- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath S12D (05v22) eng Attention: The assembly of this tub should be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
-
Page 4: Technical Data
Technical data Outside dimensions of the pool 170 cm Length 85 cm Wide 60 cm Height Hot and cold water connection ½ Inch max. 4 Bar Waste water HT 40mm Power connection 220-240 V 50 Hz max. 4 A Massage pump water (Whirlpool) 750 W Massage pump air (Air version) 400 W... -
Page 5: Product Components
Product components Sanitary acrylic bathtub with door Wall rail Straight wall spacer Shower door Wall plug Screws Wall rail Connecting screw Washers and Door hinge from spacer to Cover caps wall rail Wall hinge Screw Wall hinge Door seal... - Page 6 Dimensioning...
- Page 7 Designations Umschalter Wanneneinlauf - Handbrause Changeover switch bath spout - hand shower Warm-/Kaltwasser Handbrause Hot/cold water Einstellung Massagedüsen Hand shower Massagedüsen ein/aus Setting massage jets Wanneneinlauf Wasser Ansauger Massage jets on/off ...
-
Page 8: Preparing The Connections
Preparing the connections S12D right 105 cm 85 cm 40 cm 23 cm 38 cm Hot water 1/2 Inch Cold water 1/2 Inch - Connections can also be on the opposite side (possible with hose extension) Grey area = possible area for the drain pipes, in the wall area the drain can be up to a max. - Page 9 S12D left 105 cm 85 cm 40 cm 23 cm 38 cm Hot water 1/2 Inch Cold water 1/2 Inch - Connections can also be on the opposite side (possible with hose extension) Grey area = possible area for the drain pipes, in the wall area the drain can be up to a max.
-
Page 10: Installing The Drain
Alignment In order for the pool to stand straight, it is necessary to align the pool precisely with the help of a spirit level. Each foot is individually adjustable, so you can compensate for small irregularities in the floor. Please make sure that all feet are touching the ground and that the weight is evenly distributed on the ground. - Page 11 Connecting the cold and hot water After the drain pipes have been installed, the water is now connected. The cold water con- nection is on the right and the hot water connection is on the left. Wand Wall Hot water Cold water Kaltwasser Warmwasser...
-
Page 12: Door Assembly
Door assembly First attach the lower door hinge C3 to the underside of the spacer C as shown in the adjacent illustration. Now slide the bracket C onto the previ- ously fastened wall rail B as shown in the illustration. Now place the shower door D on the already fixed lower door hinge C3. -
Page 13: Attach The Wall Bracket
At the holes already pre-drilled, connect the wall rail B and the spacer C with the washers C2 and the screws C1 (see fig.). Then place the covers C2 on the screw heads. Attach the wall bracket To improve stability, you must now attach the wall bracket D1. To do this, place it on the spacer as shown in the illustration and mark the exact position on the wall. - Page 14 Door seal Do not forget to attach the door seal D3 to the lower edge of the door. Cut the seal on the hinge side with a cutter knife as shown in the illustration. Sealing You can now draw a silicone joint between the tub and the wall to seal it.
- Page 15 Commissioning/leak test For the leak test, please now connect the water and waste water with the hose connections. It is important that the tub continues to stand away from the wall so that you can still operate behind it. Before you put the pipe under water pressure, please note that it has only been pre-assembled by the factory to make it easier for you to set it up.
-
Page 16: Warranty And Service
Fax: Defects that can be traced back to calciferous or iron-rich water are excluded from the warranty. Please describe the spare part exactly and state the exact pool type (e.g. S12D). We are always open to your comments and suggestions.
