7 EXT port
8 USB3.0
9 Factory
Default
10 Service tag
11 Side
brackets

Management LED

The Management LED shows the status of the retries mechanism:
Action
Zero Touch is running.
Successfully connected to Zero Touch Cloud Server and saved the
deployment script.
Zero Touch process is completed. SMP activation is not needed.
Activation sleeping time.
Reactivation.
SMP is connected.
SMP mode is off.
Gateway failed to connect to the SMP and will exit from the retry script.
Description
Insert micro-SD card here.
Two WAN ports each of which is a combo port of SFP and RJ45 (on the right).
Only one can operate a time once plugged in and connected.
RJ45 - supports 10/100/1000MbE.
SFP - supports 1000MbE.
Management port - supports 10/100/1000MbE.
USB port 3.0 for software download.
Press the button continuously for 12 seconds to restore the appliance to its
factory default.
All user parameters previously configured are removed.
Shows the regulated module, serial number, and the MAC address.
For rack mount.
Quantum Spark 1600 / 1800 Appliance R80.20.XX Getting Started Guide | 16
Appliance Diagrams and Specifications
Management LED
Activity
Blinks red (slowly)
Blinks red (rapidly)
LED off
Blinks blue (slowly)
Blinks blue (rapidly)
Solid blue.
LED off
Constant red.
