- Page 1 Senior GmbH Assembly Instructions Whirlpool Bath (07v20) eng Attention: The pool should always be be done by two people!
- Page 2 Foreword Dear customer, we are pleased that you have chosen this product. Please observe all instructions before assembly and use and strictly follow the procedure below! Please check the product for completeness first. If there is any damage, please send us a message with a short description and photos of the affected area.
- Page 3 Sealing areas under/behind the bathtub Sealing is compulsory - silicone is not enough! The areas behind and under the bathtub must be tiled. Sealant joints - like silicone joints - are not waterproofing, but only maintenance and beauty joints! Only the use of bathtub sealing tapes or e.g.
- Page 4 Please note: The pool should be connected by an approved tradesman. The pool should be assembled by a professional in accordance with these assembly instructions. The power connection for the pool must be made by a certified electrician. This person must also ensure sufficient earthing to prevent accidents and malfunc- tions.
-
Page 5: Product Components
Product components Glass shelf Bath tub made of sanitary acrylic with removable apron/panel Right rear panel: The right rear panel is fitted with the glass shelf. Shower panel: The panel is equipped with the back massage, the fitting, the rain show- er and optionally with the control display. - Page 6 Glass shelf Screw Underlay Underlay Sili- Self-tapping washer metal cone washer screw 4x30 4x30 Screw Upper arch Lower arch 4a narrow Side window Flat gasket profile profile corner profile 2 x thick 4b wide corner profile 4x30 Middle profile Screw Screw Upper door Lower door...
- Page 7 Connections for water, sewage, electricity, telephone Right version 115-125 cm 42 cm 50 cm 25 cm Hot water 1/2 inch ATTENTION: leave the 15 cm Ø around the white siphon (dark grey Cold water 1/2 inch area) under the drain free. Connections can also be on the opposite side 230V 16A socket (or fixed socket)
- Page 8 Connections for water, sewage, electricity, telephone Left version 115-125 cm 42 cm 50 cm 25 cm Hot water 1/2 inch ATTENTION: leave the 15 cm Ø around the white siphon (dark grey Cold water 1/2 inch area) under the drain free. Connections can also be on the opposite side 230V 16A socket (or fixed socket)
- Page 9 Setting up and aligning the tub Remove the skirt/panel and place the bathtub where you want it to stand later. Align it with the help of a spirit level. Then pull the tub out approx. 40-50 cm from the corner. This is necessary so that you can mount it on the back later.
- Page 10 Screw back panels to panel and tray Silicone washer Screw Washer metal The joint sealing tape (sponge rubber seal) supplied is glued to the two long corner profiles and to the panel (see diagram below). Foam rubber seal 2-3 mm from the outer edge, stick along the panel.
- Page 11 4x30 Self-tapping screw The panel is now simply placed on the tray and fixed with the B5 screws. Attention: The marking points on the tub serve as orientation for the subsequent screwing of the rear panels to the shower tray. The base of the tub must not be drilled through!
- Page 12 The front frame 4x30 Screw Upper arch Lower arch 2 corner Magnetic bar profile profile profiles Pre-assemble frame First take the magnetic strip C18 and insert it into the recess of the profile C4 (wide). Now screw the corner profile C4 (narrow) to the two arch profiles C3 for the bottom and C2 for the top.
- Page 13 Prepare door Lower door Glass door Upper door Door seal, roller roller F-seal The diagram shows the preparation of the door, which is completely uncomplicated. The only thing to note is that the roller C12 (with push-button) should be at the bottom, the other C11 at the top.
- Page 14 Final assembly of the front and the door Screw Upper arch Lower arch profile profile Corner profiles Side window Flat gasket 2 x thick narrow broad Screw Screw Middle profile TIP: The distance be- tween C7 and C4 (narrow) must be approx.
-
Page 15: Hose Connections
TIP: If the magnetic lock does not close the door because the door is not exactly perpendicular, you can adjust the height of the door precisely on the upper rollers C11. This also applies if you cannot engage the lower roller C12 in the guide in profile C3 because it is then too tight or even too loose. - Page 16 View of the connections from behind The sketch shows an overview of the water connections, which are located behind the shower panel. Single-lever connection Thermostat connection 4fach-Umsteller 4-way diverter 4-way diverter e.g. for - rain shower e.g. for - rain shower z.B.
- Page 17 Reattach apron When the tub is finished and professionally connected, the sides are faced again. To do this, simply tilt the tub slightly and raise it to click the side parts underneath, now just screw them in place and put the cover cap on the screw. Sealing It is necessary to draw a silicone joint between the tub and the C3 profile as well as be- tween the front glass pane and the C3 profile from the inside (see illustration).
-
Page 18: Operating Display
Commissioning/leak test For the leak test, please now connect the water and the waste water with the hose connec- tions. It is important that the tub continues to stand away from the wall so that you can still get behind the shower panel. Before you put the line under water pressure, please note that the shower panel has only been pre-assembled by the factory to make it easier for you to set it up. - Page 19 Shower maintenance and cleaning Clean the tub and shower enclosure with a mild liquid detergent and a soft cloth. Caution: Never use acetone, cleaning agents containing ammonia or coarse-grained scouring agents! Clear the shower drain regularly of hair and the like to prevent clogging. Use an acrylic care product for the bathtub and the panel to protect the surface from scratches.
-
Page 20: Warranty And Service
Defects that can be traced back to calciferous or iron-rich water are excluded from the war- ranty. Please describe the spare part exactly - preferably add the abbreviated designation (letter / number) used in this booklet as well as the exact type of cabin (e.g. K55). We are always open to your comments and suggestions.
