- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath (05v23) eng Attention: The pool should always be be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
-
Page 4: Technical Data
Technical data Outside dimensions of the pool 170 cm Length 80 cm Wide 56 cm Hight Hot and cold water connection ½ Inch max. 4 Bar Waist water HT 50mm Power connection 220-240 V 50 Hz max. 4 A Massage pump water 750 W Ozone 10 W... - Page 5 Dimension The pool was developed especially for bathrooms with limited space. 80 cm aussen outside inside - top 77 cm innen - oben 80 cm aussen 77 cm innen - oben Höhen 56 cm aussen outside Höhen 42 cm innen inside 56 cm aussen Filling level...
-
Page 6: Preparing The Connections
Preparing the connections 141 cm 135 cm 60 cm 35 cm 40 cm 40 cm Hot water 1/2 inch Cold water 1/2 inch Grey area = possible area for the drain pipes, in the wall area the drain can be up to a max. height of 6 cm from the centre of the hole (German drain fitting e.g. - Page 7 Alignment In order for the pool to stand straight, it is necessary to align the pool exactly with the help of a spirit level. Each foot is individually adjustable, so you can compensate for small irregular- ities in the floor. Please make sure that all feet are touching the ground and that the weight is evenly distributed on the ground.
- Page 8 Connecting the cold and hot water After the drain has been installed, the water is now connected. The cold water connection is on the right and the hot water connection is on the left. Wall Hot water Cold water Commissioning/leak test For the leak test, please now connect the water and waste water with the hose connections.
- Page 9 Facing the tub When the tub has been finished and connected properly, the sides are faced. To do this, simply tilt the tub slightly and raise it to click the side parts underneath, now just screw them in place and put the cover cap on the screw.
- Page 10 Sealing You can now draw a silicone joint between the tub and the wall to seal it. Pool control panel Massage- On / Off switch press 3 sec Strength control Heating * Select function key +/- Bubble massage Confirmation key Ozone Select function key +/- Underwater light...
-
Page 11: Warranty And Service
+49 35795 - 179 699 Defects that can be traced back to calciferous or iron-rich water are excluded from the warranty. Please describe the spare part exactly and state the exact pool type (e.g. W49). We are always open to your comments and suggestions. - Page 12 Senior GmbH...
