- Page 1 Operating and installation instructions Commercial tumble dryers PDR 914/918/922/928/944 To avoid the risk of accidents or damage to the en-GB machine, it is essential to read these instruc- tions before it is installed and used for the first time. M.-Nr. 11 840 480...
-
Page 2: Caring For The Environment
Caring for the environment Disposal of the packing material The packaging is designed to protect the appliance from damage dur- ing transportation. The packaging materials used are selected from materials which are environmentally friendly for disposal and should be recycled. Recycling the packaging reduces the use of raw materials in the man- ufacturing process and also reduces the amount of waste in landfill sites. -
Page 3: Table Of Contents
Contents Caring for the environment ......................Warning and Safety instructions ..................... Appropriate use ..........................Foreseeable misuse ........................Technical safety ..........................Gas-heated tumble dryers ...................... Correct use............................. Accessories ............................ 10 Description of the machine ....................... 11 Operating the tumble dryer ....................... 12 Control panel.......................... - Page 4 Contents Timer ............................... 25 Prerequisite for setting the timer ................... 25 Setting the timer........................25 Changing the programme sequence..................26 Changing a programme once it has started ................26 Cancelling the current programme ..................... 26 Reselecting a cancelled programme..................26 Time left ............................
- Page 5 Additional fan ..........................36 Pressure sensor ........................36 Peak load signal ........................36 Peak load prevention........................ 37 COM module selection ......................37 Availability of Miele digital products ..................37 WiFi / LAN ..........................37 Remote............................38 Remote update ......................... 38 Machine parameters........................38 Legal information ........................
-
Page 6: Warning And Safety Instructions
If using, do so at your own risk, and follow the instructions provided on the packaging. Any other applications may be dangerous. Miele cannot be held liable for dam- age resulting from incorrect or improper use or operation. -
Page 7: Foreseeable Misuse
Warning and Safety instructions Foreseeable misuse Do not make any alterations to the tumble dryer, unless authorised to do so by Miele. Do not lean on the tumble-dryer door. Otherwise, the tumble dryer may tip over, causing injury to yourself or others. - Page 8 Repairs should only be undertaken by a Miele authorised technician, otherwise any subsequent damage will not be covered by the warranty. Faulty components may only be replaced by genuine Miele spare parts. Miele can only guarantee the safety standards of the appliance when Miele replacement parts are used.
-
Page 9: Gas-Heated Tumble Dryers
Ensure that no closeable door, sliding door or an oppositely hinged door is installed that would hinder the drum door being opened in any way. If the mains connection cable is faulty it must always be replaced by a Miele authorised technician to protect the user from danger. -
Page 10: Accessories
Aggressive vapours containing chlorine can also be corrosive. Do not store containers of these agents near the tumble dryer. Accessories Accessory parts may only be fitted when expressly approved by Miele. If other parts are used, warranty, performance and product liability claims will be invalidated. -
Page 11: Description Of The Machine
Description of the machine ① ⑨ ⑥ ⑤ ⑩ ② ⑦ ③ ⑧ ④ Control panel with touch display Door Fluff filter flap 4 height-adjustable screw feet Electrical connection Communication module slot Intake vents for drying air Exhaust duct Connection for communication box Communication box (optional) For setting up a connection with external systems... -
Page 12: Operating The Tumble Dryer
Operating the tumble dryer Control panel sensor control For selecting the current user language At the end of the programme, the language is automatically reset to the language set at the supervisor level. sensor control Takes you back one level in the menu. Touch display / sensor control For starting the selected drying programme and cancelling a programme once it has star-... -
Page 13: Sensor Controls And Touch Display With Sensor Controls
Operating the tumble dryer Sensor controls and touch display with sensor controls The sensor controls , and Start/Stop and the sensor controls in the display re- spond to finger tip contact. Every touch of a sensor control is confirmed with an audible keypad tone. -
