Summary of Contents for Senior Bad T18
- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath (10v20) eng Attention: The pool should always be be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
-
Page 4: Technical Data
Technical data Outside dimensions of the pool 188 cm Length 120 cm Wide 86 cm Hight (highest point - TV side) Hot and cold water connection ½ Inch max. 4 Bar Waist water HT 50mm Power connection 220-240 V 50 Hz max. - Page 5 Dimension Enough space for two people. 188 cm Screen Bildschirm: 43 x 32 cm 120 cm It is designed to stand in a corner. There are front skirts on the hull at the front and at the head end, only at the back and on the TV side it is not faced. 112 cm Liege äche Lying surface 80 cm Liege äche...
-
Page 6: Preparing The Connections
Modell A 2118C - Preparing the connections Variante links Frontschürze vorn und links 86 cm 80 cm 70 cm 40 cm 40 cm 120 cm 60 cm Hot water 1/2 inch Warmwasser 1/2 Zoll grauer Bereich = mögl. Bereich für die Ab ussrohre, im Wandbereich kann der Ab uss sich bis zu einer Cold water 1/2 inch Kaltwasser 1/2 Zoll... - Page 7 Alignment In order for the pool to stand straight, it is necessary to align the pool exactly with the help of a spirit level. Each foot is individually adjustable, so you can compensate for small irregular- ities in the floor. Please make sure that all feet are touching the ground and that the weight is evenly distributed on the ground.
- Page 8 Connecting the cold and hot water After the drain has been installed, the water is now connected. The cold water connection is on the right and the hot water connection is on the left. Wall Hot water Cold water Commissioning/leak test For the leak test, please now connect the water and waste water with the hose connections.
- Page 9 Facing the tub When the bathtub is finished and properly connected, the sides are faced. To do this, simply tilt the tub slightly and raise it in order to click the side parts underneath. Now just screw the sides together and place the cover cap on the screw. Sealing You can now draw a silicone joint between the tub and the wall to seal it.
- Page 10 Pool control panel/remote control Light ON/OFF ON/OFF Air jets ON/OFF Radio ON/OFF Water jets ON/OFF, pressing the Station search/temperature button twice lightly switches the control Heating heating on - use the arrow keys to select the temperature Station memory ON/OFF Radio/USB input ON/OFF Station memory Channel search...
-
Page 11: Tv Remote Control
TV remote control 1 Power switch to switch on the TV set. 2 USB buttons to control playback from the USB input 3 HOME key to call up the first page again 4 INFO key to display information (e.g. channel no. TV system, PC frequency), top right corner of the screen 5 P. -
Page 12: Operating The Tv Set
Operating the TV set Input source Select the source (Source 7) to display the input source menu. Select the desired input signal source with the (9) button and press OK. TV menu Press the „Menu“ button (10) to display the menu, use (9) to ... -
Page 13: Search Channels
Sound Select the sound menu with the (9). The option „Sound mode“ offers the possibility to switch between music/movie/motion/ user. There are also options for au- tomatic volume control and set- tings via the equaliser function. Search channels Under the menu item Channel, you have the option of an auto- matic channel search or manual setting of the channels. -
Page 14: Personal Settings
Networks Select the setting and press the OK button to display the interface of the „Android“ setting. Select „WIFI“ and press the OK button to open it. A list of WiFi signals is displayed. Select the correct signal and enter your password. -
Page 15: Warranty And Service
Defects that can be traced back to calciferous or iron-rich water are excluded from the war- ranty. Please describe the spare part exactly and state the exact pool type (e.g. T18). We are always open to your comments and suggestions. - Page 16 Senior GmbH...
