User Manual
Trio
Swine Controller
Ag/MIS/ImEN-2748-09/19 Rev 4.1
P/N: 116798
Trio
Controller

Advertisement

Table of Contents
loading

Related Manuals for Munters Trio

Summary of Contents for Munters Trio

  • Page 1 Trio Controller User Manual Trio Swine Controller Ag/MIS/ImEN-2748-09/19 Rev 4.1 P/N: 116798...
  • Page 2 Munters reserves the right to effect modifications to the apparatus in accordance with technical and legal developments.

  • Page 3: Table Of Contents

    Index Chapter page INTRODUCTION ........................Disclaimer......................... 7 Introduction ......................7 Notes ........................7 ..................USING THE TRIO TOUCH SCREEN Icons ........................8 Dashboard ....................... 9 ........................BASIC SETUP Defining the General Settings ................11 ................. 3.1.1 Defining the Preferences 3.1.2 Defining the Time/Date ...................
  • Page 4 Defining the Tunnel Ventilation Parameters 7.4.2 Defining the Tunnel Ventilation Settings ..........7.4.3 Tunnel Doors ................................. 7.4.4 Tunnel Ventilation Static Pressure Calibrating the Inlet/Tunnel Door ................ 61 Stir Fan ........................62 ...................... COOLING FUNCTIONS Cooling Principles ....................63 © Munters AB, 2020...
  • Page 5 15.1 Climate and Air Quality ..................90 15.2 Alarms and Events ....................91 15.3 Water and Feed History ..................92 15.4 Devices History ..................... 93 RESETTING, SAVING AND LOADING SETTINGS, UPDATING SOFTWARE ....16.1 Resetting the Settings..................95 © Munters AB, 2020...
  • Page 6 16.2 Resetting the Trio CPU and Sensor Connections ..........96 16.3 Saving or Loading the Settings ................97 16.4 Viewing the Log .....................97 16.5 Updating the Software ..................98 ................. APPENDIX A: CENTRAL EXHAUST 17.1 Introduction to Central Exhaust ................99 17.2 Selecting Central Exhaust ..................

  • Page 7: Introduction

    Munters Controllers. 1.3 Notes Date of release: Jan 2020 Munters cannot guarantee to inform users about the changes or to distribute new manuals to them. All rights reserved. No part of this manual may be reproduced in any manner whatsoever without the expressed written permission of Munters.

  • Page 8: Using The Trio Touch Screen

    Go back to the previous screen View the Main menus Choose language Trio connected to internet via Wi-Fi. Click to view network settings. Trio connected to internet via LAN. Click to view network settings. View alarms Go back to the main screen...

  • Page 9: Dashboard

    Click the circle containing the user name to edit personal preferences such as the language, units, name, and more. When a Trio controls two or more rooms or there are two or more houses on a farm, Send to All enables editing certain select functions in more than one room or house.
  • Page 10 © Munters AB, 2020...

  • Page 11: Basic Setup

    Define all units as metric or imperial. • Define each unit. Click Edit > Customize and define: • o Temperature (Celsius/Fahrenheit) o Pressure (Pascal/Inches of Water) o Weight (Kilogram/Pounds) o Air Flow (Cubic Meter/Hour/Cubic Feet/Minute) o Volume (Liter /Gallon) © Munters AB, 2020...

  • Page 12: Defining The Time/Date

    Date and Time Set: Manually enter the date and time.  o Time Zone: Select the zone from the drop-down list. NOTE Set the time zone even if you enable automatic date and time adjustment. © Munters AB, 2020...

  • Page 13: Defining The Room Setting

     Weaners: Same as Nursery  Mating: Breed gilts  Insemination  Stimulation  Quarantine  When you change the room setting from Room to any other setting, the new setting appears on the menu bar. © Munters AB, 2020...

  • Page 14: Batch Settings

    Growth day (used in various system algorithms) • Batch number enables tracking each herd’s production • Defining the Batch Settings Parameters • Settings Defining the Batch • 3.2.1 D EFINING THE ATCH ETTINGS ARAMETERS Manual Set Up • New Batch Wizard • © Munters AB, 2020...

