Management Led - Check Point Quantum Spark 1570R Getting Starded Manual

Management LED
The Management LED shows the status of the retries mechanism:
Action
Zero Touch is running.
Successfully connected to Zero Touch Cloud Server and saved the
deployment script.
Zero Touch process is completed. SMP activation is not needed.
Activation sleeping time.
Reactivation.
SMP is connected.
SMP mode is off.
Gateway failed to connect to the SMP and will exit from the retry script.
Wait times before retry:
Failure Waiting Time
1st 2 minutes
2nd 4 minutes
3rd 8 minutes
4th 16 minutes
Subsequent Retries every 16 minutes until Cloud Services are successfully activated
Quantum Spark 1570R Appliance R80.20.XX Getting Started Guide | 29
Front Panel
Management LED
Activity
Blinks red (slowly)
Blinks red (rapidly)
LED off
Blinks blue (slowly)
Blinks blue (rapidly)
Solid blue.
LED off
Constant red.
