WASHING
MACHINE
WF101490C
User Manual
ENG
Product images are for illustrative purposes only and may differ from the actual product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF101490C and is the answer not in the manual?

Questions and answers

Related Manuals for Tesla WF101490C

Summary of Contents for Tesla WF101490C

  • Page 1 WASHING MACHINE WF101490C User Manual Product images are for illustrative purposes only and may differ from the actual product.

  • Page 2: Safety Instructions

    Safety instructions • Do not machine wash fiberglass materials (such as When properly cared for, your new appliance has curtains and windows coverings that use fiberglass been designed to be safe and reliable. Read and materials). Small particles may remain in the washer understand all safety instructions before using the and stick to fabrics in subsequent wash loads causing appliance.
  • Page 3 Safety instructions INSTALLATION • Due to the use of the condensation principle in drying, please keep the connected water tap open during the drying process. • The appliance must be handled and installed by • Make sure there is no water in the drum before two or more persons –...
  • Page 4 Safety instructions • The appliance must not be installed behind a • In order to ensure your safety, you must plug the lockable door, a sliding door or a door with a hinge cable into a socket which connected to earth. And on the opposite side to that of the appliance, in please check your socket to make sure that it is such way that a full opening of the appliance door is...
  • Page 5 Safety instructions SERVICE • Keep all laundry aids (including detergent, bleach, fabric softener, etc.) out of the reach of children. • Do not repair or replace any part of the appliance • To reduce the risk of poisoning or chemical burns, or attempt any service unless specifically stated in keep all cleaning products out of the reach of the user manual.

  • Page 6: Installation

    Installation WARNING • This user manual should be kept in a safe place for Packing materials can be dangerous to children. Keep future reference. If the washer is sold, transferred or all packing material (plastic bags, polystyrene. etc.) moved, make sure that the user manual remains with well out of children’s reach.
  • Page 7 Installation What’s included  Description of the parts  Accessories...

  • Page 8: Removing The Transport Bolts

    Installation NOTE Removing the transport bolts  Transport the washer for the prevention of breakage as below: CAUTION - The transport bolts are reinstalled. - The power cord is secured to the back of the DAMAGE TO THE APPLIANCE OR INJURY POSSIBLE washer.
  • Page 9 Installation CAUTION: Do not let metallic portions of the appliance come into contact with metal sinks or other appliances.

  • Page 10: Leveling The Appliance

    Installation Leveling the Appliance Procedure for adjusting the appliance feet: Importance of leveling the appliance 1. After determining which the appliance feet need The appliance uses high spin speeds to remove water to be extended, have someone lift up on the at the end of the wash cycle.
  • Page 11 Installation Connection the water supplies and • If the hose is not long enough, contact a specialized electricity shop or an authorized technician. • Never use second-hand water inlet hose. Connecting the water inlet hose • Use the new water inlet hose supplied with the 1.
  • Page 12 Installation ■ Sink siphon • We advise against the use of drain hose extensions; in case of absolute need, the extension must have the same diameter as the original hose and must not exceed 250cms in length. Secure the drain hose to the sink siphon using a Ǿ...

  • Page 13: Technical Date

    installation Electric connection • When the appliance is installed, the mains socket must be within easy reach. Before plugging the appliance into the mains socket, make sure that: • Do not use extension cables, multiple sockets or  The socket is earthed and in compliance with the adapters.

  • Page 14: Description Of The Appliance

    Description of the appliance Control panel ---SPA button: According to the needs, you can select A--- WASH CYCLE button area: Long press the one of four SPA washing functions through "POWER" button to start the machine, and then this button. select the required washing cycle in the WASH CYCLE For a detailed description, see→...
  • Page 15 Description of the appliance 5--SPA WASH TYPE indicator ---START/PAUSE button: Long press the button to start or pause a wash cycle. The SPA WASH TYPE symbol lit indicates the type of ● Add clothes during the program is running: SPA WASH has been selected. Once the cycle has begun, if you want to pause the wash cycle, please long press the button again.

  • Page 16: Preparing And Sorting The Laundry

    Preparing and sorting the laundry Preparing the laundry for drying Preparing the laundry  Only tumble-dry textiles which have been washed, rinsed and spun. Notice: Damage to the appliance/fabric  Remove as much water as possible from the Foreign objects (e.g. coins, paper-clips, needles, nails) laundry.
  • Page 17 Preparing and sorting the laundry Sorting the laundry according to jeans and other clothing worn for outside work colour and degree of soiling and activities. Sort laundry items according to color, degree of soiling and recommended wash temperature range.  Items of clothing can become discoloured. ...
  • Page 18 Preparing and sorting the laundry Sorting laundry according to their care label specifications The symbols on labels of your garments will help you in choosing the suitable wash program, the right temperature, wash cycles, and ironing methods. Don’t forget to give a glance to these useful indications!
  • Page 19 Various cycles and functions Table of wash cycle Max.Load(kg) Kind of detergent Temp. Wash cycle Specification Detergents Wash- Dry- Softe ℃ (Max) -ner Universal Special For washing lightly to normally soiled mixed load of cotton and L / P synthetic fabrics, white and colored items together For small amount or lightly soiled Quick...