  • Page 15: Manual Set Up

    Growth day: This parameter defines the animals’ age. Growth day automatically goes up by one (1) at midnight. When editing the growth day, you can increase the number; you cannot decrease the number. Trio increases the growth day at midnight. Range: 0 - 999 o Initial Number of Animals: Set the number of animals that are in the beginning of a batch.

  • Page 16: New Batch Wizard

    Stop growth day progress.  3.2.1.2 New Batch Wizard Trio provides a simple to use wizard to set up the Growing or Pre-Heat modes. Using the wizard enables defining negative growth days. When starting a new batch Trio: o Resets historical data...
  • Page 17 3. Select Growing or Pre-Heat. You must select an option to continue. o Growing Mode Define the Growth Day (zero or higher) and Initial Number of Animals.  o Pre-Heat Mode: © Munters AB, 2020...

  • Page 18: Defining The Batch Settings

    4. Click Next, Review and Save. 3.2.2 D Settings EFINING THE ATCH “Batch Settings” Settings page defines basic parameters for rooms when these room are NOT in normal mode. All other modes have the same parameters. 1. Click © Munters AB, 2020...

  • Page 19: Defining The Expected Animal Weight

    Animal weights are used when calculating the amount of air required when using Ventilation by Weight (page 35). In this screen, define the expected weights over the growth cycle. Trio provides a default chart which can be edited. Piglets: 1.5kg – 2.0kg •...

  • Page 20: Animal Weight Main Screen

    Growth Day: Define the growth day to determine the desired weight. Range 0 - 999 o Animal Weight: Set the expected animal weight. Range 0 - 250.0 NOTE Trio provides a default growth curve. If required, you can edit the growth days and animal weights. © Munters AB, 2020...

  • Page 21: Animal Weight Curve

    Edit the number of animals when animals are removed from or added to the herd. 1. Go to Batch > Animal Management. This screen displays the animal mortality data. 2. Click Add Mortality and edit (add or subtract) the number of animals removed or added. © Munters AB, 2020...

  • Page 22: Tech Support Information

    3.5 Tech Support Information To view information on your unit go to System > General Settings > Network . You will need this information when speaking with technical support. © Munters AB, 2020...

  • Page 23: Temperature Settings

    For example, if on day 1 the target temperature is 95° F and on day 5 the target temperature is 86° F, Trio adjusts the target temperature on days 2 to 4 so that it approaches the day 5 setting.

  • Page 24: Configuring The Temperature Curve

    Range: Target temperature to +90⁰ C. NOTE Tunnel appears if Tunnel Ventilation is enabled in Ventilation Settings (page 56). o Low/High Temperature Alarm: These parameters are differentials from the target temperature at which Trio sends an alarm. Range: Low Temp Alarm: -40°- Target ...

  • Page 25: Defining Temperature Curve Settings

    High Temperature Alarm: Enable if required. Outside Temperature Compensation: High temperature set point =  measured outside temperature + “outside temperature compensation”. Range [0.0° – 10.0°] Absolute High Temperature: Set the critical temperature (maximum  allowable). © Munters AB, 2020...

  • Page 26: Emergency Temperature Control

    4.3 Emergency Temperature Control In the event that Trio fails to receive a signal from the temperature sensor for an extended period of time, an alarm is triggered. Between the time that Trio stops receiving a signal and when an alarm is triggered, ventilation remains at the current level. When an alarm is...

  • Page 27: Introduction To Ventilation

    Scheme: Defining the fans/ventilation determines • how much air the fans provide and which fans provide the air. In addition, Trio controls the inlets and tunnel doors. There are two ways to control • the inlets and tunnel doors: o Static pressure: Based on the difference in the interior and exterior air pressures, Trio continually calculates the inlets’/doors’...