Page 14: Setting Numerical Values
Operating the tumble dryer The orange scroll bar in the bottom display area shows that there are further options to choose from. To select the required drying programme, touch the programme name with your finger. The display will now change to the standard menu for that programme. “Extras”... -
Page 15: Pull-Down Menu
Operating the tumble dryer Clock display 12:00 To enter the numerical value, touch the numbers on the right-hand side and then confirm with OK. Pull-down menu The pull-down menu can be used to display information (e.g. about a drying programme). ... -
Page 16: Initial Commissioning
Some settings can only be modified during the initial commissioning process. After that, they can only be changed by the Miele Customer Service Department. These settings are also described under “Supervisor level”. Switching on the tumble dryer Press the button. -
Page 17: Setting The Display Brightness
Initial commissioning Setting the display brightness You will be asked to select the brightness of the display. Display brightness Darker Brighter Touch the segment bar for the required level of brightness. The selected level of brightness is represented by the length of the segment bar. -
Page 18: Completing The Initial Commissioning Process
“Supervisor level” chapter. You can only make these settings during initial commissioning. If you wish to change the set- tings after the commissioning process, please contact the Miele Cus- tomer Service Department. If you do not wish to set up a payment device, you can skip this step. - Page 19 Initial commissioning Programmes 11:02 Cottons Cottons Woollens Cottons PRO Minimum iron Delicates Swipe to the left with your finger until the pro- Timed drying cool air gramme is displayed. Programmes 11:02 Timed drying Timed drying Woollens cool air hygiene Timed drying...
-
Page 20: Drying
Drying 1. Notes on correct laundry care Washing before Heavily soiled laundry must be washed particularly thoroughly. Use drying sufficient detergent and select a high wash temperature. If in doubt, wash the items several times. The tumble dryer must not be used for drying items of laundry which have been cleaned using industrial chemicals. -
Page 21: Loading The Tumble Dryer
Drying 2. Loading the tumble dryer Loading laundry Preventing damage to fabrics. into the tumble Before loading, read chapter “1. Notes on correct laundry care” first. dryer Open the door. Load laundry into the tumble dryer. Risk of damage with laundry getting trapped. Laundry can be damaged by getting trapped when closing the door. -
Page 22: Selecting Programme Settings
Drying Programmes 11:02 Cottons Cottons Woollens Cottons PRO Minimum iron Delicates With your finger, swipe to the left until you reach the required pro- gramme. Touch the sensor control for that programme. The display will change to the standard menu for that drying pro- gramme. - Page 23 Drying 11:02 Overview Weight Drying level Normal Cottons Drying temp. Extras 0:57 °C not selected Touch the sensor control. Extras Extras 11:02 Gentle tumble Anti-crease Touch the sensor control for the extra you want. ...
-
Page 24: Starting A Programme
Drying 5. Starting a programme Payment device If your machine is connected to a payment device, the amount of pay- (optional) ment required will appear in the display. Money may be lost if the drum door is opened or the programme is cancelled. -
Page 25: End Of The Programme
Drying When using the programmes for the first time, the displayed time sometimes deviates significantly from the real time left. The differ- ence between the estimated and achieved time becomes smaller if the corresponding programme is run more often. If different load sizes are dried in one programme, the time left display can only show an approximate time. -
Page 26: Changing The Programme Sequence
Changing the programme sequence Changing a programme once it has started You cannot change to another programme once a programme has started (this prevents unintentional alterations). You will need to can- cel the current programme before you can select a new one. ... -
Page 27: Supervisor Level
Be careful when entering a new code. You will need to inform Miele Service if you forget your new code. Miele Service will have to reset the code. Make a note of your new code and store it in a safe place. -
Page 28: Set Languages
Supervisor level Language setting The sensor control can be used to select a language. All languages are available (fact- ory default). You can change the order of the first 4 languages. These slots are allocated to the most commonly used languages. Standard language The user language cannot be changed. -
Page 29: Res. Moisture Display
