- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath (05v23) eng Attention: The pool should always be be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
-
Page 4: Technical Data
Technical data Outside dimensions of the pool 182 cm Length 120 cm Wide 80 cm Hight (highest point - headrest) Hot and cold water connection ½ Inch max. 4 Bar Waste water HT 50mm Power connection 220-240 V 50 Hz max. - Page 5 Dimension Enough space for two people. 120 cm 182 cm Seat: Length: 120cm Sitz äche: Länge: 120 cm Wide: 90cm Breite: 90 cm Höhe: 47 cm Hight: 47cm 120cm Lying surface 120 cm Liege äche 90cm Lying surface 90 cm Liege äche It is designed to stand in a corner.
-
Page 6: Preparing The Connections
Preparing the connections Modell A 2113 90 cm 80 cm 90 cm 40 cm 40 cm 57 cm 150 cm Warmwasser 1/2 Zoll grauer Bereich = mögl. Bereich für die Ab ussrohre, Hot water 1/2 inch im Wandbereich kann sich der Ab uss bis zu einer Kaltwasser 1/2 Zoll max. - Page 7 Alignment In order for the pool to stand straight, it is necessary to align the pool exactly with the help of a spirit level. Each foot is individually adjustable, so you can compensate for small irregular- ities in the floor. Please make sure that all feet are touching the ground and that the weight is evenly distributed on the ground.
- Page 8 Connecting the cold and hot water After the drain has been installed, the water is now connected. The cold water connection is on the right and the hot water connection is on the left. Wall Hot water Cold water Commissioning/leak test For the leak test, please now connect the water and waste water with the hose connections.
- Page 9 Facing the tub When the tub has been finished and connected properly, the sides are faced. To do this, simply tilt the tub slightly and raise it to click the side parts underneath, now just screw them in place and put the cover cap on the screw.
- Page 10 Sealing You can now draw a silicone joint between the tub and the wall to seal it. Pool control panel Massage- On / Off switch press 3 sec Strength control Heating * Select function key +/- Bubble massage Confirmation key Ozone Select function key +/- Underwater light...
-
Page 11: Warranty And Service
+49 35795 - 179 699 Defects that can be traced back to calciferous or iron-rich water are excluded from the warranty. Please describe the spare part exactly and state the exact pool type (e.g. W23). We are always open to your comments and suggestions. - Page 12 Senior GmbH...