  • Page 28: Defining The Fans/Ventilation Scheme

    For more information, refer to Ventilation by Weight, page 35. Curve: Trio calculates a curve between growth days; the increase between days is • steady. If a curve is not enabled, ventilation increases at the next defined growth day.

  • Page 29: Extra Ventilation

    Target Temperature The temperature is still below the Tunnel Set Point. • Trio only enters Extra Ventilation if the temperature is 0.5⁰ above the Target • Temperature (this is the minimum; you can set the differential to be higher). You can set a differential for each level to ensure that ventilation increases only •...

  • Page 30: Tunnel Ventilation

    UNNEL ENTILATION If enabled, once the temperature reaches the Tunnel Set Point, Trio turns on the tunnel fans and opens the tunnel doors. As in Basic Ventilation, you define the fans to be used in each level. However, there is no curve between levels.

  • Page 31: Minimum And Maximum Ventilation

    Ventilation The following sections detail how to configure the minimum and maximum ventilation levels by growth day. As the temperature rises above the target temperature, Trio gradually increases ventilation level using a combination of increased fan speeds, cycle times, opening the inlets and more.

  • Page 32: Defining Basic Ventilation

    Day: Set the growth day for the required min/max set points. Each day must have a unique number. Add up to ten lines. o Min/Max percentage: Define the minimum and maximum ventilation percentages. Trio will automatically adjust the ventilation as the temperature changes. Extra/Tunnel Minimum Ventilation: As option when additional minimum ventilation is required in hot climates, Extra and Tunnel Ventilation can provide minimum ventilation.

  • Page 33: Defining Dynamic Ventilation

    (for cold temperatures) and the ventilation level (for warm temperatures). 1. Go to System > Control Strategy > Ventilation 2. Under Minimum / Maximum Ventilation, enable: o Dynamic Minimum Ventilation or o Dynamic Maximum Ventilation or o Both. In this example both are enabled. © Munters AB, 2020...
  • Page 34 Cold Maximum: When the outside temperature reaches the Dynamic Maximum Cold Outside Temperature, Maximum Ventilation runs at this percentage . o Warm Max. Level: When the outside temperature reaches the Dynamic Maximum Warm Outside Temperature, Maximum Ventilation runs at this Extra Ventilation level. © Munters AB, 2020...

  • Page 35: Ventilation By Weight

    When using cycle fans, each level has minimum and maximum on times, which determine the minimum and maximum CFM. If the ventilation doesn't provide enough air for the pigs (based on their numbers and weight) Trio sends an alarm. You will need to redefine the minimum level.

  • Page 36: Adding A Curve

    This device can be used for: • Measuring real time air speed • Enable ventilation compensation if the air speed does not meet the calculated minimum ventilation requirements.  Define a sensor as Measuring Fan. Refer to the Installation Manual. © Munters AB, 2020...

  • Page 37: Measuring Real Time Air Speed

    Installation Manual. 1. Go to System > Devices & Sensor and select the Measuring Fan. 2. In the Related Fan parameter, define the designated compensation fan. 3. Go to System > Control Strategy > Ventilation © Munters AB, 2020...
  • Page 38 4. In the Measuring Fan Usage parameter, define the usage as Real-Time Compensation. 5. In the Measuring Fan Maximum Compensation parameter, define the maximum percentage increase in the Related Fan’s speed. Range 0 – 100. Default 10%. © Munters AB, 2020...

  • Page 39: Levels Of Ventilation

    1. Go to Climate > Ventilation and click 2. Define: o Efficiency Maximum: Refer to Fans (Efficiency Fan). o Ventilation Tuning: This parameter determines how aggressively the Trio responds to differences between the measured temperature and the target temperature. CAUTION Munters recommends leaving this parameter at Normal.

  • Page 40: Basic Ventilation

    7.2.1 D EFINING ASIC ENTILATION In this configuration, Trio raises the minimum ventilation from 10% at Level One to 100% at Level 10.  In System map relays and analog output ports to fans (including the capacity), inlets, and stir fans as required. Only mapped devices show up in the following screens.
  • Page 41 4. Click the fan in the upper right. Both fans turn blue. 5. Define fans as required. © Munters AB, 2020...

