Optex Smart Line Series Installation Instructions page 3

Interruption time
Optical alignment
< Horizontal alignment angle > < Vertical alignment angle >
[ TOP VIEW ]
90°
90°
< Using a viewfinder >
Viewfinder
< How to look into the viewfinder >
From right side
Left eye Right eye
< LED and monitor jack >
Receiver
Alarm Indicator
Alarm
LED
Caution
Dip switch
(Receiver)
Typical
interruption
time setting
* For UL/ULC Installations the Setting of 50 msec shall be used.
< Using a beam blocking plate >
[ SIDE VIEW ]
10°
10°
10°
10°
< Using a voltmeter for fine alignment >
From left side
Light
interrupted
ON (Red)
Alarm indicator
LED
Adjustment
level
Monitor jack
0 V
output
Be sure to perform fine alignment to ensure the maximum output level through the monitor
jack.
ON ON
1 2 1 2
Running Jogging
(50 msec)* (100 msec)
Beam blocking
plate
Light received
OFF
Realign Fair Good
2.0 V 3.5 V 5.0 V
- 3 -
ON ON
1 2 1 2
Walking Slow movement
(250 msec) (500 msec)
Note >>
Beam blocking
plate
Cover
* Put it back after aligning for re-using.
Note >>
Turn the small dial for horizontal alignment.
Turn the large dial for
vertical alignment.
- Clockwise: Upward
- Counterclockwise: Downward
Note>>
Power indicator LED on the
transmitter is not turned off
when the cover is closed.
( i.e. The tamper button is
Excellent
depressed.)
< How to remove >*