Supervisor level Finish tone The finish tone signals the end of the drying programme. Keypad tone Welcome tone Fault alarm The fault tone signals a fault and can be switched off. The volume of the fault tone cannot be adjusted. Res. -
Page 30: Machine Off Status
Supervisor level Machine off status In order to save energy, the tumble dryer will switch off automatically after the end of the programme or if no further selection is made. You can change this setting. Changing this setting leads to increased energy consumption. - No switch off - Factory default: Switch off after 15 minutes - Switch off after 20 minutes... -
Page 31: Programme Packages
Supervisor level Caution: When activating any of these options, the Supervisor level will no longer be available. You will no longer be able to access the Supervisor level via the display. Please follow the instructions below if you wish to change any other settings. Opening the Supervisor level (launderette version) Switch the tumble dryer on and open the dryer door. -
Page 32: Favourite Programmes
Supervisor level Favourite programmes After switching on, you can also select a programme via: Favourites. 12 programmes can be stored as favourites based on your own priorities and require- ments. These favourites will also be made available in the control options - Launderette ext. -
Page 33: Sort Programmes
Supervisor level – Pause: 2–15 seconds – Drum reversal 20–600 seconds Anti-crease – Drum rotation, main direction 0–500 seconds – Pause 100–3000 seconds – Drum reversal 0–500 seconds Timed drying Running time 5–180 minutes (Process air): Temperature cold – 75 °C (Process air): Cooling down temperature 40–55 °C –... -
Page 34: Prog. Colour Allocation
Supervisor level Prog. colour allocation You can assign a specific colour to a favourite programme. In the list of favourites, each fa- vourite programme is given a coloured frame, which can be adjusted. - Factory default: Off - On Process technology Anti-crease At the end of the programme, the drum will continue to rotate at intervals if the laundry is not removed immediately. -
Page 35: Service
If the message appears on the display even though the fluff filter is clean, the vent ducting is regarded as borderline. Miele recommends improving the vent ducting. Poor vent duct- ing will result in longer programme running times and greater energy consumption. -
Page 36: External Applications
External applications External exhaust flap External hardware is connected via the Miele Connector Box. The time delay between the external exhaust air flap's activation point and the switch-on time for the drum/fan motor is regulated. -
Page 37: Peak Load Prevention
An XKM module is inserted into the module slot. Availability of Miele digital products The ability of Miele digital products depends on the availability of the services in your coun- try. The different services are not available in all countries. -
Page 38: Remote
If you do not install a RemoteUpdate, you can continue to use your tumble dryer in the usual way. However, Miele recommends installing RemoteUpdates. Miele’s RemoteUpdate function can only be used if the tumble dryer is connected to a WiFi/LAN network and you have an account in the Miele Professional app. The tumble dryer must be registered in the app. -
Page 39: Payment System
Supervisor level Payment system The Miele Connector Box accessory unit or the COM module is required to connect a pay- ment device. Setting for payment systems If you wish to change the settings after the commissioning process, please contact Miele Service. -
Page 40: Connectivity
Connectivity Pairing instructions Follow the steps below to connect the tumble dryer to your network. Opening the supervisor level Select the menu option in the appliance display. Supervisor Select the menu option. Access via code Enter the 3-digit supervisor code. ... -
Page 41: Technical Data
Connectivity Technical data System requirements for WiFi - WiFi 802.11b/g/n - 2.4 GHz band - WPA/WPA2 encryption - DHCP activated - Multicast DNS / Bonjour / IGMP snooping activated - Ports 443, 80, 53 and 5353 open - IP DNS server = IP standard gateway/router - Mesh/repeater use: same SSID and password as standard gateway/router - SSID must be permanently visible System requirements for LAN... -
Page 42: Problem Solving Guide
Problem solving guide Fault diagnosis Message Cause and remedy The display remains dark. There is no power to the tumble dryer. Check the mains plug, main switch and fuses (on site). Problem Cause and remedy The efficiency of the tumble The fluff filter in the tumble dryer is dirty. - Page 43 Problem solving guide Problem Cause and remedy When drying, open a door or window to ensure sufficient ventilation. The laundry has not been spun sufficiently. Make sure that your laundry is thoroughly spun at the ap- propriate spin speed in the washing machine. The tumble dryer has been overloaded.