  • Page 42: Fan Options

    Level 1. The fan will supply up to 10% of the possible ventilation. At Level 4, Fan 2 also begins to operate, supplying up to 40% of the possible ventilation. Under each ventilation level, Trio displays the total fan capacity of the fans operating.

  • Page 43: Minimum Ventilation Cycle

    2. Define: o Total Cycle Time (sec): Range: 60 – 999 seconds. o Min Cycle OFF Time (sec.): When using cycle time, Trio automatically adjusts the ON time set in the main screen. This parameter defines the minimum cycle off time. Range: 0 – 600 seconds.
  • Page 44 Under On (sec), enter the cycle ON time (Go to the Settings to define the Off time). In this example, at Level 4 Fan 1 runs in cycles (100 seconds on) and Fan 2 runs continuously. The maximum ventilation capacity reflects the change caused by running the fan in a cycle. © Munters AB, 2020...

  • Page 45: Analog Fans

    At Level 1 (10% output of the total fan capacity), Fan 1 runs at 35% speed. At Level 4 (40% of the total output), the speed drops to 20% but Fan 2 turns on as well. © Munters AB, 2020...

  • Page 46: Fans (Efficiency Fan)

    2. Click the fan in the upper right. Both fans turn blue. A percentage appears under the fan. 3. Click . This icon and the fan icon turn green. 4. In the percentage, enter the fan’s minimum speed (in percentage). 5. Go to Settings. © Munters AB, 2020...

  • Page 47: Fan Rotation

    Using the same fan or a limited number of fans exclusively can lead to mechanical wear and tear, for example to the drive belt. To minimize this damage, Trio enables “rotating” between fans. The rotation function switches between cycle fans in the same stage.
  • Page 48 2. Enable Fan Rotation and Minimum Ventilation Cycle. (Fan Rotation does not appear unless Fan Cycle is enabled.) 3. Go to Climate > Ventilation. 4. After enabling fans, click on any fan that you want to rotate. appears. 5. Click the icon. Repeat for any required fans. © Munters AB, 2020...

  • Page 49: Inlet And Curtain Ventilation

    Fan 2 while Fan 3 always runs during the on cycle. 7.2.3 NLET AND URTAIN ENTILATION In Basic Ventilation, Trio enables control over the inlets using one of two methods: Level • Static Pressure • NOTE Outlet control is by level only.

  • Page 50: Level Control

    1. Go to Climate > Ventilation. 2. Click 3. Click on a required inlet/outlet and enable it by clicking on the fan symbol that appears. 4. Define the opening level. 5. Repeat for every required inlet/outlet at each level. © Munters AB, 2020...

  • Page 51: Static Pressure Control

    Note that the Trio will adjust the inlets' opening only if one or more fan is operating. Set the required pressure, according to the air flow specification. The greater the difference between the exterior and interior pressures, the greater the air flow.

  • Page 52: Static Pressure Main Screen

    Trio goes into an Emergency Pressure state: Any vent that is not fully open, opens an additional 10%.  Trio remeasures the pressure. If the air pressure is still too high, vents  open an additional 10%. This process continues until pressure meets the specification.

  • Page 53: Static Pressure Settings Screen

    • o Wind delay: When pressure rises above or drops below the required level, Trio waits this amount of time before adjusting the inlet openings. Range: 0 – 999 seconds o Low Pressure Alarm Minimum Level: Low static pressure alarm is disabled when the minimum ventilation drops below this level.

  • Page 54: Defining Extra Ventilation

    Level: Read-only. o Diff: Define the temperature differential. When the temperature rises above the target temperature by this amount at each level, Extra Ventilation begins. Range: 0.0°C >15.0°C. By default, there is a 0.5°C/F minimum differential, © Munters AB, 2020...
  • Page 55 6. Go to System > Control Strategy > Ventilation 7. Under Enable Fan Cycle, check Extra. 8. Go to Climate > Ventilation > Extra Ventilation. 9. Define the cycle times. Refer to Minimum Ventilation Cycle, page XXXX for details. © Munters AB, 2020...

