Linear Technology DC2015A Demo Manual page 6

DEMO MANUAL DC2015A
PARTS LIST
ITEM QUANTITY
REQUIRED CIRCUIT COMPONENTS
1 1
2 3
3 1
4 3
5 1
6 1
7 2
8 1
9 1
10 3
11 1
12 1
13 1
14 1
15 1
16 1
17 1
18 1
19 1
20 1
21 1
22 1
23 1
24 1
25 1
26 3
27 1
28 1
29 4 R7, R17, R34, R35
30 1
31 1
32 1
33 2
34 1
35 1
36 1
37 1
38 1
39 1
40 1
41 1
6
REFERENCE PART DESCRIPTION
C1 Cap., X7R 4700pF 250V 20% 1812
C2, C4, C23 Cap., X7S 4.7µF 100V 10% 1210
C3 Cap., Alum 10µF 100V 20%
C5, C6, C24 Cap., X5R 47µF 16V 20% 1210
C7 Cap., U2J 390pF 250V 5% 0805
C9 Cap., Alum 470µF 16V 20%
C10, C14 Cap., X7R 22nF 25V 10% 0603
C11 Cap., X7S 1µF 100V 10% 0805
C12 Cap., X7R 0.01µF 25V 10% 0603
C13, C17, C19 Cap., X5R 4.7µF 16V 20% 0805
C15 Cap., NPO 100pF 25V 5% 0603
C16 Cap., X7R 0.1µF 25V 10% 0603
C18 Cap., X7R 3.9nF 25V 20% 0603
C20 Cap., NPO 220pF 25V 5% 0603
C25 Cap., U2J 3.9nF 250V 5% 0805
C26 Cap., X5R 1µF 25V 20% 0603
D2 Diode, 1A/200V SOD-123
ISO1 Opto Iso., 2.5kV TRANS 4SOIC PbF
L1 Inductor, 8µH
L3 Inductor, 1µH
Q1 MOSFET N-Channel, 200V/36A SuperSO8
Q2 MOSFET, Single N-Chan. 100V/60A POWER-56
Q3 MOSFET N-Channel, 75V/100A SuperSO8
R1 Res., Chip 86.6k 0.10W 1% 0603
R3 Res., Chip 100k 0.10W 1% 0603
R4, R14, R36 Res., Chip 10k 0.10W 5% 0603
R5 Res., Chip 11.3k 0.10W 1% 0603
R6 Res., Chip 1.74k 0.10W 1% 0603
Res/Jumper, Chip 0Ω 0.25W 5A 0603
R8 Res., Chip 1.43k 0.10W 1% 0603
R10 Res., Chip 10.0Ω 0.10W 1% 0603
R11 Res., RL Vert. 0.010Ω 1W 1% 0815
R13, R38 Res., Chip 4.02k 0.10W 1% 0603
R16 Res., Chip 3.32k 0.10W 1% 0603
R18 Res., Chip 113k 0.10W 1% 0603
R19 Res., Chip 20.0k 0.10W 1% 0603
R23 Res/Jumper, Chip 0Ω 0.33W 6A
R26 Res., Chip 41.2k 0.10W 1% 0603
R27 Res., Chip 100k 0.10W 5% 0603
R28 Res., Chip 178Ω 0.10W 1% 0603
R29 Res., Chip 499k 0.10W 1% 0603
MANUFACTURER/PART #
Murata GA343DR7GD472KW01L
TDK C3225X7S2A475K
Sun Elect. Ind. Corp. 100HVH10M
Taiyo Yuden EMK325BJ476MM
Murata GRM21A7U2E391JW31D
Sun Elect. Ind. Corp. 16SVPE470M
AVX 06033C223KAT1A
TDK C2012X7S2A105K
AVX 06033C103KAT2A
TDK C2012X5R1C475M
AVX 06033A101JAT2A
AVX 06033C104KAT2A
AVX 06033C392MAT2A
AVX 06033A221JAT1A
Murata GRM21B7U2E392JW32L
AVX 06033D105MAT2A
Central Semi. CMMR1U-02
NEC PS2801C-1-P-A
Champs Tech. PQA2050-08-LTC
Coilcraft XAL6030-102MEC
Infineon BSC320N20NS3G
Fairchild Semi. FDMS86101
Infineon BSC042NE7NS3G
Vishay CRCW060386K6FKEA
Vishay CRCW0603100KFKEA
Vishay CRCW060310K0JNEA
Vishay CRCW060311K3FKEA
Vishay CRCW06031K74FKEA
Vishay CRCW06030000Z0EA
Vishay CRCW06031K43FKEA
Vishay CRCW060310R0FKEA
SSM Thin Film Tech. RL3720WT-R010-F
Vishay CRCW06034K02FKEA
Vishay CRCW06033K32FKEA
Vishay CRCW0603113KFKEA
Vishay CRCW060320K0FKEA
Vishay CRCW08050000ZOEA
Vishay CRCW060341K2FKEA
Vishay CRCW0603100KJNEA
Vishay CRCW0603178RFKEA
Vishay CRCW0603499KFKEA
