- Page 1 AVX-105C-TX USB-C over Copper Transmitter with PoE OPERATION MANUAL...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ..........1 3. Package Contents .........1 4. System Requirements ........1 5. Features ............2 6. Operation Controls and Functions ....3 6.1 Front Panel .............3 6.2 Rear Panel ...............4 7. Connection Diagram ........5 8. Specifications ..........6 8.1 Technical Specifications ........6 8.2 Video Specifications..........7 8.3 Audio Specifications ...........9 8.3.1 Digital Audio ..........9... -
Page 6: Introduction
1. INTRODUCTION This 4K UHD USB-C over Copper Transmitter and Receiver is designed for high-quality AV extension with minimum latency. By using a sophisticated ultra-light compression scheme (lossless for most content) it’s a great solution for extending 4K@60Hz (4:4:4) audio/video streams. Advanced video content such as HDR (High Dynamic Range), 10-bit color and multi-channel HD Bitstream audio can be easily transmitted. -
Page 7: Features
5. FEATURES HDMI 2.0 (via USB-C) compatible HDCP 2.2 and HDCP 1.x compliant 1x USB-C input, 1x 10GbE output (Transmitter) 1x 10GbE input, 1x HDMI output (Receiver) Ultra-light compression, lossless for most content Extension up to 100m when using at.6A/7 Supports up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video input and output... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel VIDEO CAT6A/7 Power LED: This LED will illuminate to indicate the unit is on and receiving power. Note: This LED will blink during the firmware update process. SYS LED: This LED will illuminate to indicate that the system is stable and ready to process audio/video streams. -
Page 9: Rear Panel
6.2 Rear Panel USB-C IN DC 48V USB-C IN Port: Connect to USB-C source equipment such as a laptop, PC, set-top box, or media player. Note: The unit can optionally be powered directly via this port. DC 48V Port: Plug the 48V DC power adapter into this port and connect it to an AC wall outlet for power. - Page 10 6.3 Receiver Front Panel HDMI OUT VIDEO CAT6A/7 Power ( ) LED: This LED will illuminate to indicate the unit is on and receiving power. Note: This LED will blink during the firmware update process. System ( ) LED: This LED will illuminate to indicate that the system is stable and ready to process audio/video streams.
-
Page 11: Connection Diagram
7. CONNECTION DIAGRAM Power Supply PC / Laptop USB-C IN DC 48V VIDEO CAT6A/7 USB-C In Cable HDMI Output HDMI OUT VIDEO CAT6A/7 SERVICE DC 48V HDMI TV / Display Power Supply (Optional) -
Page 12: Specifications
8. SPECIFICATIONS 8.1 Technical Specifications USB-C Bandwidth 21.6 Gbps Ethernet Bandwidth 10 Gbps Input Ports [TX] 1×USB (Type-C) [RX] 1×10GbE (RJ-45) Output Ports [TX] 1×10GbE (RJ-45) [RX] 1×HDMI (Type-A) Power Supply 48V/0.83A DC (US/EU standards, CE/FCC/UL certified) ESD Protection (HBM) ±8kV (Air Discharge) ±4kV (Contact Discharge) TX Dimensions (W×H×D) -
Page 13: Video Specifications
8.2 Video Specifications Input Output Supported Resolutions (Hz) USB-C 10GbE 720×400p@70/85 640×480p@60/72/75/85 720×480i@60 720×480p@60 720×576i@50 720×576p@50 800×600p@56/60/72/75/85 848×480p@60 1024×768p@60/70/75/85 1152×864p@75 1280×720p@50/60 ... - Page 14 Input Output Supported Resolutions (Hz) USB-C 10GbE 1920×1080p@24/25/30 1920×1080p@50/60 1920×1200p@60RB 2560×1440p@60RB 2560×1600p@60RB 2048×1080p@24/25/30 2048×1080p@50/60 3840×2160p@24/25/30 3840×2160p@50/60 (4:2:0) 3840×2160p@24, HDR10 3840×2160p@50/60 (4:2:0), ...
-
Page 15: Audio Specifications
8.3 Audio Specifications 8.3.1 Digital Audio USB-C Input/Output / 10GbE Output/Input LPCM Max Channels 8 Channels Sampling Rate (kHz) 32~192 Bitstream Supported Formats Standard & High-Definition... -
Page 16: Cable Specifications
8.4 Cable Specifications Cable Length USB-C Cable USB-C Input Ethernet Cable Cat.6A/7 100m 1080p 4K30 4K60 (4:4:4) (4:4:4) Cable Length 8-bit 12-bit 8-bit 8-bit High Speed HDMI Cable HDMI Input Bandwidth Category Examples: • HD Video - 720p@60Hz - HDMI transmission rates lower than 3Gbps - HD-SDI (SMPTE 292M, 1.485Gbps) •... - Page 17 • 4K UHD Video - 1080p@120Hz (10/12-bit HDR) - 4K@50/60Hz (4:4:4, 8-bit) & 4K@50/60Hz (4:2:0, 10/12-bit HDR) - HDMI transmission rates between 10.2Gbps and 18Gbps - 12G-SDI (SMPTE ST 2082, 12Gbps) • 8K UHD Video - 4K@120Hz (10/12-bit HDR) - 8K@24/25/30Hz (10/12-bit HDR) & 8K@50/60Hz (4:2:0, 8-bit color) - HDMI transmission rates between 18Gbps and 48Gbps - 24G-SDI (SMPTE ST 2083, 24Gbps)
-
Page 18: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM 10GbE 10 Gigabit Ethernet 4K UHD 4K Ultra-High-Definition (10.2Gbps max) 4K UHD 4K Ultra-High-Definition (18Gbps max) 8K UHD 8K Ultra-High-Definition (48Gbps max, without DSC) 8K UHD 8K Ultra-High-Definition (48Gbps max, with DSC) AVoIP Audio/Video over IP Cat.5e Enhanced Category 5 cable Cat.6... - Page 19 ACRONYM COMPLETE TERM Universal Serial Bus VoIP Video over IP...
- Page 20 CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton, Middlesex, TW17 8BA Tel: +44 (0) 20 3137 9180 | Fax: +44 (0) 20 3137 6279 Email: sales@cypeurope.com www.cypeurope.com v1.00...