  • Page 56: Tunnel Ventilation

    Tunnel Ventilation Static Pressure • 7.4.1 D EFINING THE UNNEL ENTILATION ARAMETERS 1. Go to System > Control Strategy > Ventilation 2. Under Ventilation, enable Tunnel. 3. Go to Climate > Ventilation and click the Tunnel Tab. © Munters AB, 2020...
  • Page 57 NOTE To prevent overcooling, when defining the fans in the first tunnel level, the total amount of air should be the same or slightly lower than the last Minimum Ventilation or Extra Ventilation level. Tunnel Ventilation Fan Cycle (Optional): 5. Go to System > Control Strategy > Ventilation © Munters AB, 2020...
  • Page 58 6. Under Enable Fan Cycle, check Tunnel. 7. Go to Climate > Ventilation > Tunnel. 8. Define the cycle times. Refer to Minimum Ventilation Cycle, page 43 for details. © Munters AB, 2020...

  • Page 59: Defining The Tunnel Ventilation Settings

    7.4.3 UNNEL OORS In Tunnel Ventilation, Trio enables control over the tunnel doors using control by level or control by static pressure. Control of these doors is the same as control over inlets. Refer to these sections for details. Level Control •...

  • Page 60: Tunnel Ventilation Static Pressure

    Range: 0 – 20 Pa. Default: 5 o Pressure Alarm: Set the low and high pressures, at which an alarm is transmitted. Range: 0 – 40 Pa. © Munters AB, 2020...

  • Page 61: Calibrating The Inlet/Tunnel Door

    1. Go to System > Control Strategy > Ventilation 2. Click 3. Define: o Enable Calibration: Select 24 hours a day or define a specific time frame. o Number of steps: Set up the number of steps (number of movements). © Munters AB, 2020...

  • Page 62: Stir Fan

    3. Option: Define the stir fan cycle time (refer to Minimum Ventilation Cycle, page 43) 4. If the ventilation fans are running in a cycle, go to Climate > Ventilations > Settings. 5. Define when the stir fan operates, during the cycle On or Off time. © Munters AB, 2020...

  • Page 63: Cooling Functions

    • Invalid humidity sensor readings are not taken into consideration. • To avoid causing the animals undo heat stress during periods of high relative humidity, Trio employs the following rules: When the temperature reaches the Cooling Temperature in the Temperature •...

  • Page 64: Selecting The Cooling Mode

    8.2 Selecting the Cooling Mode Trio enables running the cooling device in three different modes: Ramping: Cycle modulation, frequency depends on the error in °C, with respect to • the cooling setting (target). Continuous: When activated, the cooling devices operate continuously.

  • Page 65: Continuous Cooling

    If you want cool pads to operate only in Tunnel mode, 1) enable Tunnel Mode 2) set up the Temperature Curve so that Tunnel Targe Temperature is below the Cooling Temperature. o Humidity Limit: Stop cooling when the humidity level reaches the level defined in the Humidity settings. © Munters AB, 2020...

  • Page 66: Cycle Cooling

    Enable from ventilation Level: Select the level (ventilation output) to enable cooling operation. (Default 1). o ON/OFF Time: Describe the amount of time the cycle is ON and OFF, respectively. o Humidity Limit: Enable stopping cooling at a certain humidity level. © Munters AB, 2020...

  • Page 67: Ramping Cooling

    When cooling starts, the off time will be the maximum off time. As the temperature rises to the band maximum, the maximum off time decreases to the minimum. o Humidity Limit: Enable stopping cooling at a certain humidity level. © Munters AB, 2020...

  • Page 68: Sprinkler

    Water is sprayed at different intervals, depending on the outside temperature.  Go to System > Devices and Sensors and define one relay as sprinkler (refer to the Installation Manual). 1. Go to Control > Sprinkling. © Munters AB, 2020...