  • Page 20: Drying Program

    Various cycles and functions Various cycles 2. Selection method of single drying program The single drying program is to run only the drying program without running the washing program. It is One Touch wash cycle suitable for drying cotton clothes. Do not dry clothes that are easily deformed or shrunk.

  • Page 21: Special Wash Cycles

    Various cycles and functions Ozone refresh Special wash cycles  The ozone refresh program can be selected at the Kids: a cycle designed for dirt typical of children’s same time as other selected programs. In the garments in that it effectively removes any traces of startup state, short press the ozone refresh button residual detergent.
  • Page 22 Various cycles and functions Drum Clean Plus (Drying Channel Cleaning x Drum Clean) • After the machine is started, briefly press " Drum Clean Plus" button to enter the "Drum Clean" program. • After the machine is powered and before startup, under any program, press and hold "...

  • Page 23: Various Functions

    Various cycles and functions off the machine by pressing the POWER button. When the machine is turned on again, the machine Various functions directly run the program before turning off the machine. Delay end SPA washing Press and hold STAINS button for 3 seconds before the program runs to set the "...

  • Page 24: Load Balancing System

    Various cycles and functions Downlight DIY time  Downlight is always on during program or function  Adjust the program time by pressing the DIY TIME setting. button. The program time adjustment value is  When the program is suspended, the downlight displayed on the digital display, and the appliance can be lit by opening the machine door.

  • Page 25: How To Use The Appliance

    How to use the appliance Before loading your first load of How to use the appliance laundry 1. Load laundry Open the door and load the laundry. Load the Your new appliance was tested before leaving the articles one at a time loosely into the drum, factory.
  • Page 26 How to use the appliance • When adding the softener, the maximum liquid • If the selected option is incompatible with the level of the softener shall not exceed the "Max" program set, the incompatibility will be signaled by a mark on the dispensing port.
  • Page 27 How to use the appliance Pause a running program and open the door, if needed Press START/PAUSE button to pause a running program. If the water level and/or temperature in the drum are/is not high, the DOOR LOCK indicator light turns off.

  • Page 28: Care And Maintenance

    Care and maintenance Cleaning the drum Your appliance is designed to give you years of service. Observe the following instructions to maintain and protect your appliance and keep it in Metallic debris left in the drum can product rust top operating condition. spots on the drum.
  • Page 29 Care and maintenance Tip: Do not operate the appliance without the Checking the water inlet hose detergent dispenser drawer in place. Always keep the detergent dispenser drawer completely closed. Check the water inlet hose at least once a year. If there are any cracks, it should be replaced Cleaning the mesh filter in the water inlet immediately, during the wash cycle, water pressure...
  • Page 30 Care and maintenance 4. Use the pull-out drain hose located in the pump Cleaning the drain pump access opening to drain the remaining water into a suitable container (up to 5.3U.S.gallon/20 liters of water may be drained). Pull the sealing cap WARNING from the hose and lay the hose over the side of RISK OF SCALDING...

  • Page 31: Troubleshooting

    Troubleshooting Your appliance could occasionally fail to work. Before contacting the service center, make sure that the problem cannot be solved easily using the following list. Problem Possible cause / solutions There are color spots and  The appliance requires a service wash. Run a “Drum Clean” wash cycle with oil stains in the drum no detergent and no laundry.
  • Page 32 Troubleshooting Problem Possible cause / solutions The water level is too low  This is not a fault. The water consumption in wash cycle of this appliance is relatively little, the water level in wash cycle is lower than other type when the machine is washing machine normally.
  • Page 33 Troubleshooting Problem Possible cause / solutions  The top of the drain hose is too low – It must be fitted at a height between The machine continuously 65 and 100 cm from the floor (see “Installation”).  The end of the drain hose has been pushed too far down the standpipe, fills with water and the hose elbow should be fitted 4’...
  • Page 34 Troubleshooting In case of the following faults, the fault state will be detected by the microcomputer system, with the buzzer sounds issued and the following fault codes display in the control panel: Fault codes Fault type Possible cause / solutions ...
  • Page 36 tesla.info...
