DEMO MANUAL DC2015A
QUICK START PROCEDURE
50mV/DIV
2µs/DIV
Figure 4. Output Ripple at 48V
and 12A
(20MHz BW)
IN
OUT
5A/DIV
200mV/DIV
200µs/DIV
Figure 5. Load Transient Response Waveform at 48V
and 6A
to 12A
IN
OUT
OUT
dc2015af
4