  • Page 69: Defining The Sprinkler Settings

    Cold outside Temperature: Set the cold temperature for maximum sprinkling off time. o Warm outside Temperature: Set the warm temperature for min sprinkling off time. o Stop outside temperature: The temperature below which the device stops. © Munters AB, 2020...

  • Page 70: Heating Functions

    • 10.1 Heating Functions Trio supports up to six (6) on/off heating devices and variable heaters. To control the heat, Trio has two different programs, one to maintain the target temperature in the entire house and one program that controls separate heating zones. In the case of the latter, each heater has a dedicated sensor and unique target temperature.

  • Page 71: Analogue Heaters

    Heater On Temp: Define the difference from the Heat target temperature at which the heaters turn on. Range: 0.2 - 5⁰ C. o Heat Tuning: This parameter determines how aggressively the TRIO responds to differences between the measured temperature and the target temperature.

  • Page 72: Heat Cycles

    Once a zone’s heater is activated, it will work to maintain the temperature. All zone heaters work independently.  Define relays output ports as heaters. Refer to the Installation Manual. © Munters AB, 2020...
  • Page 73 Heater On Temp: Define the difference from the Heat target temperature at which the heaters turn on. Range: 0.2 - 5⁰ C. o Heat Tuning: This parameter determines how aggressively the TRIO responds to differences between the measured temperature and the target temperature.

  • Page 74: Piglet Zone

    10.4 Piglet Zone Trio supports a piglet zone, which is a thermal environment that maintains the newly born animals’ heat. Using a dedicated temperature sensor for that area, Trio’s software automatically adjusts the heat output to maintain the required temperature.
  • Page 75 Heater On Temp: Define the difference from the Heat target temperature at which the heaters turn on. Range: 0.2 - 5⁰ C. o Heat Tuning: This parameter determines how aggressively the TRIO responds to differences between the measured temperature and the target temperature.
  • Page 76 After defining the Piglet Zone, an icon appears on the dashboard. © Munters AB, 2020...

  • Page 77: Feed Management

    Feed lines transport the feed from the hoppers to feeding pans, according to signals sent from the hoppers. Trio receives inputs from the augers and hoppers that enable controlling the feed distribution (start and stop signals). In addition, the user enable am alarm if the run time exceeds the defined parameters.
  • Page 78 Feeding Runtime (min.): Define how long the feed runs last. o Feed Line Sensor Max. Delay (min.): Define the maximum amount of time that can pass from a feeding start time before Trio generates an alarm. 4. If required, go to Control > Feed > Alarm to set the alarms.

  • Page 79: Air Quality

    Ensuring air quality means configuring the Trio relative humidity, CO2, and ammonia sensors. Each of these factors are independent and require a sensor. When any of these factors rise above the user defined levels, Trio compensates by increasing the ventilation rate or by increasing the heat.

  • Page 80: Defining The Air Quality Settings

    12.2 Defining the Air Quality Settings When the air quality (CO2/NH3/Humidity) exceeds the specifications defined in the Air Quality Screen, Trio can increase the ventilation, the heat or both. (Alternatively, additional treatment can be disabled). When central heating is employed, the changes to heating are global. When zone heaters are employed, changes are specific to each heater.
  • Page 81 RH Shutoff Differential: (%): Below this level, humidity treatment ceases. Range: 0% to 10% o High RH Alarm Threshold (%): Trio sends an alarm when the humidity level rises above this level. Range: 0% to 100% o Co2 Shutoff Differential: (ppm): When CO2 levels are below the target level by this amount, all CO2 treatment stops.

  • Page 82: Timers

    13 Timers Timers provide an additional method of controlling relay devices, namely setting a timetable in which the device can operate. In addition to the timetable, Trio enables setting up time cycles and temperature ranges in which a device can operate.
  • Page 83 If an outside temperature sensor is enabled, map timers to it (if required). • © Munters AB, 2020...

