- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath (05v23) eng Attention: The assembly of this tub should be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
-
Page 4: Technical Data
Technical data Outside dimensions of the pool 140 cm Length 140 cm Wide 70 cm High Hot and cold water connection ½ Inch max. 4 Bar Waste water HT 40mm Power connection 220-240 V 50 Hz max. 12 A Massage pump air 400 W Massage pump water 750 W... - Page 5 Designations Switch for hand shower/optional Large massage jets Self-Clean Light Cold water Water suction Hot water Massage jets small ...
-
Page 6: Preparing The Connections
Preparing the connections 0-6 cm 45 cm 40 cm 75 cm 75 cm Hot water 1/2 inch ATTENTION: leave the 15 cm Ø around the white siphon (dark grey Cold water 1/2 inch area) under the drain free. Connections can also be on the 230V 16A socket outlet (or fixed opposite side (possible with hose socket outlet) -
Page 7: Installing The Drain
Alignment In order for the pool to stand straight, it is necessary to align the pool precisely with the help of a spirit level. Each foot is individually adjustable, so you can compensate for small irregularities in the floor. Please make sure that all feet are touching the ground and that the weight is evenly distributed on the ground. - Page 8 Connecting the cold and hot water After the drain pipes have been installed, the water is now connected. The cold water con- nection is on the right and the hot water connection is on the left. Wall Cold water Hot water Commissioning/leak test For the leak test, please now connect the water and waste water with the hose connections.
- Page 9 Facing the tub When the tub is finished and professionally connected, the sides are faced. To do this, simply tilt the tub slightly and raise it to click the side parts underneath. Now just screw it in place and put the cover cap on the screw.
- Page 10 To do this, press the OK button for approx. 3 sec- onds. Please note that these displays are installed in all W60 whirlpool tubs. Regardless of wheth- er the equipment is with or without heating.
-
Page 11: Warranty And Service
+49 35795 - 179 699 Defects that can be traced back to calciferous or iron-rich water are excluded from the warranty. Please describe the spare part exactly and state the exact pool type (e.g. W60). We are always open to your comments and suggestions. - Page 12 Recycling The disposal of the product‘s electronics is governed by the Waste Electrical and Electronic Equipment Act. The „old device“ must then be taken to an appropriate collection point. We recommend that you remove the control unit, the lighting unit and the display and take these parts to the electrical/electronic collection point.
