Menu 7 - Display; Menu 8 - Power Management; 3.3.10 Menu 9 - Flowmeter - Fluidwell F Series Manual

Page 16
3.3.8

MENU 7 - DISPLAY

7 DISPLAY
7.1 FUNCTION
7.2 ALARM SET
7.3 LIGHT
7.4 BL ALARM
3.3.9

MENU 8 - POWER MANAGEMENT

When used with the internal battery option (type PB/PC), the user can expect reliable measurement
over a long period of time. The F114-P has several smart power management functions to extend
the battery life time significantly. Two of these functions can be set.
8 POWER MANAGEMENT
8.1 LCD NEW
8.2 BATTERY MODE

3.3.10 MENU 9 - FLOWMETER

9 FLOWMETER
9.1 SIGNAL A
TYPE OF SIGNAL
NPN
NPN - LP
REED
REED - LP
PNP
PNP - LP
NAMUR
COIL-HI
COIL-HI (type ZF)
COIL-HI (type ZG)
COIL LO
Sets the flow rate and/or total values to be shown on the main display.
DISABLE no flow rate or total will be shown
RATE flow rate A and B will be shown (no totals)
TOTAL total A and B are shown (no flow rate)
BOTH flow rates and totals will be shown
Enables the setting of alarm levels in Operator mode.
The backlight brightness can be adjusted from 0% (off) to 100% (full
brightness) in steps of 20%.
Sets the backlight functionality during alarm condition.
The calculation of the display-information influences the power
consumption significantly. When the application does not require a fast
display refresh rate, it is strongly advised to select a slow refresh rate.
Please understand that NO information will be lost; every pulse will be
counted and the output signals will be generated in the normal way.
At a key press, the display refresh rate will switch to FAST for 30 seconds.
When 'OFF' is selected, the display goes off after 30 seconds after the last
key press. The display temporarily comes on after a key press.
Example battery life-time with a coil pick-up:
• 1kHz pulse and FAST update: about 2 years;
• 1kHz pulse and 1 sec update: about 5 years.
The F114-P has two modes: operational or shelf.
After "shelf" has been selected, the F114-P can be stored for several
years; it will not process the sensor signal; the display is switched off but all
settings and totals are stored. In this mode, power consumption is
extremely low.
To wake up the F114-P again, press the SELECT/▲ key two times.
With this setting the type of output of flowmeter A is selected. The settings
with LP (low-pass) filter are used to apply a build-in noise reduction.
Selections "active pulse" offer a detection level of 50% of the supply
voltage.
EXPLANATION RESISTANCE
NPN input 100 kΩ pull-up
NPN with low pass
100 kΩ pull-up
filter
Reed-switch input 1 MΩ pull-up
Reed-with low pass
1 MΩ pull-up
filter
PNP input 100 kΩ pull-down
PNP with low pass
100 kΩ pull-down
filter
NAMUR input 820 Ω pull-down
High sensitive coil
input
Low sensitive coil
input
FW_F114-P_M_v2201-02_EN.docx
FREQ. / mV
max. 6 kHz.
max. 1.2 kHz.
max. 1.2 kHz.
max. 120 Hz.
max. 6 kHz.
max. 1.2 kHz.
max. 4 kHz.
min. 20 mV
-
min. 10 mV
min. 5 mV
pp
- min. 80 mV
REMARK
PP
(open collector)
(open collector) less
sensitive
Less sensitive
Less sensitive
External power
required
pp
Sensitive for
pp
interference!
Normal sensitivity
pp