  • Page 84: Alarms

    Trio waits this amount of time before sending an alarm. This prevents sending alarms for short deviations. Range: 0 – 999 seconds. Alarm Reminder: Trio will resend an alarm after this amount of time if the alarm is • not acknowledged. Range: 0 – 999 minutes.

  • Page 85: Alarm Test

    Water Shortage: • o Min Water/Hour: Trio will send an alarm if the water flow is less than this amount. Range: 0 – 999 gallons/liters. o Enable Water Shortage Alarm: Define the period in which the alarm is active, 24 hours a day or specific time frames.

  • Page 86: Viewing The Alarms

    This function compares the relay’s current state to its defined state (normally open, normally close). If the relay is not in its defined state, Trio sends an alarm. You can define the auxiliary alarms to operate during specific time periods. Use this alarm for those relays controlling important functions.

  • Page 87: Sending A General Alarm

    (normally open, normally closed) an alarm is sent. 14.4 Sending a General Alarm  Define a relay as an alarm. Refer to the Installation Manual. 1. Go to System > Device and Sensors. © Munters AB, 2020...

  • Page 88: Water Alarm

    Refer to the Installation Manual. 1. Go to System > Control Strategy > Water 2. Enable (according to your requirements): o Low water flow: This alarm is triggered when there is a shortage in the estimated water consumption. © Munters AB, 2020...
  • Page 89 6. Define: o High Flow Delay (Min.): Define the amount of time that water flows at the high flow rate before Trio sends an alarm. o Low Flow Delay (Min.): Define the amount of time that water flows at the low flow rate before Trio sends an alarm.

  • Page 90: History

    15 History A Trio controller saves: • o 150 growth days of history data (minimum). o Up to 365 growth days of history data (estimated maximum) TrioAir saves data on the server for an unlimited amount of time. • Starting a new batch/flock erases all history data.

  • Page 91: Alarms And Events

    Go to this screen to view the last 999 alarms and events. Alarms history can display the following alarms. NOTE Performing a Cold Start or Starting a new group clears the Alarm History. 1. Go to Batch > History > Alarms 2. Click the relevant tab. © Munters AB, 2020...

  • Page 92: Water And Feed History

    NOTE Water and feeder relays or sensors must be enabled to see these screens 1. Go to Batch > History > Water 2. Click the relevant tab to see its history. Click the clock symbol to view the hourly breakdown. • © Munters AB, 2020...

  • Page 93: Devices History

    Records the heaters and cooling devices run time (in minutes) for each growth day in 24H resolution, this information gives the opportunity to investigate and verify if the runtime of a device performs as expected. Go to Batch > History > Devices • © Munters AB, 2020...
  • Page 94 Click the clock symbol to view the hourly breakdown. • NOTE History displays installed devices only. © Munters AB, 2020...

  • Page 95: Resetting, Saving And Loading Settings, Updating Software

    16 Resetting, Saving and Loading Settings, Updating Software Resetting means erasing the tables and current product definitions. Once the settings have been erased, the user can manually reconfigure the Trio or load settings from a USB device. Resetting the Settings •...

  • Page 96: Resetting The Trio Cpu And Sensor Connections

    16.2 Resetting the Trio CPU and Sensor Connections There are two ways to reset the Trio unit, depending on what is required. To reset the CPU and the user interface, press the button shown in Figure 2: CPU • Reset Button.

  • Page 97: Saving Or Loading The Settings

    1. Go to System > General Settings and click Files 2. Click Choose Operation and select Load Settings, Save Settings, or Delete File. 3. Follow the instructions. 16.4 Viewing the Log The log displays which tables were successfully saved. © Munters AB, 2020...

  • Page 98: Updating The Software

    16.5 Updating the Software CAUTION Do not disconnect the power while updating the software. Any disconnection can cause severe hardware damage. To update the Trio Software: 1. Go to System > General Settings. 2. Click 3. In Software Version, click Update.

  • Page 99: Appendix A: Central Exhaust

    • maintains the required pressure in the air duct. By adjusting the ventilation, each room independently controls the amount of air entering. As temperature rises, the inlets’ opening increases. Trio dynamically adjusts the • ventilation to maintain the required pressure.