-
Page 44: Cleaning And Maintenance
Cleaning and maintenance Cleaning the fluff filter Risk of fire if the tumble dryer is operated without a fluff filter. If there is no fluff filter, the air channels, heating elements and vent ducting can become clogged during drying and may catch fire. The fluff filter must not be removed for cleaning. -
Page 45: Additional Annual Cleaning
In the case of electrically heated tumble dryers, the heater bank and the heating shaft must also be checked by the Miele Customer Service Department. In the case of gas- heated dryers, the burner and the burner area must be checked. -
Page 46: Customer Service Department
Customer Service Department Contact in case of malfunction In the event of any faults which you cannot remedy yourself, please contact your Miele Dealer or Miele Service. Contact information for Miele Service can be found at the end of this document. -
Page 47: Installation
Incorrect installation of the tumble dryer can lead to personal injury or damage to property. The tumble dryer must only be installed and commissioned by Miele Customer Service Department or an authorised dealer. The tumble dryer must be installed in accordance with all relevant ... -
Page 48: Installing The Tumble Dryer
*INSTALLATION* Installation At the installation site, the tumble dryer must be lifted from the trans- port pallet using suitable lifting gear. Installing the tumble dryer Place the tumble dryer on a perfectly level, secure and horizontal surface that is able to withstand the specified floor load. The floor load created by the tumble dryer is concentrated and trans- ferred to the installation surface via the adjustable feet. -
Page 49: Securing The Machine
*INSTALLATION* Installation PDR 514/518/522/914/918/922 PDR 528/544/928/944 1400 mm 1640 mm 906 mm 1206 mm PDR 514/914: 852 mm PDR 528/928: 1018 mm PDR 518/918: 1035 mm PDR 544/944: 1384 mm PDR 522/922: 1164 mm To facilitate any future maintenance work, a maintenance corridor with a width of at least 500 mm must be set up behind the machine and must be accessible at all times. - Page 50 dryer can be converted for connection to the relevant input voltage. This conversion must be performed by the Miele Customer Service Department or by an authorised dealer. During the conversion, the wiring instructions given on the wiring diagram must be followed.
-
Page 51: Air Intake/Exhaust Air
If the gas type needs to be changed, please request the appropriate conversion kit from the Miele Customer Service Department. Inform- ation is required on the appliance type, serial number, gas family, gas group, gas connection pressure and country of installation. -
Page 52: Optional Accessories
In addition, it can display detailed machine and programme status information. This module forms the basis for wired communication with Miele MOVE. It is not possible to integrate the machine into the “Miele@home” app for domestic in- stallations. The communication module is intended exclusively for commercial use and is supplied with mains voltage directly via the Miele Professional machine. -
Page 53: Payment Systems
Payment systems This tumble dryer can be fitted with a payment system (optional Miele accessory). In this case, a Miele Customer Service technician must programme the relevant settings in the tumble dryer’s electronics and connect the payment system. -
Page 54: Technical Data
UK declaration of conformity UKCA mark (UK only) The Supply of Machinery (Safety) Regulations 2008 This Statement of Compliance confirms this Miele product fully complies with the Product Security and Telecommunications Infrastructure (Security Requirements for Relevant Connectable Products) Regulations 2023. - Page 56 Tel: (01) 461 07 10, Fax: (01) 461 07 97 E-Mail: info@miele.ae E-Mail: info@miele.ie, Internet: www.miele.ie Website: www.miele.ae Manufacturer: Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany Alteration rights reserved / Publication date: 18.24 M.-Nr. 11 840 480 / 01 ...
