- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath (11v20) eng Attention: The pool should always be be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
-
Page 4: Technical Data
Technical data Outside dimensions of the pool 141 cm Length 141 cm Wide 55 cm Hight Inner dimensions of the pool at the bottom 105 cm x 45 cm 150 cm x 63 cm Hot and cold water connection ½ Inch max. 4 Bar Waist water HT 40mm Power connection 220-240 V... - Page 5 Bezeichnungen Handbrause Luftdüsen (je Ausführung) Wasserfall Ab uss Umschalter Handbrause/Wasserfall Farblicht Hand shower Air jets (per version) Kaltwasser Ab ussö ner Warmwasser Massageeinstellung Waterfall Drain Wasseransauger Bedienteil (je Ausführung) Hand shower/waterfall switch Colour light Massagedüsen groß...
- Page 6 Vorbereitung der Anschlüsse 40 cm 40 cm 70 cm 70 cm height of 6 cm from the centre of Socket 230V 16A (or fixed the hole. socket) R-variant Waste water via a flexible con- nection HT 40 supplied. Hot water 1/2 inch possible with hose extension Connection possible without dismantling the skirt/panel.
- Page 7 Alignment In order for the pool to stand straight, it is necessary to align the pool exactly with the help of a spirit level. Each foot is individually adjustable, so you can compensate for small irregular- ities in the floor. Please make sure that all feet are touching the ground and that the weight is evenly distributed on the ground.
- Page 8 Connecting the cold and hot water After the drain has been installed, the water is now connected. The cold water connection is on the right and the hot water connection is on the left. Wall Wand Hot water Cold water Kaltwasser Warmwasser Commissioning/leak test...
- Page 9 Sealing You can now draw a silicone joint between the tub and the wall to seal it. Pool control panel - A1420 R VOL- VOL+ On/off switch Volume + Station search + Volume - Station search - Underwater lamp...
- Page 10 Pool Bedienteil - A1420 H On/off switch Confirmation switch left right Press for 2 seconds to start the control unit, press again to switch the control unit off again. Press the left and right buttons to select the respective function and confirm with Light Bluetooth...
- Page 11 Confirm Bluetooth selection with (2s) The display shows „PAIR“. Switch on the Bluetooth function on your mobile phone. The pool appears on your display under the name JOYONWAY. The password is 2288. Now connect both devices. Now you can play music stored on your mobile phone or content from streaming services (extra charge, not included in the scope of delivery) via the speakers of the pool.
-
Page 12: Warranty And Service
Fax: Defects that can be traced back to calciferous or iron-rich water are excluded from the warranty. Please describe the spare part exactly and state the exact pool type (e.g. W20). We are always open to your comments and suggestions.