  • Page 100: Selecting Central Exhaust

    1. Perform a Cold Start. Go to System > General Settings > About. a. Click Reset Factory Default. b. Create a backup if required. 2. Click Reset. 3. Click Start New Setup. 4. Click Central Exhaust. © Munters AB, 2020...

  • Page 101: Central Exhaust Dashboard

    Ventilation, page 103. Cooling (Version 4.2.3 and above) Pressure Timers Aux Alarm History • Alarms & Events System • o Temperature Definition (Installation Manual) o Device & Sensors Definition and Mapping (Installation Manual) Room Settings © Munters AB, 2020...

  • Page 102: Setting The Static Pressure

    20 Pascal. o Pressure Adjustment Delay: When the pressure is outside of the band limits, define the amount of time that Trio waits before adjusting the inlets. Range 5 – 30 seconds. o Ventilation Level while Pressure Fails: In the event that the pressure sensor fails, set the ventilation level.

  • Page 103: Room Setting

    Central Exhaust supports 30 levels of ventilation. The user adds each layer manually. To set up the ventilation levels: 1. Go to System > Devices & Sensors and define the fans. Refer to the Installation Manual. 2. Go to Control > Ventilation. © Munters AB, 2020...
  • Page 104 4. Enable the fan(s) in Level 1 as required. Refer to Defining the Fans/Ventilation Scheme, page 28 for details. 5. Click to add an additional level and define the Level 2 fan(s) as required. 6. Repeat these steps, up to 30 levels. © Munters AB, 2020...

  • Page 105: History

    7. Click Save. 17.8 History Go to History > Devices > Cooling to view the controller’s cooling data. © Munters AB, 2020...

  • Page 106: Appendix B: Central Corridor

    • 18.1 Introduction to Pressure Control Trio adjusts the inlet positions to maintain the defined static pressure levels. Inlet position open or close as required to maintain a pressure level that is within the target level’s band. To ensure that inlets open or close only when required, there is a delay time; the pressure must remain outside of the pressure band for a certain amount of time before the inlets move.

  • Page 107: Central Corridor Dashboard

    3. Click Start New Setup. 4. Click Central Corridor. 18.3 Central Corridor Dashboard The basic task of the Central Exhaust Mode is to control and monitor the air pressure. The dashboard shows the pressure and ventilation status. © Munters AB, 2020...

  • Page 108: Central Corridor Functions

    System • Temperature Definition Alarm Settings Device & Sensors Definition and Mapping Room Settings Mapping Devices o General Time & Date  Alarm  User  Network  File Saving and Loading  Software Update  © Munters AB, 2020...

  • Page 109: Setting The Pressure Levels

    Pressure Adjustment Delay: When the pressure is outside of the band limits, define the amount of time that Trio waits before adjusting the inlets. Range 5 – 30 seconds. o Ventilation Level while Pressure Fails: In the event that the pressure sensor fails, set the ventilation level.

  • Page 110: Defining The Heat

    Max Heat Temperature: Set the temperature at which heaters work at maximum capacity. Range: -40⁰ to On temperature o Minimum Output: Set the voltage at which heaters work at their minimum level. o Maximum Output: Set the voltage at which heaters work at their maximum level. © Munters AB, 2020...

  • Page 111: Room Setting

    In System > Room Settings, select the room mode. Room mode is based on the animals’ growth stage. You can change the stage throughout the growth cycle. The default is Central Corridor. NOTE The room setting is used when comparing data from rooms, it does not change room settings. © Munters AB, 2020...

  • Page 112: Warranty

    Munters plant was required: if this is not done, the user is fully responsible for the damage which they could suffer.
  • Page 113 Dismantling and assembly must be performed by qualified technicians and according to the manufacturer’s instructions. The use of non-original spare parts or incorrect assembly exonerates the manufacturer from all liability. Requests for technical assistance and spare parts can be made directly to the nearest Munters office. © Munters AB, 2020...

Table of Contents
